Audio Subwoofer : 1.15 Vrms
(> 1 kohm)
Audio Rear L + R: 2 Vrms (> 1 kohm)
Digital output: 0.5 Vp-p (75 ohm)
Optical, Coaxial
HDMI output
Sampling frequency:
MP3: 32 kHz, 44.1 kHz, 48 kHz
WMA: 44.1 kHz, 48 kHz
Constant bit rate:
MP3: 112 kbps - 320 kpbs
WMA: 48 kpbs - 192 kpbs
USB
Compatibility: Hi-Speed USB (2.0)
Class support: USB Mass Storage Class
File system: FAT16, FAT32
USB port: 5V
, 500mA (for each port)
Support HDD (a portable hard disc drive):
an external power source may be needed.
Main unit
Power supply rating: 110-240V~, 50/60 Hz
Power consumption: 20 W
Power consumption in standby mode (fast
wakeup disabled): < 0.15 W
Dimensions (w x h x d):
435 x 42 x 230 (mm)
Net Weight: 1.51 kg
Accessories supplied
Remote control and batteries
AC power cable
User manual
Laser Specification
Laser Type (Diode): AlGaInN (BD), AlGaInP
(DVD/CD)
Wave length: 405+7nm/-7nm (BD),
660+10nm/-10nm (DVD), 785+10/-10nm (CD)
Output power: 1mW (BD), 0.26mW
(DVD), 0.3mW (CD)

6 Troubleshooting

Note
For identification and supply ratings, see the type plate
at the back or bottom of the product.
Before you make or change any connections, make sure
that all devices are disconnected from the power outlet.
Warning
Risk of electric shock. Never remove the casing of the
player.
To keep the warranty valid, never try to repair
the player yourself.
If you have problems using this player, check the
following points before you request service. If
you still have a problem, register your player and
get support at www.philips.com/support.
If you contact Philips, you will be asked for the
model and serial number of this player. The
model number and serial number are on the
back of this player. Write the numbers here:
Model No. __________________________
Serial No. ___________________________
Main unit
The buttons on this player do not work.
Disconnect this player from the power
supply for a few minutes, and then
reconnect.
No picture.
Make sure that the TV is switched to the
correct source input for this player.
For the composite connection (via the
VIDEO connector) to the TV, on this player
select a video resolution of 480i/576i or
480p/576p to enable video output (press
, and select [Setup] > [Video] > [HDMI
video]) .
EN
23
