- Page 1 BDCOM Switch Module Hardware Installation Guide...
-
Page 2: Table Of Contents
1.2 Preparing to install the interface card........................1 1.2.1 Safety information ............................. 1 1.2.2 Tools & equipment needed........................2 Chapter 2 Installing Module in BDCOM Switches ........................ 3 Chapter 3 Connecting Module to a Network......................... 4 3.1 Installing Single-port 100Base-TX Ethernet Module....................4 3.1.1 Overview .............................. -
Page 3: Chapter 1 Overview Of Bdcom Module
BDCOM switch module Hardware Installation Guide Chapter 1 Overview of BDCOM Module 1.1 Module Overview This section explains the interface module of the BDCOM switch. BDCOM switch provides 2 extended Ethernet slots. Plug into the following interface module as needed: Type Name Label... -
Page 4: Tools & Equipment Needed
BDCOM switch module Hardware Installation Guide You should guarantee that the power of the power supply is powerful enough. Use the power safety. Do not insert/unlatch the cable with the power. Static protection: please wear anti-static loop in the process of installation. -
Page 5: Chapter 2 Installing Module In Bdcom Switches
BDCOM switch module Hardware Installation Guide Chapter 2 Installing Module in BDCOM Switches The section explains how to install interface module. Before installing interface module, make sure the switch is turned off. Note: Interface module does not support hot plug. Hot plug may cause permanent damage to interface module. -
Page 6: Chapter 3 Connecting Module To A Network
BDCOM switch module Hardware Installation Guide Chapter 3 Connecting Module to a Network 3.1 Installing Single-port 100Base-TX Ethernet Module Single-port 100Base-TX Ethernet module (LS-1FE-TX) adopts RJ45 interface standard. It supports 10/100Mbps auto-sense and auto-MDI/MDIX, which may realize Ethernet message transmission at 140m. -
Page 7: Ls-1Fe-Tx Ethernet Module Connection With External Device
BDCOM switch module Hardware Installation Guide 2. Single-port 100Base-TX Ethernet Module LED Name Note LINK Indicate the connection status of RJ45. Indicate transmission of RJ45. 3.1.3 LS-1FE-TX Ethernet Module Connection with External Device 3.2 Installing Single-port 100Base-FX(SM) Ethernet Module Single-port... -
Page 8: Ls-1Fe-Fx(Sm) Ethernet Module Connection With External Device
BDCOM switch module Hardware Installation Guide 1. Single mode Ethernet fiber optical transceiver module pin TX: optical signal transferring end; RX: optical signal receiving end. 2. Single-port 100Base-FX(SM) Ethernet Module LED Name Note LINK Indicate the connection status of the ports Indicate transmission of the ports 3.2.2... -
Page 9: Ls-1Fe-Fx(Mm) Ethernet Module Connection With External Device
BDCOM switch module Hardware Installation Guide Figuer 3-3 Single-port 100Base-FX(MM) Ethernet Module 1. Multi-mode Ethernet fiber optical transceiver module pin. TX: optical signal transferring end; RX: optical signal receiving end. 2. Single-port 100Base-FX(MM) Ethernet Module LED. Name Note Indicate the connection status of the LINK ports. -
Page 10: Overview
BDCOM switch module Hardware Installation Guide 3.4.1 Overview Single-port 1000Base-TX Ethernet module port supports 10/100/1000M auto-sense and auto-MDI/MDIX and adopts UTP 5 and is able to transfer 100m: Figuer 3-4 Single-port 1000Base-TX Ethernet Module 1. Cable of interface card Definition of 1000Base RJ45 pin Table 3-2 Pin NO. -
Page 11: Ls-1Ge-Tx Ethernet Module Connection With External Device
BDCOM switch module Hardware Installation Guide 3.4.2 LS-1GE-TX Ethernet Module Connection with External Device 3.5 Installing Single-port 1000Base-LX Ethernet Module Single-port 1000Base-LX Ethernet module (LS-1GE-LX) transform 1000Methenet message into optical message. Optic fiber transmission lengthen the transmission of Ethernet transmission. -
Page 12: Ls-1Ge-Lx Ethernet Module Connection With External Device
BDCOM switch module Hardware Installation Guide 2. Single-port 1000Base-LX Ethernet Module LED Name Note LINK Indicate the connection status of the ports Indicate transmission of the ports 3.5.2 LS-1GE-LX Ethernet Module Connection with External Device Connect the Single-port 1000Base-LX Ethernet module TX to 1000Base-LX Ethernet fiber optical transceiver module RX and the RX to the TX. -
Page 13: Ls-1Ge-Sx Ethernet Module Connection With External Device
BDCOM switch module Hardware Installation Guide 1. Gigabit multi-mode Ethernet optic module pin TX: optical signal transferring end. RX: optical signal receiving end. 2. Single-port 1000Base-SX Ethernet Module LED Name Note LINK Indicate the connection status of the ports. Indicate transmission of the ports. -
Page 14: Ls-1Ge-Sx Module And Connection To The External Device
BDCOM switch module Hardware Installation Guide GBIC-ZX-80 Remote single mode GBIC module. 80km erent transmission distance: Figuer 3-7 Single-port Gigabit GBIC Module Extension Panel 1. Gigabit GBIC optic module pin Arrow pointing outside: optical signal transferring end. Arrow pointing inside: optical signal receiving end. - Page 15 BDCOM switch module Hardware Installation Guide Identify the GBIC module. Confirm whether it is single mode or multi-mode; Hold the front side of GBIC module; Follow the direction of the arrow on the module and insert into the GBIT slot;...
