3.12 COMBUSTION SETTINGS.

Supply pressure
Burner nozzle
Flue flow rate at max heat output
Flue flow rate at min heat output
CO at Q. Nom./Min.
2
CO at 0% di O at Q. Nom./Min.
2
NOX at 0% of O2 at Nom.Q./Min.
Flue temperature at nominal output
Flue temperature at minimum output
Gas rate at maximum heat output
Gas rate at maximum heat output
9
10
15
16
13
14
View B
12
11
View A
15
15
Natural Gas
mbar 20
mm N/A
kg/h 52
kg/h 12
% 9.40 / 8.90
ppm 206 / 9
ppm 83 / 43
°C 73
°C 64
m³/h 3.49
kg/h N/A
25
View C
16
Fig. 3-5
Propane
37
6.00
53
12
10.50 / 10.30
190 / 8
99 / 54
74
66
N/A
2.57
Alpha Intec 50CS
