M
CTF~SE
1. I'ruit and vegetable crispers
2. Three adiustab]e cantilever shelves
3.
Adjustable slide-out meat pan
4. Butter storage compar~rnent
5. Portable egg tray
6. Freezer door juice-can shelf
7. F.asy-ReieaseTM i ce trays and
smrage bucket
8. Temperature controls (both fresh
food and freezer]
9. Powersaver switch
10.
Roll-out wheels (behind grille)
11.\lodel und serial number
12.Defrost water pan (behind grille)
LA-mm
nch clearance at both sides and a
e o!'installation. When building :
consider providing water supply tc
reftigeratc)r location. It will simplify connec-
tion of optional automatic icemaker should
you tvishto install one at a later date.
Your
refrigerator should not be installed where
the :cmperature will go below 60°F, because
the refrigerator will not run frequently enough
to m.lintain proper temperatures.
Be sure
to install on a floor strong enough to
supp)rt a fully loaciedrefrigerator.
Adi:sting screws for raising or lowering rollers
are Lwted behind the grille. Set these screws
so Ike refrigerator is firmly positioned on the
flot~:and t/ze
fiotlt
i.s raised
just enough that
[he d,mrs close easily when opened about half-
wa~.,Removcthe grille by grasping at bottom
anj ~ullingup and out. (See Fig. 1).
,
1
1
1
,
.
""...
,.;;-tII-:;adjus[ing screws c~ockwise to raise the
– '.~!~:erator, c~>Llll[erc]~Jck\vise to ]owcr. (See
c
.:+ . ._-+-F.
~,j >,
-;+----=-'. Use an adjustable wrench or pliers.
.=.-.,, , ,.
.: .=.<
-.,
Adjusting screw
Fig. 2
To replace grille, set tabs on hooksat both ends
and push top toward refrigerator until grille
snaps into place. (See Fig. 3).
ELECTRICAL
CONNECTION
IMPORTANT'
(PLEASE READ CAREFULLY)
FORPERSONAL S.4FETY,THMAPPLIANCE
MUST BE PROPERLYGROUNDED.
The power cord of this appliance is equipped
with a three-prong (grounding) plug which
mates with a standard three-prong (grobnding)
wall receptacle (Fig. 4) to minimize -the possi-
bility of electric shock hazard from this appli-
ance. The customer should have the wall
receptacle and circuit checked by a qualified
electrician
to make sure the receptacle
is
properly grounded.
Vhere a standard two-prong wall receptacle is
ncountered, it is Lhe personal responsibility
nd obligation of the customer to have it re-
lated with a properly grounded three-prong
M1lreceptacle.
1)0 NOT, IJNDER ANY CHRC!JMSTAPWE!3,
['UT
OR REMWE
'mm
THIRD {GROUND)
rRo!NG
FROM THE POWER 'CORD.
USAGE SITUATIONS WHERE APPLIANCE'S
POWER CORD WILL BE DISCONNECTED
~NFREQUEPdTLY
~MPORARY
METHOD
lAtMPTEfI p LuGsIWT\
F=z3
MM41TTED IN
CANADA)
ALIGN LARGE
Fig. 5
BEFORE USE
Because of potential safety hazards under cer-
tain conditions, we strongly recommend
against the use of an adapter plug. However, if
you still elect to use an adapter, where local
codes permit, a TEMPORARY CONNEC-
TION may be made to a properly grounded
two-prong wall receptacle by the use of a UL
listed adapter which is available at most local
hardware stores (Fig. 5), The larger slot in the
adapter must be aligned with the larger slot in
the wall receptacle to provide proper polarity
in the connection of the power cord.
CAUTION: Attaching the adapter ground ter-
minal to the wall receptacle cover screw does
not ground the appliance unless the cover
screw is metal. and not insulated, and the wall
receptacle
is grounded through the house
wiring. The customer should have the circuit
checked bya qua~ified electrician
to make
sure the receptacle is properly grounded.
When disconnecting the power cord from the
adapter, always hold the adapter with one
hand. If this is not done, the adapter ground
terminal is very likely to break with repeated
use. Should this happen, DO NOT USE the
appliance until a proper ground has again
been established.
USAGE SITUATIONS WHERE APPLIANCE'S
POWER CORD WiLL BE D!SCOINNECTED
FREQUENTLY
Do not use an adapter plug in these situations
because frequent disconnecting of the power
cord piaces undue strain on the adapter and
leads to eventual failure of the adapter ground
terminal. The customer should have the two-
prong wall recepi acie replaced with a tiwee-
prong (grounding) receptacle
by a qualified
electrician before using [he appliance.
The refrigerator should alwaysbe plugged into
its own individua] electrical outlet (115vol[,
60 hertz, single phase AC.)
.,' .,
