Quick Setup Guide

VideoEdge IP Indoor Mini-dome

Part Number 8200-2646-08 B0

Table of Contents

Need help?

Do you have a question about the ADCIPE3312ISPU and is the answer not in the manual?

Page 1 Quick Setup Guide VideoEdge IP Indoor Mini-dome Part Number 8200-2646-08 B0...
Page 2 Quick Setup Guide...
Page 4: The Front View
1. The Front View ETHERNET AC 24V -DC 12V+ (PoE) VIDEO 1 2 3 4 5 6 7 8 RESET USB 1. SD CARD slot: his is used for system software updating and archiving / accessing critical images. 2. RESET: estore factory defaults.
Page 5: Lens Adjustment
Quick Setup Guide 2. Lens Adjustment Before adjusting the lens, you must remove the cover of the dome. There are 4 screws holding the cover in place. 1) Loosen the screws holding the camera mount and then 2) carefully lift the cover up. After all adjustments are made, attach the dome cover to the camera.
Page 6 3. Cover Attaching To attach the dome to the base, please do as follows: (1) and (2). (1) The protrusion (the convex-shaped fitter) that reaches right up to the edge of the ring on the dome cover must align with the concave on the dome body.
Page 7 Quick Setup Guide Step 4: Check UPnP User Interface, and choose OK. Step 5: Click Next when the original Network Component Wizard dialog box returns. After about one minute the UPnP installation is complete. Step 6: Select Finish to close. 3.
Page 8 Model ADCIPE3312ISN VideoEdge IP Indoor Mini-dome, 3.3-12mm, smoke, NTSC, w/PS ADCIPE3312ISPE VideoEdge IP Indoor Mini-dome, 3.3-12mm, smoke, PAL, EU Plug, w/PS ADCIPE3312ISPU VideoEdge IP Indoor Mini-dome, 3.3-12mm, smoke, PAL, UK Plug, w/PS System PAL/ NTSC Video sensor 1/3” Sony Super HAD CCD...
