Beat-Sonic Installation Instruction:
Product: NDS6223EP
Car Model: 2014-2015 Lexus LS460
Disclaimer:
The navigation and DVD lock while in motion was originally installed for safety reasons. By unlocking the navigation and
DVD lock, we are assuming that the navigation and DVD will be controlled and enjoyed by the passenger(s) and not by
the driver. As such, are not responsible to damage, loss or injury from using the bypass modules. Please be responsible
drivers!
For additional information, contact:
info@beatsonicusa.com
About the Beat-Sonic NAV/DVD Bypass Module:
System: 100% Plug and play kit from Beat-Sonic for allowing use of factory features that would be locked out during
vehicle movement.
This plug-and-play module kit allows override of the lock out system equipped in your factory TV or Navigation/DVD
system when the vehicle is in motion. Due to the fact that no modification is needed on the factory harness and this is
100% plug and play, it is easily reversible to the original factory specs without showing any signs that this modification
was ever made.
The NDS kit provides automatic video in motion for the DVD player at all times. Navigation in motion is activated by the
steering wheel volume control buttons by pressing volume up (+), down (-), up (+), down (-) in sequence and at normal
cadence. While navigation in motion is activated, the navigation system will temporarily lose its GPS location and the
position indicator on the navigation screen will stop moving. By default, a programmable timer will reset the navigation
in motion to switch off after 3 minutes.
Navigation in motion can be switched off before the timeout period has expired by repeating the volume control button
sequence up (+), down (-), up (+), down (-).
This device is suitable for Lexus generation 7 and 8 navigation systems. The full time video in motion feature is
compatible with all navigation system features including Lexus App Suite, Enform App Suite and energy consumption
display found on hybrid models.
1. PRECAUTION
CAUTION: After turning the engine switch off, waiting time may be required before disconnecting the cable
from the battery terminal. Therefore, make sure to read the disconnecting the cable from the battery terminal
notice before proceeding with work

Advertisement

loading

Related Manuals for Beat-Sonic NDS6223EP

Summary of Contents for Beat-Sonic NDS6223EP

  • Page 1 About the Beat-Sonic NAV/DVD Bypass Module: System: 100% Plug and play kit from Beat-Sonic for allowing use of factory features that would be locked out during vehicle movement. This plug-and-play module kit allows override of the lock out system equipped in your factory TV or Navigation/DVD system when the vehicle is in motion.
  • Page 2 2. REMOVE COWL TOP VENTILATOR LOUVER RH. (a) Remove the 6 clips and cowl top ventilator louver RH. 3. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL NOTICE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected 4.
  • Page 3 6. REMOVE SHIFT LEVER KNOB SUB-ASSEMBLY. (a) Lower the shift lever boot and disconnect it from the shift lever knob sub-assembly. (b) Twist the shift lever knob sub-assembly in the direction indicated by the arrow and remove it. 7. REMOVE NO. 3 BOX PANEL. (a) Detach the 4 claws and remove the No.
  • Page 4 (e) Disconnect each connector and each wire harness clamp. 9. REMOVE UPPER INSTRUMENT CLUSTER FINISH PANEL. (a) Apply protective tape as shown in the illustration. (b) Hold the opposite end with one hand as shown in the illustration so that the clip can be firmly pushed. (c) Insert a screwdriver at the location shown in the illustration, and then push the lower clip on the backside of the upper instrument cluster finish panel towards the rear of the vehicle to detach it.
  • Page 5 Text in Illustration Protective Tape Lower Clip Rear of the Vehicle (d) Insert a screwdriver at the location shown in the illustration, and then push the lower clip on the backside of the upper instrument cluster finish panel towards the rear of the vehicle to detach it. NOTICE: Slowly push on the clip to detach it.
  • Page 6 Text in Illustration Protective Tape Lower Clip Rear of the Vehicle (e) Insert moulding remover A between the upper instrument cluster finish panel and lower No. 1 instrument panel finish panel, and between the upper instrument cluster finish panel and lower No. 2 instrument panel finish panel to detach the 3 upper clips and remove the upper instrument cluster finish panel.
  • Page 7 11. REMOVE LOWER NO. 2 INSTRUMENT PANEL FINISH PANEL. (a) Detach the 4 clips and 5 guides and remove the lower No. 2 instrument panel finish panel. 12. REMOVE LOWER NO. 1 INSTRUMENT PANEL FINISH PANEL. (a) Detach the 4 clips and 5 guides and remove the lower No. 1 instrument panel finish panel. (b) Disconnect the connector.

  • Page 8: Removing The Connector

    13. REMOVE MULTI-MEDIA MODULE RECEIVER ASSEMBLY. (a) Remove the 2 bolts. HINT: Grab a towel and rest the radio between the towel and center console to avoid scratching interior pieces. 14. REMOVING THE CONNECTOR. (a) The connector circled in red is what you will be working on.
  • Page 9 The right side of the connector is what you need to disconnect from the main connector. (e) Connect the male side of the NDS6223EP connector to the female connector which was disconnected from the previous step. Make sure the connection is secure and that none of the pins are exposed on the side.
  • Page 10 15. The GPS Connector.  2014-2015 Lexus LS owners: Please do not use the 1-pin connectors on the NDS6223EP. GPS on the 2014-2015 LS models does not engage the safety lockout feature. Wrap the 1-pin connectors on the NDS6223EP individually by using the electric tape and isolate them to avoid any unwanted contacts with other wires or connectors.
  • Page 11  Disconnect the steering wheel control connector.  Connect the matching connector on the NDS6223EP to the factory steering wheel control connector what you just disconnected from the head unit.
  • Page 12 Connect the other side of the NDS6223EP connector to the factory head unit. Programming the switch The default setting of the NDS6223EP is programmed to turn off automatically after 3 min. Please read the enclosed programming instruction (found inside the retail box) and program the switch to your desired setting.
