Orbea alma Technical Manual
Hide thumbs
Also See for alma:
- Instruction and maintenance manual (196 pages) ,
- Technical manual (19 pages)
Related Manuals for Orbea alma
Summary of Contents for Orbea alma
- Page 1 TECHNICAL SPECIFICATIONS BLUE PAPERS ALMA TECHNICAL MANUAL...
-
Page 2: Table Of Contents
TECHNICAL SPECIFICATIONS CONTENT GEOMETRY AND SPECIFICATIONS FRAME MATERIAL AND CARE PARTS AND HARDWARE ADDITIONAL INFORMATION TORQUE SPECIFICATIONS ORBEA WARRANTY ADDITIONAL INFORMATION... -
Page 3: Geometry And Specifications
TECHNICAL SPECIFICATIONS GEOMETRY AND SPECIFICATIONS 27” 29” SIZES (mm) 16"/S 17,5"/M 17,5”/M 19"/L 21"/XL 1. Seat tube 2. Top tube (EFF) 583 mm 3. Head tube 4. Chain stay 5. BB height 6. BB offset 7. Wheelbase 1038 1070 1084 1106 1132 8. - Page 4 TECHNICAL SPECIFICATIONS GEOMETRY AND SPECIFICATIONS TECH SIZES 27” 29” FORK 100 mm tapered SIZE (mm) 16"/S 17,5"/M 17,5”/M 19"/L 21"/XL HEADSET Integrated. Same as Occam or Oiz Crank SEATPOST 27,2 mm Stem SEATCLAMP 33 mm, not standard Handlebar FRONT DERAILEUR 35 mm Shimano pressfit 92 mm REAR WHEEL AXLE...
-
Page 5: Frame Material And Care
Orbea frames are carefully designed to be durable, tires. Check and adjust tire pressure. WHEELS Spin efficient, and easy to maintain. Alma tubes are sti- the wheels and look for wobbles, check for loose or ff and light, giving excellent steering precision and broken spokes. -
Page 6: Parts And Hardware
TECHNICAL SPECIFICATIONS PARTS & HARDWARE 1. SEAT CLAMP Cod: 16100235 3. HANGER Cod: 16100237 Number Name/Description Number Name/Description ABRAZADERA SILLIN ALMA 14 NEG HANGER 2. SEAT CLAMP Cod: 16100236 Number Name/Description ABRAZADERA SILLIN ALMA 14 TITA... - Page 7 TECHNICAL SPECIFICATIONS 4. CHAINSTAY PROTECTOR Cod: 11000273 5. REAR BRAKE HOSE GUIDE Cod: 16100238 Number Name/Description Number Name/Description Chainstay protector Rear brake hose guide...
- Page 8 TECHNICAL SPECIFICATIONS Cod: 12301062 7. BOTTLE CAGE SPACER Cod: 16100239 Number Name/Description Number Name/Description M5 / Ti M5 Bottle cage spacer...
- Page 9 TECHNICAL SPECIFICATIONS 8. INTEGRATED CABLE GUIDE Cod: 11001174 Number Name/Description M5 integrated plastic cable guide...
- Page 10 PARTS & HARDWARE / CABLE ROUTING * This frame is designed to work only with Orbea DCR´s full liner system. Using the frame without these liners will result in irreversible frame damage that will not be covered by the warranty.
- Page 11 Number Name/Description Number Name/Description Tapon Di2 Alma con agujero Tapon Di2 Avant Tapon Di2 Alma sin agujero * This frame can be made compatible with Fox ICD and Shimano Di2 shifting systems, to do so please get in contact a Orbea dealer.
- Page 12 TECHNICAL SPECIFICATIONS Cod: 11001123 Number Name/Description Number Name/Description Tapon Di2 Alma sin agujero Tapon shim Di2 (D6) Tapon Di2 Alma con agujero...
- Page 13 TECHNICAL SPECIFICATIONS PARTS & HARDWARE / ELECTRONIC ROUTING (iCD) CABLE GUIDE Cod: 11001174...
-
Page 14: Additional Information
TECHNICAL SPECIFICATIONS PARTS & HARDWARE / Electronic System... -
Page 15: Torque Specifications
TECHNICAL SPECIFICATIONS TORQUE SPECS ALMA TORQUE SPECIFICATIONS Fastener Required tools Torque Note 4 mm hex 5 Nm 4 mm hex 3 Nm Minimum bolt insertion 5 mm hex 10 Nm 8 mm 3 mm hex 4 Nm CHECKING AND ADJUSTING TORQUE... -
Page 16: Orbea Warranty
2-year warranty. We warrant Orbea’s lifetime warranty is activated using the regis- 8) In case of crashes, the Orbea warranty shall be con- each frame and fork in our bikes against paint or var- tration number you will find on all frames from the sidered null and void. -
Page 17: Additional Information
FACEBOOK www.facebook.com/OrbeaBicycles TWITTER https://twitter.com/Orbea/ TECH VIDEOS Visit our Orbea Channel on YouTube for a variety of helpful setup and tech videos: http://www.youtube.com/user/OrbeaBicycles/ YOUR ORBEA DEALER INSTAGRAM Our dealers are experts and should be able to assist you with setting up and maintaining your Orbea bicy- instagram.com/orbeabicycles... - Page 18 TECHNICAL SPECIFICATIONS BLUE PAPERS ALMA TECHNICAL MANUAL...
