Summary of Contents for Baumatic B262ss
- Page 1 B262SS/B272M-A/ BK954PSS 60cm Multifunction built in oven...
- Page 2 User Manual for your Baumatic B262SS/B272M-A/ BK954PSS 60 cm Multifunction built in oven NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference;...
-
Page 3: Table Of Contents
5 – 7 Specifications 8-12 Specifications (B262SS) Specifications (B272M-A) Specifications (BK954PSS) Electrical details Control panel (B262SS) Control panel (B272M-A) Control panel (BK954PSS) Oven programmer/timer display Setting and using the oven programmer/timer 13-17 Selecting manual operation mode Setting the time of day... -
Page 4: Environmental Note
Environmental note o The packaging materials that Baumatic uses are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the environment. -
Page 5: Important Safety Information
Your new appliance is guaranteed against electrical or mechanical defects, subject to certain exclusions that are noted in Baumatic’s Conditions Of Guarantee. The foregoing does not affect your statutory rights. o Repairs may only be carried out by Baumatic Service Engineers or their authorised service agent. - Page 6 Warning and safety instructions o This appliance complies with all current European safety legislation. Baumatic do wish to emphasise that this compliance does not remove the fact that the appliance surfaces will become hot during use and retain heat after operation.
- Page 7 This appliance must be correctly installed by a suitably qualified person, strictly in accordance with the manufacturer’s instructions. o Baumatic Ltd. declines any responsibility for injury or damage, to person or property, as a result of improper use or installation of this appliance.
-
Page 8: Specifications
Specifications (B262SS) Product dimensions Aperture dimensions Height: 596 mm Height: 585 mm Width: 596 mm Width: 560 mm Depth: 565 mm Depth: 560 mm Product specifications o 9 functions o Energy efficiency class: A o Mark resistant coating o Oven capacity: 65 litres... -
Page 9: Specifications (B272M-A)
Specifications (B272M-A) Product dimensions Aperture dimensions Height: 596 mm Height: 585 mm Width: 596 mm Width: 560 mm Depth: 565 mm Depth: 560 mm Product specifications o 9 functions o Energy efficiency class: A o Oven capacity: 65 litres o LED full programmer o Cooling fan o Thermostatically controlled grill o Wipe-clean enamel cavity... -
Page 10: Specifications (Bk954Pss)
Specifications (BK954PSS) Product dimensions Aperture dimensions Height: 596 mm Height: 585 mm Width: 596 mm Width: 560 mm Depth: 565 mm Depth: 560 mm Product specifications o 9 functions o Energy efficiency class: A o Mark resistant coating o Oven capacity: 65 litres o LED full programmer o Cooling fan o Thermostatically controlled grill... -
Page 11: Electrical Details
Electrical details (B262SS/B272M-A/BK954PSS) Rated Voltage: 230 Vac 50 Hz Supply Connection: 16 A (double pole switched fused outlet with 3mm contact gap) Max Rated Inputs: 3.6 kW Mains Supply Lead: 3 x 1.5 mm² Oven Light Bulb: 25 W/300°C screw type pigmy... -
Page 12: Oven Programmer/Timer Display
Control panel (B272M-A) Oven function selector Timer end cook button knob Timer manual operation Power indicator light button Oven programmer/timer Timer minus button Timer minute minder Timer plus button button Oven operating light Timer duration button Thermostat control knob Control panel (BK954PSS) Oven function selector Timer end cook button knob... -
Page 13: Setting And Using The Oven Programmer/Timer
Setting and using the oven programmer/timer Selecting manual operation mode After your appliance is connected to your mains supply for the first time, the numbers on the timer display will flash. Before you can select a cooking function or set a temperature, you must set the appliance into manual operation mode. -
Page 14: Setting The Minute Minder Function
Setting the minute minder function You are able to set the minute minder at any time, regardless of whether an oven function has been selected. You can set a period of time using the minute minder function and an alarm will sound when this period of time has elapsed. -
Page 15: Setting The Duration Function
Setting the duration function This function will allow you to set a countdown time similar to the minute minder function. However the oven will no longer continue to heat, once the countdown period has elapsed. o Use the thermostat control knob (11) to set the temperature that you require. -
Page 16: Setting The End Cook Function
Setting the end cook function This function is similar to the duration function, however instead of selecting a period of time that you wish the oven to switch off after. You select the time of day that you wish the oven to switch off at. -
Page 17: Setting The Start And End Time Function
Setting the start and end time function This function will allow you to set a time in the future that the oven switches on at and a time that the oven will switch off at. o Use the thermostat control knob (11) to set the temperature that you require. -
Page 18: Selecting A Cooking Function And Temperature
Selecting a cooking function and temperature Selecting manual operation mode After your appliance is connected to your mains supply for the first time, the numbers on the timer display will flash. Before you can select a cooking function or set a temperature, you must set the appliance into manual operation mode. -
Page 19: Thermostat Control Knob
GRILL MODE: This method of cooking utilises the inner sections of the top element, which directs heat downwards onto the food. This function is suitable for grilling portions of bacon, toast and meat etc. FAN AND GRILL: This method of cooking utilises the top element in conjunction with the fan, which helps to provide a quick circulation of heat. -
Page 20: Oven Operating Light
Oven operating light This light will come on to indicate that the oven’s heating elements are in operation. The light will turn off when the temperature set on the thermostat control knob has been reached. It will cycle on and off throughout the cooking time. -
Page 21: Warnings
Warnings o Keep the oven door closed when using any of the grill functions. o Do not use aluminium foil to cover the grill pan or heat items wrapped in aluminium foil under the grill. The high reflectivity of the foil could potentially damage the grill element. o You should also never line the base of your oven with aluminium foil. -
Page 22: Cleaning And Maintenance
Any damage that is caused to the appliance by a cleaning product will not be fixed by Baumatic free of charge, even if the appliance is within the guarantee period. -
Page 23: Removable Oven Roof Liner
Removable oven roof liner o Your appliance is supplied with a roof liner, which should be slid over the top of the grill element. o Once you have finished cooking, the liner should be removed and thoroughly cleaned after each use of the appliance. o Do not allow fat and grease to build up on the oven liner, as this could cause a fire hazard. -
Page 24: Removing The Oven Door For Cleaning
Removing the oven door for cleaning To facilitate the cleaning of the inside of the oven and the outer frame of the oven, the door can be removed as follows:- o Open the oven door completely. o Insert an allen key into the hinge holes in the left hand hinge. -
Page 25: Installation
Care must be taken to ensure that the temperature of the mains supply cable does not exceed 50°C. o If the mains supply cable is damaged, then it must be replaced by an appropriate replacement which can be obtained from the Baumatic Spares Department. -
Page 26: Installing The Oven Into The Kitchen Cabinet
Installing the oven into the kitchen cabinet Ventilation cut out. Fixing the oven into a cabinet. o Ensure that the aperture that you will be fitting the oven into is of the size given in the above diagram. o Ensure that the rear panel of the furniture housing unit has been removed. -
Page 27: Ventilation Requirements
Ventilation requirements (Figure shows the ventilation and cut- out requirements for the installation of the appliance into a standard kitchen unit). (Figure shows the ventilation and cut-out requirements for the installation of the appliance into a tall housing unit). o Ensure that the oven has been securely fixed into the housing unit. -
Page 28: My Appliance Isn't Working Correctly
My appliance isn’t working correctly o The oven isn’t coming on. * Check that the oven is in manual operation mode. * Check that you have selected a cooking function and a cooking temperature. o There appears to be no power to the oven and grill. * Check that the appliance has been connected to the electrical mains supply correctly. - Page 29 Or any installation other than the one specified by Baumatic Ltd. has been completed. Please refer to the conditions of guarantee that appear on the...
