SERVICE MANUAL
VIDEO CASSETTE RECORDER
POWER REQUIREMENTS .................
POWER CONSUMPTION ...................
WEIGHT ..............................................
DIMENSIONS ......................................
OPERATING TEMPERATURE ...........
VIDEO RECORDING SYSTEM ..........
VIDEO SIGNAL SYSTEM ...................
VIDEO HEAD ......................................
USABLE CASSETTES ........................
CHANNEL COVERAGE ......................
RF OUTPUT ........................................
HORIZONTAL RESOLUTION ............
TIMER BACKUP .................................
TUNER SYSTEM ................................
TV SYSTEM ........................................
HV-GX950
HV-GX900
BASIC TAPE MECHANISM : OVD-6
SPECIFICATIONS
230 V AC, 50 Hz
TAPE SPEED ...................................
14W
3.5 kg (7.7 lbs.)
380 mm (W) x 267 mm (D) x
95 mm (H)
RECORDING/PLAYBACK TIME .....
(15 x 10 5/8 x 3 3/4 in.)
5°C to 40°C
Rotary 2 head helical scanning
system
PAL colour system, 625 lines,
VIDEO INPUT ...................................
50 fields
VIDEO OUTPUT ..............................
Azimuth 2 heads
VIDEO S/N .......................................
VHS video cassette
AUDIO INPUT ..................................
UHF: 21 to 69
AUDIO OUTPUT ..............................
UHF channels between 23 and
AUDIO TRACK .................................
69, 73 dBµ
FAST-FORWARD TIME ...................
240 lines
REWIND TIME .................................
30 minutes
Frequency synthesized tuner
I
•
S/M Code No. 09-975-331-5N1
Digitized in Heiloo, Holland
PAL
NTSC (playback only)
PAL
NTSC (playback only)
1.0 Vp-p, 75 ohm, unbalanced
1.0 Vp-p, 75 ohm, unbalanced
53 dB (nominal)
–3.8dBs, 50K ohm
–3.8dBs, less than 1 Kohm
1 track (Mono)
135 seconds with E-180 tape
108 seconds with E-180 tape
Design and specifications are subject to change without
notice.
18/1/2015
K
K
SP: 23.39 mm/sec
LP: 11.69 mm/sec
SP: 33.35 mm/sec
SP: 5 hours with E-300 tape
LP: 10 hours with E-300 tape
SP: 3 hours 30 minutes with
T-210 tape
