WALK THE CUSTOMER THROUGH EACH OF
THE FOLLOWING KEY DELIVERY FEATURES
CLOCK – page 10
- Demonstrate how to set clock (including daylight savings
setting for Navigation equipped vehicles)
BLUETOOTH – page 18, 22-23
- Show phone compatibility website:
www.hyundaiusa.com/bluetooth
- Make a test call using Bluetooth with the customer's
phone.
- Demonstrate Voice Recognition (VR).
BLUE LINK – pages 20-21
- Assist with creating MyHyundai.com account
- Assist with Blue Link enrollment
Show Blue Link Users Manual & tear out Voice
Commands/Quick Tip Card
- Encourage customers to press the Blue link button
CLIMATE CONTROL
-
page 16 – 17
- How to Operate Defrost
- AQS (Air Quality System)
- 3 Zone control Button
WINDSHEILD WIPER/WASHER – page 08
- To activate wipers move the switch
down to one of the three positions
(AUTO, LO, HI)
- To adjust "AUTO" speed move
control knob.
- To spray washer fluid pull lever
toward you
- Push lever up for a single wiper pass
PARKING ASSIST SYSTEM
-
page 32
- Demonstrate how to turn system PAS ON/OFF
- The system turns on automatically when you move the
shift lever to R.
- The system will turn off automatically after vehicle speed
exceeds 11mph.
MAINTENANCE
Scheduled Maintenance
Engine Oil & Filter*
Tire Rotation
Air Cleaner Filter
Vacuum Hose
Climate Control Air Filter
(For Evaporator and Blower Unit)
Air Conditioning Refrigerant
Brake Hoses & Lines
Drive Shafts & Boots
Electronic Throttle Control
Exhaust Pipe & Muffler
Front Disc Brake/Pads, Calipers & Rotors
Propeller Shaft
Steering Gear Box, Linkage & Boots,
Lower Arm Ball Joint, Upper Arm Ball Joint
Suspension Mounting Bolts
Brake Fluid
Fuel Filter
Fuel Lines, Fuel Hoses & Connections
Fuel Tank Air Filter
Rear Disc Brake/Pads, Parking Brake
Vapor Hose, Fuel Tank & Fuel Filler Cap
Valve Clearance
Drive Belts (Alt, A/C)
Spark Plugs (Iridium Coated)
Faster
Coolant
Automatic Transaxle Fluid
*Check the engine oil regularly between recommended oil change. Hyundai recommends Quaker State oil.
*See Owner's Manual for details.
Looking for more detailed information?
Manual. If you require additional information or are unsure of a specific item, you should always refer to the
Slower
vehicle's Owner's Manual or contact your authorized Hyundai dealer.
The information contained in this Quick Reference Guide was correct at the time of printing; however,
specifications and equipment can change without notice. No warranty or guarantee is being extended in this
Quick Reference Guide, and Hyundai reserves the right to change product specifications and equipment at any
time without incurring obligations. Some vehicles are shown with optional equipment. Specifications apply to
U.S. vehicles only. Please contact your Hyundai dealer for current vehicle specifications.
Normal Usage
Severe Usage*
Replace
7,500 or 12 mos.
Replace
3,750 or 6 mos.
Perform
7,500
Perform
7,500
Inspect
7,500
Replace
More Frequently
Replace
30,000
Inspect
7,500
Inspect
Same As Normal
Replace
15,000
Replace
More Frequently
Inspect
15,000
Inspect
Same As Normal
Inspect
15,000
Inspect
Same As Normal
Inspect
15,000
Inspect
7,500
Inspect
15,000
Inspect
Same As Normal
Inspect
15,000
Inspect
Same As Normal
Inspect
15,000
Inspect
More Frequently
Inspect
15,000
Inspect
7,500 or 6 mos.
Inspect
15,000
Inspect
More Frequently
Inspect
15,000
Inspect
Same As Normal
Inspect
30,000
Inspect
Same As Normal
Inspect
30,000
Inspect
Same As Normal
Inspect
30,000
Inspect
Same As Normal
Inspect
30,000
Inspect
Same As Normal
Inspect
30,000
Inspect
More Frequently
Inspect
30,000
Inspect
Same As Normal
Inspect
60,000
Inspect
Same As Normal
1st 60,000 or 48 mos.
Inspect
Addl. Inspect 15,000
Inspect
Same As Normal
or 12 mos.
Replace
105,000
Replace
More Frequently
1st Replace 120,000 mos.
Replace
Same As Normal
Addl. Replace 30,000 or 24 mos.
No check, No service required
Replace
60,000
This Quick Reference Guide does not replace your vehicle's Owner's
NP150-N2016
(Rev 05/06/15)
Printing 05/09/15
EQUUS
HYUNDAI
Quick Reference Guide
www.hyundai.com
Roadside Assistance:
Consumer Affairs:
SiriusXM
Blue Link:
1-800-243-7766
1-800-633-5151
1-800-967-2346
®
Radio:
1-855-2BLUELINK
(1-855-225-8354)
