Profile Performance Reverse Osmosis Filtration System
PNRV18ZBB01, PNRV18ZBL01, PNRV18ZWW01, PNRV18ZWH01

TABLE OF CONTENTS:

IMPORTANT INSTALLATION RECOMMENDATIONS

Read entire manual. Failure to follow all guides and rules could cause personal injury or property damage.
• BE SURE TO FOLLOW ALL APPLICABLE STATE AND LOCAL CODES.
• Use a qualified installer.
• Do not install the Reverse Osmosis system outside or in extreme hot or cold temperatures. DO NOT INSTALL ON HOT WATER.
• Recommended installation is under the sink. However, the unit can be installed in a remote location, up to 30 feet away from the sink.
Additional installation materials may be required.
• If unit is installed in basement, with faucet on 1st floor, some capacity loss may be experienced. RVTNK1 can be purchased to provide
additional capacity.
• If Reverse Osmosis system is connected to a refrigerator icemaker, a special icemaker connection kit is required (RVKIT). Do not use
copper tubing for the connection between the Reverse Osmosis system and the refrigerator.
• Be sure the water supply conforms to the specifications on page 2. If water supply conditions are unknown, contact your municipal
water company or your local health department for a list of contaminants in your area and a list of laboratories certified by your state
to analyze drinking water.
WARNING: Do not use with water that is microbiologically unsafe or of unknown quality without adequate disinfection before
or after the system. Systems certified for cyst reduction may be used on disinfected water that may contain filterable cysts. This
Reverse Osmosis system contains a replaceable treatment membrane cartridge critical for effective reduction of Total Dissolved
Solids. The water should be tested periodically to verify that the system is performing satisfactorily. This system is acceptable for
treatment of influent concentrations of no more than 27 mg/L nitrate and 3 mg/L nitrite in combination measured as N and is
certified for nitrate/nitrite reduction only for water supplies with a pressure of 280kPa (40 psig) or greater. Small parts remaining
after the installation could be a choke hazard. Discard safely.
7178993 (7-00 JR) 215C1001P005-6
Pub. No. 49-5807-6
GE SmartWater

INSTALLATION INSTRUCTIONS

For Use and Care questions call: GE Answer Center® 800.626.2000
GENERAL ELECTRIC COMPANY, Appliance Park, Louisville, KY 40225
™
Page #
1
2
2
3
4
5
6
7
8
8
9
9
10, 11
1
The GE RO PNRV18Z Model
Series is Tested and Certified
to ANSI/NSF Standard 58 for
TDS and Cyst reduction.

Advertisement

Table of Contents
loading

Related Manuals for GE Smart Water PNRV18ZWH01

Summary of Contents for GE Smart Water PNRV18ZWH01

  • Page 1: Table Of Contents

    280kPa (40 psig) or greater. Small parts remaining after the installation could be a choke hazard. Discard safely. 7178993 (7-00 JR) 215C1001P005-6 For Use and Care questions call: GE Answer Center® 800.626.2000 Pub. No. 49-5807-6 GENERAL ELECTRIC COMPANY, Appliance Park, Louisville, KY 40225...

  • Page 2: Product Specifications

    MODEL PNRV18Z PRODUCT SPECIFICATIONS Feed water pressure limits—pounds per square inch (psi) 40–125 Feed water temperature limits—minimum/maximum degrees F 40–100 Maximum Total Dissolved Solids (TDS)—parts per million (ppm) 2000 Maximum water hardness @ 6.9 pH—grains per gallon (gpg) Maximum iron, manganese, hydrogen sulfide (ppm) <0.1 Chlorine in water supply allowable...

  • Page 3: Things To Check Before Installation

    THINGS TO CHECK BEFORE BEGINNING INSTALLATION FEED WATER—The water supply to the undercounter Reverse Osmosis system must Fig. 1A. have the qualities listed in the specifications (see page 2). Municipal water supplies most often will have these qualities. Well water may need conditioning—have the water tested by a water analysis laboratory and get their recommendations for treatment.

  • Page 4: Step-By-Step Installation Instructions

    STEP-BY-STEP INSTALLATION INSTRUCTIONS FEED WATER SUPPLY Check and comply with local plumbing codes as you plan, then install a cold feed water supply fitting. For new home installation using standard plumbing fittings, see Fig. 2A below. A typical installation for existing homes using the saddle valve is shown in Fig. 2B below. A.

  • Page 5: Drain Connection Installation

    FILTRATION DRAIN CONNECTION INSTALLATIONS Check and comply with all state and local plumbing codes as you plan. Fig. 3A. CAUTION: The options detailed below are the ONLY approved installation Drain line from From second sink configurations. Do not use any drain saddle device. Reverse Osmosis or disposer by-passing faucet...

  • Page 6: Electronic Faucet Installation

    ELECTRONIC FAUCET INSTALLATION Nut (2) Be sure there is room underneath the sink to make the needed Fig. 4B. Fig. 4A. TOP VIEW connections. Select one of the following places to install the faucet: Screw (2) —IN an existing sink spray attachment or soap dispenser hole Screw (2) —IN a hole to be drilled in the sink top Faucet...

  • Page 7: Tubing And Electronics Connection

    (see Fig. 5). If needed, a 15′ leadwire extension (marked “WATER SUPPLY”) from the Reverse Osmosis inlet is available from GE (part #WS07X10009). to the feed water supply fitting (reference Fig. 2A or 2B, page 4). Connect the tubing as applies (Fig. 2A or 2B, page 4) and tighten the nut securely (use Teflon Tape™...

  • Page 8: Reverse Osmosis Assembly And Storage Tank Installation

    SANITIZING THE REVERSE OSMOSIS SYSTEM Cone screen Sanitize upon installation of the Reverse Osmosis system and after servicing inner Fig. 6A. parts of the Reverse Osmosis system, including replacement of prefilter, postfilter and Reverse Osmosis cartridge. It is important to wash hands with anti-bacterial Reverse Flow soap before handling inner parts of the system.

  • Page 9: Installation Checklist

    2. Open the RO faucet until the tank is empty and flow stops. 3. Close the RO faucet and repeat these steps three more times. THE GE ELECTRONIC MONITOR SYSTEM The system is ready to make product water for use.

  • Page 10: Parts List

    FAUCET AIR GAP BOTTOM 47, 48 49, 50 WS15X10014 SHUTOFF ASM. NOTE: Codes in the state of Massachusetts require installation by a licensed plumber and do not permit the use of the saddle valve. For installation, use plumbing code 248-CMR of the Commonwealth of Massachusetts.
  • Page 11 GENERAL ELECTRIC PARTS CATALOG P N R V 1 8 Z REF. NO. PART NO. PART DESCRIPTION BB01 BL01 WH01 WW01 0001 WS15X10011 FAUCET BLACK TIP & LEVER WS15X10013 FAUCET–ALL WHITE 0003 WS10X10008 TOP FAUCET BASE BLACK WS10X10010 TOP FAUCET BASE WHITE 0004 WS02X10007 SCREW #6-32 X 1 -3/8″...
