1
.
Fruit and vegetable crispers
2. Three adjustable cantilever shelves
3. Butter storage compartment
4. Portable egg tray
5. Freezer door juice-can shelf
6. Easy-Releasemice trays
7. Temperature controls (both fresh
food and freezer)
8. Power saver switch
9. Defrost water pan (behind grille)
10.
Model and serial number– record these
numbers here for future reference.
Rlodel #
Serial #
Do not remove rating plate.
D
NsTALLATioN
—
I1OW 5/8-inch clearance at both sides and at
p for ease of installation. When building a
ew home, consider providing water supply to
refrigerator location. It will simplify connec-
tion of optional automatic icemaker should
you wish to install one at a later date.
Yourrefrigerator should not be installed where
the temperature will go below 60°F. because
the refrigerator willnot run frequently enough
to maintain proper temperatures.
Be sure to install on a floor strong enough to
support a fully loaded refrigerator.
Adjustable legs at the front corners of the re-
frigerator should be set so the refrigerator is
firmlypositioned on the floor, and the front is
raised just enough that the doors close easily
whenoPened about ha]f-way.Removethe grille
by grasping at the bottom and pulling up and
out. (See Fig. 1).
3
~+burnadjustable legs left to raise the refrigera-
;.~:<- r, right to iower. (See Fig. 2).
3
To replace grille, set tabs on hooks at both ends
and push top toward refrigerator until grille
snaps into place. (See Fig. 3).
ELECTRICAL
C ONNECTION
I
IMR3FN-ANT
(PLEASE READ CAREFULLY]
FORPERSONAL SAFETY, T I-MS A PPLIANCE
MUST' B E PROPERLY GROUNDED.
The power cord of this appliance is equipped
with a three-prong (grounding) plug which
mates with a standard three-prong (grounding)
wall receptacle (Fig. 4) to minimize the possi-
bility of electric shock hazard from this appli-
ance. The customer should have the wali
receptacle and circuit checked by a qualified
electrician
to make sure the receptacle
is
properly grounded.
Pmwu?m
METHOD
y
yl!
Q
Q o
'1.
.
%
'.il—
2\\
INSURE PROPER GROUND
Fig. 4
EXISTSBEFORE USE
Where a standard two-prong wall receptacle is
encountered, it is the personal responsibility
and obligation of the customer to have it re-
placed with a properly grounded three-prong
wall receptacle.
IiXlNOT,
UNDERANYCUUXJMS'I'AIWES9
OUTOR REMOVETHE THNRD (GROUND]
p~lf-j~~ ~~lfj~ ~~~ p~~~~ $?-jf)~~.
1NFREQUENTL%
TEMPORARY $#ETWNl
(
a
/iDAPTER PLUGS NOT
PERMITTED M CANADA )
ALIGNLARGE
m
PRoNGS/SLOTs>
~Q~+:
0
~>
\
f=i:YK!R&&!wl!D
Fig.
BEFORE
USE
Because of potential safety hazards under cer-
tain conditions, we strongly recommend
against the use of an adapter plug. However, if
you still elect to use an adapter, where local
codes permit, a TEMPORARY CONNEC-
TION may be made to a properly grounded
two-prongwall receptacle by the use of a IX
listed adapter which is available at most local
hardware stores (Fig. 5). The larger slot in the
adapter must be aligned with the larger slot in
the wall receptacle to provide proper polarity
in the connection of the power cord.
CAUTION: Attaching the adapter ground ter-
minal to the wall receptacle cover screw does
not ground the appliance unless the cover
screw is metal, and not insulated, and the wall
receptacle
is grounded through [he house
wiring, The customer should have the circuit
checked by a qualified electrician
to make
sure the receptacle is properly grounded.
When disconnecting the power cord from the
adapter, always hold the adapter with one
hand. If this is not done, the adapter ground
terminal is very likely to break with repeated
use. Should this happen, DO NOT USE the
appliance until a proper ground has again
been established.
LJSAGE
SITUATIONS WHERE APPLIANCE'S
POWER CORD W!L!- BE DISCCINNECTED
FREQUENTLY
Do not use an adapter plug in these situations
because frequent disconnecting of the power
cord places undue strain on the adapter and
leads to eventual failure of the adapter ground
terminal. The customer should have the two-
prong wall receptacle
replaced with a three-
prong (grounding) receptacle by a qualified
electrician before using the appliance.
The refrigerator should alwaysbe plugged into
its own individual electrical outlet (115volt,
60 hertz, single phase AC.)
