vehicle guide
XMC-10A
Important: This manual contains important safety and operating information. Please read, understand, and
follow the instructions in this manual. Failure to do so could result in personal injury, death, and/or damage
to your Xpress accessories, and/or to your vehicle or property
Advertisement
Table of Contents
Related Manuals for Audiovox Xpress XMC-10A
Summary of Contents for Audiovox Xpress XMC-10A
- Page 1 vehicle guide XMC-10A Important: This manual contains important safety and operating information. Please read, understand, and follow the instructions in this manual. Failure to do so could result in personal injury, death, and/or damage to your Xpress accessories, and/or to your vehicle or property...
-
Page 2: Table Of Contents
Table of Contents Congratulations ... 3 FCC Information ... 4 Cautions and Warnings ... 5 Contents XMC10A ... 6 Accessory Kit ... 7 Installation/Wiring Precautions ... 8 Setting Up and Installing Your Kit ... 9 Cabling Interconnections ... 9 Installing the Cradle Mount Base Assembly ... 9 Interconnect Diagram ... -
Page 3: Congratulations
Congratulations ® Thank you for purchasing the Audiovox Xpress XM Satellite Radio 2nd Vehicle Kit. You are one step closer to experiencing the latest innovation in XM Satellite Radio. XM Satellite Radio will revolutionize your vehicle or in-home entertainment. XM is America’s number one satellite radio service with more than 7 million subscribers. -
Page 4: Fcc Information
FCC Information Please note that the power cable that has been supplied with your device is supplied with permanently attached ferrite beads at each end. It is the responsibility of the user to use the cable with the ferrite beads. The user is cautioned that changes or modifications not expressly approved by XM Satellite Radio Inc. -
Page 5: Cautions And Warnings
Cautions and Warnings 1. Do not install the XMC10A vehicle cradle in a position that hinders your view through the windshield, or obstructs viewing of the dashboard indicators and displays. 2. Do not install the unit where it may obstruct the operation or deployment of safety devices, such as airbags, etc. -
Page 6: Contents Xmc10A
Contents XMC10A Install Manual Swivel Bracket 1 pc. Antenna 1 pc. Cassette Adapter 1pc. 12 Volt-to-5 Volt DC Power Adapter 1 pc. See XM SureConnect Vehicle installation Cradle XMC10A 1 pc. Kit 1 pc. XM SureConnect... -
Page 7: Accessory Kit
Contents XMC10A (Cont) ACCESSORY KIT Alcohol Cleaning Pad, Surface Cleaning Pad, Instruction Sheet, Antenna Cable Exit Plug OPTIONAL(sold separately) Audio Cable FM Direct Adapter (P/N SAT-RCA) (P/N XMFM-1) -
Page 8: Installation/Wiring Precautions
Installation/Wiring Precautions 1. To prevent a short-circuit, be sure to turn off the ignition and remove the negative (-) battery cable prior to installation. Connect power wires last. 2. Do not install the unit in locations exposed to direct sunlight or, in areas subject to extreme temperatures. -
Page 9: Setting Up And Installing Your Kit
You can begin to enjoy XM Satellite Radio as soon as the Xpress XM Receiver and Vehicle Kit installation are complete. Set up your Audiovox Xpress XM System using the following installation instructions, or enlist the help of a professional installer: 2. -
Page 10: Interconnect Diagram
Interconnect Diagram NOTE: 1. IF THE XMC10A IS INSTALLED USING THE OPTIONAL XMFM-1 FM DIRECT ADAPTER, DO NOT CONNECT AN AUDIO CABLE TO THE AUDIO OUT CONNECTOR OF THE CRADLE. 2. THE FM MODULATOR OPTION MUST BE SET TO ”FM ON” IN THE XPRESS XM USER MENU. - Page 11 Interconnect Diagram (Cont) XMC10A CRADLE (REAR VIEW) TO VEHICLE RADIO ANTENNA JACK OPTIONAL FM DIRECT ADAPTER XMFM-1 (SOLD SEPARATELY) XM ANTENNA XMC10A CRADLE (RIGHT SIDE VIEW) OPTIONAL SAT-RCA AUDIO CABLE (SOLD SEPARATELY) (CONNECT TO AUXILIARY AUDIO INPUTS ON VEHICLE HEAD UNIT.)
- Page 12 CAUTION: NOTE: The adhesive backing on the bracket will not permit easy repositioning once it has been mated to the surface; use extreme care and planning when selecting the mounting location. If the bracket is to be screwed to the surface, make sure the area in back of the mounting surface is clear of wires or other items to prevent unintentional damage.
- Page 13 Remove the plastic liner from the adhesive backing on the bracket, and fix the base in position on the surface; make sure the mounting pad is accurately positioned on the first try, since repositioning may be difficult, if not impossible. If the bracket is to be screwed in place, do not remove the plastic liner from the adhesive backing.
- Page 14 VERTICAL MOUNTING CONFIGURATION SWIVEL ADJUSTMENT SCREW PLASTIC LINER AND ADHESIVE BACKING SIDE (HORIZONTAL) MOUNTING CONFIGURATION XMC10A CRADLE ASSEMBLY SWIVEL SCREW HOLES (2) BRACKET FOR DIRECT HARD MOUNTING...
-
Page 15: Using Other Manufacturer's Mounts
3. Using Other Manufacturer’s Mounts The XMC10A Cradle can also be installed using other manufacturer’s mounts; the mounting plate provisions on the rear and bottom of the cradle provide you with two mounting options within the vehicle using various vehicle-specific aftermarket brackets. 4. - Page 16 Xpress XM RECEIVER REAR VIEW CRADLE FRONT VIEW CONNECTOR XMC10A GUIDE PIN SYSTEM CONNECTOR RECEIVER NOTCH Xpress XM RECEIVER SYSTEM CONNECTOR RAISED DETENT...
-
Page 17: Connection Options
5. Connection Options The Xpress Receiver and Cradle provide an audio output signal in three ways: a. FM Modulator - When using the XMC10A cradle with the FM modulator option, the XM audio signal can be received through your vehicle’s radio on selectable FM frequencies using the menu option included in your Xpress Receiver. - Page 18 Xpress Cassette Adapter -The XM Xpress Cassette Adapter offers an additional audio connection option by utilizing your existing vehicle’s in-dash cassette deck. XM research and lab test results show that using a vehicle cassette adapter can best maximize the relationship between the best sound quality and ease of installation (see chart below).
- Page 19 Xpress Cassette Adapter Installation. Installation is simple. 1.) Plug the end jack (1) into the XM Xpress Car Cradle’s audio output (2). 2.) Insert the cassette adapter (3) in the vehicle’s in-dash cassette slot (4).
-
Page 20: Installation Guidelines
6. Installation Guidelines Step 1. First, determine the proper location for your XM satellite radio antenna based on the following criteria for your specific vehicle: a. You must locate the satellite radio antenna on the top of the roof either in front of the rear window (option 1) or behind the windshield (option 2). - Page 21 c. Avoid kinking, crimping, twisting or chafing the cable. Use pre-existing wire channels when possible. d. For option 1 and rear mounting locations, route the cable into the trunk as shown in the previous illustration. Always cross the weather seal at the lowest part of the trunk to reduce water leaks.
- Page 22 Step 2. Once you have plugged the power and antenna jacks into the vehicle cradle, secure the cables with tape or wire ties to allow for a clean appearance.For example, secure the excess cable up under your dash board, between the seat and the console, or on the floor under a seat or floor mat.
- Page 23 NOTES...
-
Page 24: Warranty
12 MONTH LIMITED WARRANTY AUDIOVOX ELECTRONICS CORPORATION (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 12 months from the date of original... - Page 25 This Warranty gives you specific legal rights and you may also have other rights which vary from state to state. U.S.A. : AUDIOVOX ELECTRONICS CORPORATION, 150 MARCUS BLVD., HAUPPAUGE, NEW YORK 11788 (1-800-645-4994) 128-7351...
- Page 26 Audiovox Electronics Corporation 150 Marcus Blvd. Hauppauge, New York 11788 U.S.A. 1 800 645 4994 www.audiovox.com Printed on Recycled Paper XMC-10A ©2006 Audiovox Electronics Corporation. All rights reserved. XM name and related logos are trademarks of XM Satellite Radio Inc. 128-7472H...
