Icom IC-F31GS Servise Manual page 19

[MAIN UNIT]
REF ORDER
NO. NO.
R1 7030003670 S.RESISTOR
R2 7030000280 S.RESISTOR
R3 7030003480 S.RESISTOR
R4 7030003480 S.RESISTOR
R5 7030005040 S.RESISTOR
R6 7030005040 S.RESISTOR
R7 7030003240 S.RESISTOR
R8 7030008290 S.RESISTOR
R10 7030005590 S.RESISTOR
R12 7030005050 S.RESISTOR
R14 7030005530 S.RESISTOR
R15 7030007570 S.RESISTOR
R16 7030005590 S.RESISTOR
R17 7030007570 S.RESISTOR
R18 7030004980 S.RESISTOR
R19 7030005050 S.RESISTOR
R20 7030005120 S.RESISTOR
R21 7030004980 S.RESISTOR
R22 7030005240 S.RESISTOR
R23 7030009320 S.RESISTOR
R24 7030004990 S.RESISTOR
R25 7030005070 S.RESISTOR
R26 7030004980 S.RESISTOR
R28 7030005070 S.RESISTOR
R29 7030005050 S.RESISTOR
R30 7030008400 S.RESISTOR
R31 7030008410 S.RESISTOR
R32 7030007250 S.RESISTOR
R33 7030007280 S.RESISTOR
R34 7030008400 S.RESISTOR
R35 7030008410 S.RESISTOR
R36 7030005530 S.RESISTOR
R37 7030009280 S.RESISTOR
R38 7030007290 S.RESISTOR
R39 7030005530 S.RESISTOR
R40 7030004980 S.RESISTOR
7030005530 S.RESISTOR
R41 7030005110 S.RESISTOR
R42 7030005090 S.RESISTOR
R43 7030009270 S.RESISTOR
7030005030 S.RESISTOR
R44 7030005290 S.RESISTOR
7030005040 S.RESISTOR
R45 7030005530 S.RESISTOR
R46 7030005040 S.RESISTOR
7030008010 S.RESISTOR
R47 7030005050 S.RESISTOR
7030009710 S.RESISTOR
R48 7030005050 S.RESISTOR
R49 7030005290 S.RESISTOR
R50 7030005120 S.RESISTOR
R51 7030005050 S.RESISTOR
R52 7030004980 S.RESISTOR
R53 7030005110 S.RESISTOR
R54 7030004980 S.RESISTOR
R55 7030005220 S.RESISTOR
R57 7030009700 S.RESISTOR
R58 7410000950 S.ARRAY
R59 7030009700 S.RESISTOR
R60 7030005090 S.RESISTOR
R61 7030005110 S.RESISTOR
R62 7030007570 S.RESISTOR
R63 7030005580 S.RESISTOR
R64 7030005240 S.RESISTOR
R65 7030005240 S.RESISTOR
R66 7030005240 S.RESISTOR
R67 7030005090 S.RESISTOR
R69 7030005090 S.RESISTOR
R73 7030005090 S.RESISTOR
R75 7030005090 S.RESISTOR
R77 7030007340 S.RESISTOR
R78 7030005220 S.RESISTOR
R79 7030008010 S.RESISTOR
R80 7030005220 S.RESISTOR
R81 7030009320 S.RESISTOR
R82 7030007340 S.RESISTOR
R85 7030007280 S.RESISTOR
R86 7030005080 S.RESISTOR
R87 7030008410 S.RESISTOR
R88 7030005240 S.RESISTOR
R89 7030005030 S.RESISTOR
R90 7030004970 S.RESISTOR
[GT]: IC-F30GT/F31GT, [GS]: IC-F30GS/F31GS,
[F30G]: IC-F30GT/F30GS, [F31G]: IC-F31GT/F31GS
[IS]: Intrinsically safe version
DESCRIPTION
ERJ3GEYJ 823 V (82 kΩ)
MCR10EZHJ 150 Ω (151)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ3GEYJ 220 V (22 Ω)
ERJ2GEJ 183 X (18 kΩ)
ERJ2GEJ 680 X (68 Ω)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 100 X (10 Ω)
ERJ2GEJ 122X (1.2 kΩ)
ERJ2GEJ 680 X (68 Ω)
ERJ2GEJ 122X (1.2 kΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 4R7 X (4.7 Ω)
ERJ2GEJ 221 X (220 Ω)
ERJ2GEJ 683 X (68 kΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 683 X (68 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 182 X (1.8 kΩ)
ERJ2GEJ 392 X (3.9 kΩ)
ERJ2GEJ 220 X (22 Ω)
ERJ2GEJ 331 X (330 Ω)
ERJ2GEJ 182 X (1.8 kΩ)
ERJ2GEJ 392 X (3.9 kΩ)
ERJ2GEJ 100 X (10 Ω)
ERJ2GE 391 X (390 Ω)
ERJ2GEJ 222 X (2.2 kΩ)
ERJ2GEJ 100 X (10 Ω)
ERJ2GEJ 101 X (100 Ω) [F30G]
ERJ2GEJ 100 X (10 Ω) [F31G]
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 821 X (820 Ω) [F30G]
ERJ2GEJ 152 X (1.5 kΩ) [F31G]
ERJ2GEJ 682 X (6.8 kΩ) [F30G]
ERJ2GEJ 472 X (4.7 kΩ) [F31G]
ERJ2GEJ 100 X (10 Ω)
ERJ2GEJ 472 X (4.7 kΩ) [F30G]
ERJ2GEJ 123 X (12 kΩ) [F31G]
ERJ2GEJ 103 X (10 kΩ) [F30G]
ERJ2GEJ 203 X (20 kΩ) [F31G]
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 682 X (6.8 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 202 X (2 kΩ)
EXB-V8V 102JV
ERJ2GEJ 202 X (2 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 122X (1.2 kΩ)
ERJ2GEJ 560 X (56 Ω)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 153 X (15 kΩ)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 123 X (12 kΩ)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 4R7 X (4.7 Ω)
ERJ2GEJ 153 X (15 kΩ)
ERJ2GEJ 331 X (330 Ω)
ERJ2GEJ 823 X (82 kΩ)
ERJ2GEJ 392 X (3.9 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 152 X (1.5 kΩ)
ERJ2GEJ 470 X (47 Ω)
[MAIN UNIT]
REF ORDER
NO. NO.
R91 7030005050 S.RESISTOR
R92 7030005240 S.RESISTOR
R93 7030005240 S.RESISTOR
R94 7030007300 S.RESISTOR
R95 7030009320 S.RESISTOR
R96 7030008410 S.RESISTOR
R97 7030005010 S.RESISTOR
R98 7030005090 S.RESISTOR
R99 7030005120 S.RESISTOR
R102 7030008280 S.RESISTOR
R103 7030004990 S.RESISTOR
R105 7030005040 S.RESISTOR
R109 7030004980 S.RESISTOR
R110 7030005040 S.RESISTOR
R111 7030005100 S.RESISTOR
R112 7030005050 S.RESISTOR
R113 7030005110 S.RESISTOR
R114 7030005050 S.RESISTOR
R115 7030005050 S.RESISTOR
R116 7030005090 S.RESISTOR
R117 7030008280 S.RESISTOR
R118 7030005090 S.RESISTOR
R119 7030006610 S.RESISTOR
R120 7030007340 S.RESISTOR
R121 7030009320 S.RESISTOR
R122 7030008400 S.RESISTOR
R123 7030005240 S.RESISTOR
R124 7030005170 S.RESISTOR
R125 7030005050 S.RESISTOR
R126 7030005090 S.RESISTOR
R127 7030004980 S.RESISTOR
R128 7030005090 S.RESISTOR
R129 7030008410 S.RESISTOR
R130 7030005050 S.RESISTOR
R131 7030005230 S.RESISTOR
R132 7030008300 S.RESISTOR
R133 7030007290 S.RESISTOR
R134 7030003200 S.RESISTOR
R135 7030003200 S.RESISTOR
R136 7030005290 S.RESISTOR
R137 7030009140 S.RESISTOR
R138 7030007300 S.RESISTOR
R139 7030005120 S.RESISTOR
R140 7030005160 S.RESISTOR
R141 7030005070 S.RESISTOR
R150 7030005110 S.RESISTOR
R151 7030005100 S.RESISTOR
R152 7030005100 S.RESISTOR
R153 7030009320 S.RESISTOR
R155 7030007350 S.RESISTOR
R157 7030005220 S.RESISTOR
R159 7030005090 S.RESISTOR
R161 7030005070 S.RESISTOR
R162 7030005070 S.RESISTOR
R163 7030005060 S.RESISTOR
R164 7030005110 S.RESISTOR
R165 7030005240 S.RESISTOR
R166 7030005050 S.RESISTOR
R167 7030005170 S.RESISTOR
R168 7030007350 S.RESISTOR
R171 7030005070 S.RESISTOR
R172 7030005070 S.RESISTOR
R173 7030005100 S.RESISTOR
R174 7030005600 S.RESISTOR
R175 7030009290 S.RESISTOR
R176 7030005720 S.RESISTOR
R177 7030008290 S.RESISTOR
R178 7030005600 S.RESISTOR
R179 7030005600 S.RESISTOR
R180 7030007340 S.RESISTOR
R181 7030005600 S.RESISTOR
R182 7030005600 S.RESISTOR
R183 7030005030 S.RESISTOR
R184 7030008010 S.RESISTOR
R185 7030005310 S.RESISTOR
R186 7030005070 S.RESISTOR
R187 7030005040 S.RESISTOR
R188 7030005090 S.RESISTOR
R189 7030005000 S.RESISTOR
R190 7030005090 S.RESISTOR
R192 7030005090 S.RESISTOR
R193 7210003060 VARIABLE
*=Safety critical components
6 - 3
DESCRIPTION
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 332 X (3.3 kΩ)
ERJ2GEJ 4R7 X (4.7 Ω)
ERJ2GEJ 392 X (3.9 kΩ)
ERJ2GEJ 681 X (680 Ω)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 271 X (270 Ω)
ERJ2GEJ 221 X (220 Ω)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 154 X (150 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 271 X (270 Ω)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 394 X (390 kΩ)
ERJ2GEJ 153 X (15 kΩ)
ERJ2GEJ 4R7 X (4.7 Ω)
ERJ2GEJ 182 X (1.8 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 474 X (470 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 392 X (3.9 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 334 X (330 kΩ)
ERJ2GEJ 184 X (180 kΩ)
ERJ2GEJ 222 X (2.2 kΩ)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 100 V (10 Ω)
ERJ2GEJ 682 X (6.8 kΩ)
ERJ2GEJ 272 X (2.7 kΩ)
ERJ2GEJ 332 X (3.3 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 105 X (1 MΩ)
ERJ2GEJ 683 X (68 kΩ)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 154 X (150 kΩ)
ERJ2GEJ 154 X (150 kΩ)
ERJ2GEJ 4R7 X (4.7 Ω)
ERJ2GEJ 393 X (39 kΩ)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 683 X (68 kΩ)
ERJ2GEJ 683 X (68 kΩ)
ERJ2GEJ 333 X (33 kΩ)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 474 X (470 kΩ)
ERJ2GEJ 393 X (39 kΩ)
ERJ2GEJ 683 X (68 kΩ)
ERJ2GEJ 683 X (68 kΩ)
ERJ2GEJ 154 X (150 kΩ)
ERJ2GEJ 273 X (27 kΩ)
ERJ2GEJ 562 X (5.6 kΩ)
ERJ2GEJ 563 X (56 kΩ)
ERJ2GEJ 183 X (18 kΩ)
ERJ2GEJ 273 X (27 kΩ)
ERJ2GEJ 273 X (27 kΩ)
ERJ2GEJ 153 X (15 kΩ)
ERJ2GEJ 273 X (27 kΩ)
ERJ2GEJ 273 X (27 kΩ)
ERJ2GEJ 152 X (1.5 kΩ)
ERJ2GEJ 123 X (12 kΩ)
ERJ2GEJ 124 X (120 kΩ)
ERJ2GEJ 683 X (68 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 471 X (470 Ω)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 104 X (100 kΩ)
TP76N00N-15F-10KA-2251
S.=Surface mount
