Sealey RS1224.V2 Instruction Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions and properly
maintained, give you years of trouble free performance.
IMPORTANT: BEFORE USING THIS PRODUCT, PLEASE READ THE INSTRUCTIONS CAREFULLY. MAKE CAREFUL NOTE OF SAFETY INSTRUCTIONS, WARNINGS
AND CAUTIONS. THIS PRODUCT SHOULD ONLY BE USED FOR ITS INTENDED PURPOSE. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY
AND WILL INVALIDATE THE WARRANTY. RETAIN THESE INSTRUCTIONS FOR FUTURE USE.
Read and understand the general safety and operating instructions before use. The following information is intended to help you keep
the product in top working order.
NOTE – The battery in this unit is a consumable item and its ability to accept charge will reduce over time. We will warranty it against
mechanical and electrical defect for a period of one year - this does not cover fair wear and tear.
If the battery is not properly charged before first use, or regularly conditioned, its capacity will diminish. Under these circumstances we will not
replace the battery even if it is less than one year old.
You can help prolong the lifecycle of the battery by following a few simple guidelines.
• Plug in your new Roadstart to the mains transformer and make an INITIAL charge lasting 38 hours.
• Ensure the unit is fully charged before storage.
• DO NOT leave the Roadstart for longer than 2 months without putting it on charge.
• DO NOT attempt to start a vehicle when the Roadstart battery voltage is reduced to less than 7Volts.
• DO NOT drop or roughly handle the Roadstart – this will break or disjoin the battery terminals rendering the battery useless and the
warranty void.
• DO NOT use any other charger, other than the one supplied, to recharge the battery.
1. GENERAL FEATURES
IMPORTANT: READ SAFETY INSTRUCTIONS BEFORE ATTEMPTING TO USE THE ROADSTART.
GENERAL FEATURES
Initial peak power 3200 amps at 12V and 1700 amps at 24V. More than enough to start most

vehicles. May also be used in DEEP CYCLE applications.
The Roadstart is also a portable power source for accessories equipped with a male cigarette

lighter plug. The DC outlet has automatic 12 amp overload protection.
Test switch and LED lights. Solid state circuitry.

SAFETY FEATURES
Safety storage holsters prevent accidental sparking of clamps.

The Roadstart contains the latest technology with its 12 volt sealed lead acid batteries.

This means the Roadstart may be stored in any position without fear of leakage.
The Roadstart incorporates an Advanced Warning System which sounds a buzzer in certain

undesirable connection conditions. See Section 5.1.
2. SPECIFICATIONS
Built-in batteries: Sealed lead acid, maintenance free, re-chargeable.
DC Output (volts):. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12/24
Peak Current (amps): . . . . . . . . . 12V:. . . . . . . . . . . . . . . . . . . 3200
. . . . . . . . . . . . . . . . . . . . . . . . . . 24V:. . . . . . . . . . . . . . . . . . . 1700
Cold Cranking Current (amps): . 12V:. . . . . . . . . . . . . . . . . . . 1200
. . . . . . . . . . . . . . . . . . . . . . . . . . 24V:. . . . . . . . . . . . . . . . . . . . 600
Charging Time: . . . . . . . . . . . . . . . .Up to 30 hours with AC charger
Breaker: . . . . . . . . . . . . . . . . . . . . . . . .12 amp (for DC power port)
Weight: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16.25kg
Dimensions (mm): . . . . . . . . . . . . . . . . . . . . . . . . . 345 x 400 x 180
3. SAFETY INSTRUCTIONS
 DANGER! - RISK OF EXPLOSIVE GASES.
WORKING IN THE VICINITY OF A LEAD-ACID BATTERY IS DANGEROUS. BATTERIES GENERATE EXPLOSIVE GASES DURING NORMAL OPERATION. FOR
THIS REASON, IT IS VERY IMPORTANT TO READ, AND FOLLOW THESE INSTRUCTIONS EXACTLY, EACH TIME YOU USE THE RS1224.V2.
IMPORTANT: To reduce risk of battery explosion, follow these instructions and those published by battery manufacturer and manufacturer of any
equipment you intend to use in vicinity of the battery. Remember to review warning marks on all products and on engines.
3.1. PERSONAL PRECAUTIONS
Ensure there is another person within hearing range of your voice, or close enough to come to your aid should a problem arise when

working near a lead-acid battery.
Have fresh water and soap nearby in case battery acid contacts skin, clothing or eyes.

Wear safety eye protection and protective clothing. Avoid touching eyes while working near battery.

Wash immediately with soap and water if battery acid contacts skin or clothing. If acid enters eye, flush eye immediately with cool, clean

running water for at least 15 minutes and seek immediate medical attention.
Remove personal metallic items such as rings, bracelets, necklaces and watches. A lead-acid battery can produce a short-circuit current

high enough to weld a ring or the like to metal, which may cause severe burns.
3.2. OTHER IMPORTANT SAFETY INSTRUCTIONS
Familiarise yourself with the application, limitations and potential hazards of the unit.

Keep the unit in good working order and condition. Take immediate action to repair or replace damaged parts.

Only use recommended attachments and parts. To use unapproved items may be dangerous and will invalidate your warranty.

The Roadstart must only be opened and checked by qualified service personnel. DO NOT disassemble for any reason.

IMPORTANT WARRANTY INFORMATION: KEEP YOUR ROADSTART HEALTHY
INSTRUCTION MANUAL FOR:
PORTABLE ROADSTART UNIT
MODEL NO:
Original Language Version
RS1224.V2
RS1224.V2
(12V/24V)
Issue: 5 - 23/12/11
