Beat-Sonic Installation Instruction:
Product: NDS6223EP
Car Model: 2014-2015 Lexus GX460
Disclaimer:
We are not responsible to damage, loss or injury caused from attempting or performing the DIY. Further,
the navigation and DVD lock while in motion was originally installed for safety reasons. By unlocking the
navigation and DVD lock, we are assuming that the navigation and DVD will be controlled and enjoyed
by the passenger and not by the driver. As such, are not responsible to damage, loss or injury from using
the bypass modules. Please be responsible drivers!
For additional information, contact:
info@beatsonicusa.com
About the Beat-Sonic NAV/DVD Bypass Module:
System: 100% Plug and play kit from Beat-Sonic for allowing use of factory features that would be
locked out during vehicle movement.
These plug and play module kits allow override of the lock out system equipped in your factory
Navigation/DVD system when the vehicle is in motion. Due to the fact that no modification is needed on
the factory harness and this is 100% plug and play, it is easily reversible to the original factory specs
without showing any signs that this modification was ever made.
The NDS kit provides automatic video in motion for the DVD player at all times. Navigation in motion is
activated by the steering wheel volume control buttons by pressing volume up (+), down (-), up (+),
down (-) in sequence and at normal cadence. While navigation in motion is activated, the navigation
system will temporarily lose its GPS location and the position indicator on the navigation screen will stop
moving. By default, a programmable timer will reset the navigation in motion to switch off after 3
minutes.
Navigation in motion can be switched off before the timeout period has expired by repeating the
volume control button sequence up (+), down (-), up (+), down (-).
This device is suitable for Lexus generation 7 and 8 navigation systems. The full time video in motion
feature is compatible with all navigation system features including Lexus App Suite, Enform App Suite
and energy consumption display found on hybrid models.

1. The DIY Installation Starts Here:

2. PRECAUTION
NOTICE:
After turning the engine off (switch), it may be necessary to allow a period of time to elapse
before disconnecting
the cable from the battery terminal. Therefore, make sure to read the
"disconnecting the cable from the battery terminal notice" before proceeding with work.
