Galaxian Move™
1. The Galaxian Move™ is a eight DMX channel DMX fixture. See
pages 16-17 for detailed description of the DMX values and traits.
2. To control your fixture in DMX mode, follow the set-up procedures
on pages 6-8 as well as the set-up specifications that are includ-
ed with your DMX controller.
3. Use the controller's faders to control the various DMX fixture traits.
4. This will allow you to create your own programs.
5. Follow the instruction on page 10 to set the DMX address.
6. For longer cable runs (more than a 100 feet) use a terminator on
the last fixture.
7. For help operating in DMX mode consult the manual included
with your DMX controller.
Sound Active Mode:
This mode allows either single unit or several
units linked together, to run to the beat of the music.
1. Tap the MENU button until
ENTER.
2.
Tap the UP or DOWN buttonS until you find your desired show,
and press ENTER.
3. The optional UC3 Controller (not included) may be used to con-
trol different functions including blackout.
Show Mode:
This mode allows either a single unit or several units
linked together, to run one of four shows that you choose.
1. Tap the MENU button until
ENTER.
2.
Tap the UP or DOWN buttons until you find your desired show,
and press ENTER.
Galaxian Move™
Stand By Blackout the unit
Function 1. Strobe Red
2. Strobe Green
3. Strobe in Green/Red
Mode Sound (LED OFF)
American DJ - www.americandj.com - Galaxian Move Instruction Manual Page 15
© ®
Operation
"SOUN" is displayed, and press
"SHND" is displayed, and press
UC3 Control
Show Rotation
1-4
LED Blinking LED ON
Galaxian Move™
Channel
1
2
3
4
5
6
7
Speed
American DJ
©
Value
0 - 255
0 - 255
0 - 7
8 - 15
16 - 239 SLOW - FAST
240 - 247 SOUND ACTIVE
248 - 255
GREEN LASER
0 - 7
8 - 15
16 - 239 SLOW - FAST
240 - 247 SOUND ACTIVE
248 - 255
LASER ROTATION
0 - 9
10 - 120 COUNTER - CLOCKWISE FAST - SLOW
121 - 134
135 - 245 CLOCKWISE SLOW - FAST
246 - 255
0 - 7 NO FUNCTION
8 - 49 RED COUNTER - CLOCKWISE
50 - 91 RED CLOCKWISE
92 - 133 GREEN COUNTER - CLOCKWISE
134 - 175 GREEN CLOCKWISE
176 - 217 RED & GREEN COUNTER - CLOCKWISE
218 -255 RED & GREEN CLOCKWISE
MOVEMENT
0 - 7 NO FUNCTION
8 - 28 MOVEMENT 1
29 - 49 MOVEMENT 2
50 - 70 MOVEMENT 3
71 - 91 MOVEMENT 4
- www.americandj.com - Galaxian Move Instruction Manual Page 16
®
DMX Traits
Function
PAN
TILT
RED LASER
OFF
ON/OPEN
ON/OPEN
OFF
ON/OPEN
ON/OPEN
LASER OFF
LASER OFF
LASER OFF
MACROS
