Onkyo TX-SR875 Service Manual

SERVICE MANUAL
AV RECEIVER
MODEL
STANDBY/ON
STANDBY
READY
ZONE 2
ZONE 3
PURE AUDIO AUDIO SEL DVD VCR/DVR CBL/SAT
TX-SR875 Black, Golden and Silver models
B UDC, S UDC, B MDC, S MDC
G UDT
B UMP, S UMP, B UMB, S UMB
B MMP, S MMP, B MMB, S MMB
G UMK, G UMT
SAFETY-RELATED COMPONENT
WARNING!!
COMPONENTS IDENTIFIED BY MARK
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.
MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.
