Page 1: Instruction Manual
The Kid Charge Controller Instruction Manual Features MPPT charge controller gives maximum yield for solar, wind and hydro Standard model can wall or flush mount Marine model includes mounting bracket Backlit LCD display Works as a load controller / Charge controller...
Page 2: Warnings
FOLLOW THESE INSTRUCTIONS CAREFULLY. If service or repair should become necessary, contact MidNite Solar Inc. Improper servicing may result in a risk of shock, fire or explosion. To reduce these risks, disconnect all wiring before attempting any maintenance or cleaning. Turning off the inverter will not reduce these risks. Solar modules produce power when exposed to light.
Page 3 Si vous ne comprenez pas l’une des concepts ou des instructions contenu dans cette manuel consulter un agent spécialisé. Si des réparations sont nécessaires contactez MidNite Solar pour plus des informations. Danger de choc électrique et de risque de brulure. Rien à dépanner à l'intérieure du cette appareil. Ne pas ouvrir le couver.
Page 4: Table Of Contents
The Kid Charge Controller Instructions Table of Contents Warnings....................2 The Kid Dimensions................6 Mounting The Kid................. 6 Stickers....................8 Wiring....................1 3 Load Circuit..................1 5 Aux Input / Output................1 6 MNBTS Battery Temperature Sensor...........1 8 Stacking The Kid.................. 1 8 Set-Up and Use...................
Page 5 The Kid Charge Controller Instructions The parts included in the hardware kit Included Hardware kit provide great flexibility for installing The Kid in many different locations. 9-61 4-1 90° 1 /2" snap-in Conduit adapter (2)* There are straight and right angle...
Page 6: Mounting The Kid
The hole cut into the wall must be very accurate. A template is provided at the end of this manual. The casting on the KID is 8.65” (21 9mm) x 4.54” (11 5mm) with a .400 (1 0mm) radii on each corner.
Page 7 2. Surface mount. The Kid can be mounted on a wall using the supplied wall mount adapter. As a minimum you will need to supply ½” strain reliefs to secure the wires to the casting. Regular metal strain reliefs are available at any hardware or electrical store.
Page 8 The Kid Charge Controller Instructions Sticker Identification 1 . Warning-Ignition Protected. 2. Equipment Grounding Terminal. 3. Warning Connection Sequence. 4. Do Not Overtighten. 5. Serial Number Shipping Box. 6. Separate Negatives. 7. Model Number. 8. Caution-Voltage Present. 9. Aux Out / Terminal Info.
Page 9 These warning labels are by the the regulatory standards that The Kid has been tested to. Required Place the stickers where shown. Some Stickers will be applied at the factory. Some are internal and number 1 7 will be on the shipping box.
Page 10: Stickers
The Kid Charge Controller Instructions Additional Stickers: In Canada CSA 22.2 No. 1 07.1 -01 requires certain information to be visible while the unit is in operation. To satisfy this requirement some additional stickers have been provided on the wall mount adapter.
Page 11: Wiring 1
This bracket comes standard with Marine versions. There are two metal pieces that come with the Marine Mount Bracket. A collar that mounts to the KID and the Marine mounting bracket base. Mount the KID to the collar using four 8-32 screws and nuts provided. The kit is available in black or white.
Page 12 Threadlocker 222 (Purple) is recommended to prevent the marine mount from ® loosening due to vibration. The Kid should be rotated no more than 1 5º to maintain protection from the rain/drip shield. 1 0-268-1 REV P25 1 2 | Page...
Page 13 Remove the screw on the middle right of the back cover and gently remove the back cover. The connections for PV/Wind input, Load/Clipper and Battery out are available on the terminal block shown below, located inside The Kid on the backside of the circuit board. Observe polarity on all connections.
Page 14 The Kid Charge Controller Instructions Grounding Lug Grounding points are provided inside and on the back of The Kid. This ground is inecessary to satisfy the requirements of UL458 Marine and RV standard. Install the external ground lug as shown below with the hardware supplied.
Page 15: Wiring
DC voltage rating of the battery bank with a minimum of 5000 Amp interrupt rating. Fuses incorporated into the KID are not to be used as these NEC required overcurrent devices. The internal KID fuses are for internal KID operation only. MidNite Solar manufactures numerous circuit breaker boxes for this use.
Page 16: Aux Input/Output
The Kid Charge Controller Instructions Aux input/output: This 2 position terminal block is the aux input/output. Presently the KID supports only the MidNite Whizbang Jr battery status monitor to these terminals. The top terminal connects to the single wire coming from the Whizbang Jr.
Page 17 See the power graph at the end of this section. Battery voltage for the KID can be 1 2, 24 or 48 volts, so that means when you jump to a 24V battery bank, the KID can process twice the power than if it were connected to a 1 2V battery.
Page 18: Mnbts Battery Temperature Sensor
KID and have it act like a 60 amp controller. This requires that the PV input and battery output be paralleled, You accomplish this outside of the KID in a suitable junction box. See page 21 for stacking set-up. Make sure to use wire and breakers of suitable size for each KID.
Page 19 The Kid Charge Controller Instructions Stacking Jumpers MasterStacking Port Slave Stacking Port USB Connector Jumper settings for stacking: In the upper right corner of the circuit board there are two positions for placing jumpers. If not stacking (only one Kid) or stacking two Kids leave the jumpers off. The jumpers may be placed on one pin to be saved for later use.
Page 20: Set-Up And Use
Battery plus to battery minus to get your nominal voltage. A 1 2V battery should read between 11 .5 and 1 3.00. By the way if it does read below 1 2V, that is not a good sign Then measure it again at the KID terminals.
Page 21 The Kid Charge Controller Instructions The next set of screens are where you select battery type. Selecting the applicable battery type sets some important parameters that are specific to different battery chemistries. The first choice is Flooded. Use the up arrow to see all the choices. Listed below.
Page 22 AGM etc. batteries. Different manufacturers have different requirements. Differences may be subtle, but the KID is capable of very fine adjustment. There is no reason to guess as to these important settings. When done, hit the right arrow key to go to the Float settings screen.
Page 23 Turn on the PV input breaker so the KID has PV array voltage applied. The KID is not yet turned on, so you will need to turn it on. To turn the KID on, you will need to get to the INPUT Main Menu. Use the right arrow key to go to the INPUT menu and push enter.
Page 24 Rebulk is the Voltage set-point at which the Float stage will terminate and return to Bulk. In Float, the Kid will return to Bulk if a load placed on the battery bank reduces the battery bank voltage below the Rebulk set point for two minutes.
Page 25 The Kid Charge Controller Instructions Load Menu: All loads are connected to the LOAD terminals of the main KID terminal block. Programming the Load Functions determine how and where the load is connected. (Battery vs. Input). Hitting the right arrow key brings up the INPUT menu.
Page 26 The Kid Charge Controller Instructions Low Battery Disconnect The kid includes an adjustable Low battery Disconnect function which allows the user to set an absolute discharge limit when using a daily function such as Night Light and the life of the batteries...
Page 27: Input Menu
The Kid Charge Controller Instructions Input Menu: The INPUT MENU is where you turn the KID on and off. There are 1 0 different selections for how the KID will track your Solar, Wind or Hydro system. Selections are below:...
Page 28 There is no limit to how many controllers can be connected in Follow Me mode. Both Follow Me and Bully mode are MidNite Solar exclusive methods of applying multiple controllers.
Page 29 The first (left) screen shows: The 9.5a as depicted above represents the PV array output current. BULKMPPT shows the state that the charger is in. BULKMPPT means the KID is going all out to put all available energy into the batteries.
Page 30 Setting up The Kid for use with a Whiz Bang Jr. (Sold separately) State Of Charge: The Kid in conjunction with the Whiz-Bang JR. offer a real battery tate harge meter. There is some set-up before using the WBJr. It is necessary to enter values for Battery bank size in Amp- Hours, battery efficiency, Battery temperature compensation reference, and percentage of change per degree C.
Page 31: Firmware Update
- Plug the other end into an available USB port on the PC. - Go to MAIN Menu on the Kid And scroll to the right to the TECH menu and press Enter. - Press the down arrow key until Firmware Update is selected and press Enter.
Page 32 Eco mode is the default mode. This mode will turn off the Backlight after 5 min of no user input on the keypad. Turning the backlight off helps reduce the idle power of the Kid by 1 /3 of a watt. This mode will also return the menus to the Main Status menu after 5 minutes has elapsed.
Page 33 LEDs as indicators, The top 3 LEDs refer to the Battery Capacity Meter function on the kid that indicates to the user the current battery status at a glance (refer to BCM Section for more info). The FLT LED will come on when the unit goes to Float. It will blink Slowly when the unit goes to Float MPPT.
Page 34: Wiring Diagrams
The Kid Charge Controller Instructions Wiring Diagrams 1 2 Volt System with two solar panels in series 1 2 Volt System with two solar panels in parallel 1 0-268-1 REV P25 34 | Page...
Page 35 The Kid Charge Controller Instructions 24 Volt System with two solar panels in series 24 Volt System with three solar panels in Series 1 0-268-1 REV P25 35 | Page...
Page 36 The Kid Charge Controller Instructions 24 Volt System with two strings of two panels 48 Volt System with three solar panels in series 1 0-268-1 REV P25 36 | Page...
Page 37 The Kid Charge Controller Instructions 48 Volt System with two strings of three panels Two Kids paralleled with stacking cable The string sizing tool is at www.midnitesolar.com 1 0-268-1 REV P25 37 | Page...
Page 38: Hypervoc
PV array is at its highest output voltage. This is very dangerous if the maximum operating voltage of the controller is exceeded. The Kid Solar controller gives you bonus headroom for those cold mornings that would potentially destroy any other controller. We have advised thousands of customers to play it safe in conditions like our example above.
Page 39: Accessories
The Kid Charge Controller Instructions PV Voltage levels shown are values. m ximum VOC will be 20% higher. Accessories Below are optional accessories and accessory kits. MNKID-BREAKER-30A 30 Amp replacement circuit breaker for The Kid. 1 0-268-1 REV P25 39 | Page...
Page 40 Black or white mounting bracket Flexible conduit Straight and 90° Conduit fittings MNBTS Battery temperature sensor Hardware to attach mounting bracket to The Kid MNKID-WMB-B (Black) or MNKID-WMB-W (White) Wall Mount kit Kit includes: Black wall mounting bracket Hardware to attach mounting bracket to The Kid.
Page 41 The Kid Charge Controller Instructions Accessories Continued MNHydrometer Easy to use battery hydrometer for checking the specific gravity on all "Flooded" style batteries. Size: 5.25"L x 4.25"W x 1 .5"D MNBCM / MNBCMS : Battery Status Monitor 1 . LEDs that correspond to battery voltage 2.
Page 42 The Kid Charge Controller Instructions Accessories Continued Whiz Bang Jr.: The Whiz Bang Jr. is designed to work with The Kid to give accurate battery status. The Whiz Bang Jr. keeps track of Amp-Hours going into and out of the battery. Simple one-wire installation.
Page 43 The Kid Charge Controller Instructions Optional Circuit Breakers and Accessories Quad Big Baby The Big Baby is an aluminum The Quad is an aluminum powder powder coated breaker enclosure coated breaker enclosure that holds that holds four DINRail breakers. four panel mount breakers.
Page 44: Specifications
(2) weeks after the end of the warranty period. The product must be accompanied by proof of purchase and Return Authorization (RA) number issued by MidNite Solar. For an RMA number contact MidNite Solar Inc., 1 7722 67th Ave NE, Arlington, WA 98223 (360) 403- 7207.
Page 45 The Kid Charge Controller Instructions 1 0-268-1 REV P25 45 | Page...
Page 46 Fuses / Overcurrent protection. Replace fuses with the same type and ratings: Type ATC 32V 30 Amps Max. The fuses provided in The Kid are for supplemental protection. External overcurrent protection as required as part of the installation. 1 0-268-1 REV P25...
Page 47: Wall Mount Template
The Kid Charge Controller Instructions Wall Mounting Template 4.50 4.54 5.01 0 1 0-268-1 REV P25 47 | Page...
