    SERVICE MANUAL LCD TV Model No. LEA-22H03P MT8222 Chassis WARNING This service information is designed for experienced repair technicians only and is not designed for use by the general public. It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.

  • Page 3: Table Of Contents

    Service Manual Model No.:LEA-22H03P CONTENTS Chapter 1.General Information 1-1. Document Information ................3 1-2. General Guidelines ................3 1-3. Important Notice ..................3 1-3-1. Follow the regulations and warnings ............. 3 1-3-2. Be careful to the electrical shock ............3 1-3-3.
  • Page 4 Service Manual Model No.:LEA-22H03P Chapter 5. External Equipment Connections 5-1. Antenna Connection ................17 5-2. VCR Connection ................... 18 5-3. DVD Connection ................... 18 5-4. HDMI or DVI Connection ..............18 5-5. PC Connection ..................19 5-6. Monitor Out Connection ..............

  • Page 5: Chapter 1.General Information

    Service Manual Model No.:LEA-22H03P Chapter 1.General Information 1-1. Document Information Document format: Adobe PDF Author: Compiler: 1-2. General Guidelines When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or damaged by the short circuit.

  • Page 6: About Lead Free Solder (Pbf)

    Service Manual Model No.:LEA-22H03P Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Electrostatically Sensitive (ES) Devices. The following techniques should be used to help reduce the incidence of component damage caused by electros static discharge (ESD).
  • Page 7 Service Manual Model No.:LEA-22H03P 1. Always unplug the receiver AC power cord from the AC power source before: a. Removing or reinstalling any component, circuit board module or any other receiver assembly. b. Disconnecting or reconnecting any receiver electrical plug or other electrical connection.

  • Page 8: Ordering Spare Parts

    Service Manual Model No.:LEA-22H03P 12. Use only a grounded-tip soldering iron to solder or unsolder ES devices. 13. Use only an anti-static type solder removal device. Some solder removal devices not classified as "anti-static" can generate electrical charges sufficient to damage ES devices.

  • Page 9: How To Read This Service Manual

    Service Manual Model No.:LEA-22H03P 1-4. How to Read this Service Manual 1-4-1. Using icons: Icons are used to attract the attention of the reader to specific information. The meaning of each icon is described in the table below: Note: A “note” provides information that is not indispensable, but may nevertheless be valuable to the reader, such as tips and tricks.

  • Page 10: Chapter 2. Specification

    Service Manual Model No.:LEA-22H03P Chapter 2. Specification 2-1. Specification list Model LE22T3 22 inches Screen Size Aspect Ratio 16:9 Resolution 1920*1080 Response Time (ms) Angel of View H:170/V:160 Color Display 16.7M No. of Preset Channels OSD Language English Russian Color System...

  • Page 11: External Pictures (Four Faces)

    Service Manual Model No.:LEA-22H03P 2-2. External pictures (four faces) Front Side Left Side...
  • Page 12 Service Manual Model No.: Right Side Back Side...

  • Page 13: Chapter 3. Disassemble And Assemble

    Service Manual Model No.: Chapter 3. Disassemble and Assemble 3-1. Remove the Stand 1. Remove the 2 and 3 screws indicated in picture 1. 1. Lay down the unit so that back cover faces 2.Uncover the equipment, the FFC wire and upward.

  • Page 14: Remove The Mainboard And The Driver Board

    Service Manual Model No.: 3-3. Remove the Main Board & Small Board There are four boards in the machine: A:Remote Control Board;B:Main Board;C:LED Driver Board ;D:Keypad Board (See picture 5). picture 7 3-3-3. Remove the Keypad Board There's no screw in this board,pull the keypad board out from Front Cabinet directly.

  • Page 15: Chapter 4. Location Of Controls And Components

    Service Manual Model No.: Chapter 4. Location of Controls and Components 4-1. Board Location Parts number Description A Borad 0090720951B Remote Control Board B Borad Main Board DZ0XG0E0A00 C Borad 0090724838 LED Driver Board D Borad 0090722685 Keypad Board 4-2. Main Board...

  • Page 16: Function Description

    Service Manual Model No.: 4-2-1. Function Description: Main Board Process signal which incept from exterior equipment then translate into signal that panel can display. 4-2-2. Connector definition Main board connector CNE1 CNE2 CND3 Pin number Signal name Pin number Signal name Pin number Signal name RXO0-...

  • Page 17: Driver Board

    Service Manual Model No.: 4-3. Driver Board Connector definition: Signal name PS_ON ON/OFF +12V +12V Function description:To supply power for Panel. 4-4. Remote Control Board Connector definition: Signal name GREEN Function description:receive remote control signal 4-5. LED Panel Connector definition: see next page Function description:Display program...
  • Page 18 Service Manual Model No.: Pin number Signal name Description RXO0- minus signal of odd channel 0(LVDS) RXO0+ plus signal of odd channel 0(LVDS) RXO1- minus signal of odd channel 1(LVDS) RXO1+ plus signal of odd channel 1(LVDS) RXO2- minus signal of odd channel 2(LVDS) RXO2+ plus signal of odd channel 2(LVDS) RXOC-...

  • Page 19: Chapter 5. External Equipment Connections

    Service Manual Model No.: Chapter 5. External Equipment Connections 5-1. Antenna Connection Antenna or Cable Service without a Cable Box Connections. For optimum picture quality, adjust antenna direction if needed. Note: * It is recommended that you'd better use 75Ω coaxial cable to remove the disturbance caused by airwave.

  • Page 20: Vcr Connection

    Service Manual Model No.: 5-2. VCR Connection Connect the DVD video outputs (Y, P ) to the COMPONENT (Y, P ) input jacks on the TV and connect the DVD audio To avoid picture noise (interference), leave an outputs to the AUDIO jacks on the TV’ as adequate distance between the VCR and TV.

  • Page 21: Pc Connection

    Service Manual Model No.: How to use: pattern, contrast or brightness in PC mode. If noise is present, change the PC mode to Turn on the digital set-top box. another resolution,change the refresh rate (Refer to the owner’s manual for the digital set-top to another rate or adjust the brightness and box.) contrast on the menu until the picture is clear.

  • Page 22: Headphones Connection

    Service Manual Model No.: 3.If you cause a static discharge when touching the unit and the unit fails to function, simply unplug the unit from the AC outlet and plug it back in. The unit should return to normal operation. Polarized AC Cord Plug. 5-9.Recommendation input Format Recommendation HDTV/SDTV(YPbPr/ 5-7.Headphones Connection...

  • Page 23: Chapter 6. Operation Instructions

    Service Manual Model No.: Chapter 6. Operation Instructions 6-1. Front Panel Controls 1. TV/AV :All input source display and OK confirm. 2. CH(+/-) :Program minus and plus, menu options 3. VOL(+/-) :Volume increase and decrease, menu set and entry 4. MENU :Menu display 5.
  • Page 25 CNA4 CNA4 GPIO_5 GPIO_5 3 GPIO_4 NC/10R NC/10R GPIO_5 GPIO_4 3 +3V3 +5V_DVD R0402/SMD R0402/SMD C1172 C1172 R2790 R2790 DC12V +12V +3V3 R600100K R600100K C404 C404 3.3nF 3.3nF 2.2K 2.2K +3V3 3,4,6,7,11,13 0.1uF 0.1uF DV50 U826 U826 +12V C1171 10nF C1171 10nF C0402/SMD C0402/SMD...
  • Page 26 CVBS input R2424 R2424 NS/100 NS/100 CVBS2 CVBS2 System I2C 1,2,4,5,6,7,8,9,10,11,12,13,14 OSCL0 OSCL0 6,7,10 OSDA0 OSDA0 6,7,10 U0RX U0RX U0TX U0TX VGA input LQFP256/SMD/8222/HAIER LQFP256/SMD/8222/HAIER GPIO_1 GPIO_1 9 REDP REDP CVBS_SY0 VGAGND CVBS_SY0 9 CVBS_SC0 VGAGND ORESET# CVBS_SC0 9 EPAD_GND VGASOG ORESET# OIRI...
  • Page 27 DV10 ( Bypass CAPs arround MT8222 ) DV10 DV10 +3V3 +3V3 +3V3 2,3,6,7,11,13 DV10 DV33 DV33 DV33 AV33_SIFDIG AV12 C886 C886 AV33_SIFDIG C902 C902 C889 C889 C890 C890 C891 C891 C893 C893 C894 C894 AV12 C887 C887 AV33_SIFDIG 2,3,6,7,11,13 4.7uF/10V 4.7uF/10V AV12 0.1uF...
  • Page 28 MEM_DQ0 RDQ0 MEM_DQ1 RDQ1 MEM_DQ2 RDQ2 MEM_DQ3 RDQ3 MEM_DQ6 MEM_RA0 MEM_DQ2 MEM_RA1 MEM_DQ4 MEM_RA2 MEM_DQ4 RDQ4 MEM_DQ0 MEM_RA3 MEM_DQ5 RDQ5 MEM_DQ1 MEM_RA4 MEM_DQ6 RDQ6 MEM_DQ7 MEM_RA5 MEM_DQ7 RDQ7 MEM_DQ3 MEM_RA6 MEM_DQ5 MEM_RA7 MEM_DQ13 MEM_RA8 MEM_DQ10 MEM_RA9 MEM_DQS0 RDQS0 MEM_DQ15 MEM_RA10 MEM_DQM0 RDQM0 DQ10...
  • Page 29 1st UART IF +3V3_ON +5V_ON System E2PROM System Reset# +3V3 ( For Code PWM2 +3V3 PWM2 +3V3_ON +3V3 ORESET# download and ORESET# Debug ) CE37 CE37 OIRI OIRI 4.7K 4.7K 4.7K 4.7K 4.7K 4.7K 220uF/16V 220uF/16V ORESET# R0402/SMD R0402/SMD R0402/SMD R0402/SMD CNB2 CNB2...
  • Page 30 HDMI port 1 RX1_2 RX1_2 RX1_2B RX1_2B RX1_1 HDMI TYPE-A HDMI TYPE-A RX1_1 RX1_1B JAE\DC1R019WDH JAE\DC1R019WDH RX1_1B RX1_0 D286 D286 NC/EZJZ0V800AA NC/EZJZ0V800AA RX1_0 RX1_2 RX1_0B RX1_2 RX1_0B +5V_ON RX1_C D287 D287 NC/EZJZ0V800AA NC/EZJZ0V800AA RX1_C RX1_2B RX1_CB RX1_2B RX1_CB RX1_1 D288 D288 NC/EZJZ0V800AA NC/EZJZ0V800AA...
  • Page 31 VGA IN NEAR CONNECTOR NEAR IC D-SUB15 FEMALE VERTICAL D-SUB15 FEMALE VERTICAL VGA/HAIER VGA/HAIER +5V_ON FB27 FB27 FB-0603-120-2A FB-0603-120-2A R133 R133 +5V_ON RED_GND RED+ 10nF 10nF REDP BAT54C BAT54C +5V_ON SOT23/SMD SOT23/SMD +5V_ON 2,6,7 GRN_GND VGASDA_IN GREEN TP151 TP151 VGASOG R132 R132 VGASOG 3...
  • Page 32 NEAR CONNECTOR NEAR IC SY1_IN R2726 R2726 NC/100 NC/100 C1092 C1092 NC/47nF NC/47nF CVBS_SY0 CNC4 CNC4 TX41 TX41 NC/10R NC/10R GPIO_1 SC1_IN C1094 C1094 R2725 R2725 TX42 TX42 NC/47pF NC/47pF SY1_IN D249 D249 NC/75 NC/75 TX43 TX43 NC/EZJZ0V800AA NC/EZJZ0V800AA TX44 TX44 TX46 TX46...
  • Page 33 +5V_TUNER TUNER TUNER +5V_TUNER +5V_TUNER 2,14 IF_TUNER +5V_TUNER 1,2,3,4,5,6,7,8,9,11,12,13,14 R2660 R2660 CVBS0P CVBS0P 3,14 CVBS0N CVBS0N TDQ-6ID_GW115HRA TDQ-6ID_GW115HRA MPX2_P +5V_TUNER MPX2_P MPX2_N I2C ADDRESS: MPX2_N OSCL0 OSCL0 3,6,7 OSDA0 READ is 0X87 R2665 R2665 OSDA0 3,6,7 WRITE is 0X86 R47 0/NC R47 0/NC TUNER_CVBS R0402/SMD...
  • Page 34 ASPDIF ASPDIF +3V3_ON CN18 CN18 C1181 C1181 R2846 R2846 +3V3 +3V3 2,3,4,6,7,13 AUL_OUT COAXIAL COAXIAL C031 C031 100nF 100nF R026 R026 ASPDIF 2.2uF 2.2uF D281 D281 C0402/SMD C0402/SMD R0402/SMD R0402/SMD 470R 470R 2,6,7,13 C627 C627 COAXIAL/H COAXIAL/H R028 R028 +12V C032 C032 NS/2.2nF...
  • Page 35 CHANGE NET OF HPDET TO MUTE,FOR POWER OFF POP NOIESE +12V R2782 R2782 CE904 CE904 R0402/SMD R0402/SMD D254 1N4148 D254 1N4148 220uF/16V 220uF/16V 1N4148/SMD 1N4148/SMD R2784 R2784 CAP6.3-2.5MM CAP6.3-2.5MM Q1837 Q1837 R0402/SMD R0402/SMD 2N3906 2N3906 +12V SOT23/SMD SOT23/SMD 2009/11/12 R2786 R2786 D255 D255...
  • Page 36 GPIO_11 GPIO_11 OCKN OCKN OCKP +3V3 OCKP LVDS OUT +3V3 +3V3 2,3,4,6,7,11 +12V BEAD/SMD/1206 BEAD/SMD/1206 2,6,7,11 NC/FB-1206-120-3A NC/FB-1206-120-3A DV50 L213 L213 SOT23/SMD SOT23/SMD +12V AO3401 AO3401 LVDSVDD Q1844 Q1844 +12V L214 L214 +12V 2,12 CE883 CE883 BEAD/SMD/1206 BEAD/SMD/1206 FB-1206-120-3A FB-1206-120-3A 47uF/16V 47uF/16V 1,2,3,4,5,6,7,8,9,10,11,12,14...
  • Page 37 CVBS2 NEAR CONNECTOR Near swtich CVBS2 1,2,3,4,5,6,7,8,9,10,11,12,13 AV_IN 47nF 47nF CVBS2 AV_IN_OUT AVSV2R_IN AVSV2R_IN NC/EZJZ0V800AA NC/EZJZ0V800AA 47pF 47pF AVSV2L_IN AVSV2L_IN AUR_OUT AVSV2R_IN AUL_OUT AVSV2L_IN AV_OUT AV_IN CVBS_BYPASS CVBS_BYPASS 3 CVBS0P CVBS0P RCA3X1 RCA3X1 AUL_OUT AUL_OUT RCA3X1 RCA3X1 RCA3/HAIER RCA3/HAIER RCA3/HAIER RCA3/HAIER AUR_OUT AUR_OUT...

  • Page 38: Chapter 8. Measurements And Adjustments

    Service Manual Model No.: Chapter 8. Measurements and Adjustments 8-1. Service Mode 8-1-1.How to enter into Service Mode The way to the factory mode menu: Step 1: Press Menu, Step 2: Input 8893, Step 3: Press “OK” System will be into the factory mode menu when 3 steps above are done. 8-1-2.How to exit If you want to exit this factory menu, please press the button ”Exit”...

  • Page 39: Factory Menu 2

    Service Manual Model No.: 8-2-2. Factory Menu 2 Color Temperature Adjust the Color Temperature: standard,warm,cool;used when debugging R Gain/ G Gain/ B Gain/ R Offset/ G Color Temperature value in Current source Offset/ B Offset...

  • Page 40: Factory Menu 3

    Service Manual Model No.: 8-2-3.Factory Menu 3 Video Mode Video Mode in Current source,press to choose the source  Contrast/ Brightness/ Tint/ Color/ Value in Standard mode,corresponding OSD defaut value Sharpness Contrast Min/ Contrast Max/ Brightness Min/ Brightness Max/ Register adjust area Tint Min/ Tint Max/Color Min/Color Max/ Backlight Min/ Backlight Max 8-2-4.Factory Menu 4...

  • Page 41: Factory Menu 5

    Service Manual Model No.: 8-2-5.Factory Menu 5 Every source switch,you can choose each source by it.Press to choose On or Off  8-2-6.Factory Menu 6 Some function switch,such as language or power,you can choose it by press ...

  • Page 42: Chapter 9. Trouble Shooting

    Service Manual Model No.: Chapter 9. Trouble shooting 9-1. Simple check Verify if the television is properly plugged Verify if the television is properly supplied power No picture/ No sound Verify if electricity is available. Verify if correct signals are input Press INPUT button to change signal input to TV input Blank screen Restart the television of power supply is interrupted...

  • Page 43: Mainboard Failure Check

    Service Manual Model No.: 9-2. Mainboard Failure Check Phenomena: No Sound No Sound (All Mode) Fail Check the input Change Source input Source Pass Fail Check Re-soldering or change input/output IC U13 Of IC U13 of Main Pass Fail Check Re-soldering or change input/output IC U55...

  • Page 44: Pannel Failure

    Service Manual Model No.: 9-3. Pannel Failure Failure Mode...
  • Page 45 Service Manual Model No.:...
  • Page 46 Service Manual Model No.:...
  • Page 47 Service Manual Model No.:...
  • Page 48 Service Manual Model No.:...
  • Page 49 Specification LEA-22H03P No. in exploded Assembly parts number Location No. Parts Name in English Specification view 0090722685 Keypad Assembly 0094102800 Resistor RS-0603-1/10W-8.2kΩ-J-E 0094102800 Resistor RS-0603-1/10W-8.2kΩ-J-E 0094102803 Resistor RS-0603-1/10W-22kΩ-J-E Keypad Assembly 0094102803 Resistor RS-0603-1/10W-22kΩ-J-E 0094102959 Resistor ROHS-RS-0603-1/10W-2.7kΩ-J-E 0094000975 Touch Switch TC-1111...
  • Page 50 0094102841 R348 Resistor RS-0603-1/10W-510Ω-J-E 0094102960 R2665 Resistor RS-0603-1/10W-18kΩ-J-E 0094202608 CB443 Ceramic Disc Capacitor CT41-0603-Y5V-16V-0.68μF-Z-E 0094103062 Resistor RS-0603-1/10W-51Ω-J-E 0094202714 CE905 Aluminum Electrolytic Capacitor CD110X-16V-220UF-M-02-D-A 0094202714 CE117 Aluminum Electrolytic Capacitor CD110X-16V-220UF-M-02-D-A 0094202714 CE904 Aluminum Electrolytic Capacitor CD110X-16V-220UF-M-02-D-A 0094202714 CE227 Aluminum Electrolytic Capacitor CD110X-16V-220UF-M-02-D-A 0094202714 CE120...
  • Page 51 0094103316 R138 Resistor RS-0402-1/16W-100Ω-F-E 0094103316 R165 Resistor RS-0402-1/16W-100Ω-F-E 0094103316 R2827 Resistor RS-0402-1/16W-100Ω-F-E 0094103316 Resistor RS-0402-1/16W-100Ω-F-E 0094103316 Resistor RS-0402-1/16W-100Ω-F-E 0094103316 R2820 Resistor RS-0402-1/16W-100Ω-F-E 0094103316 R2828 Resistor RS-0402-1/16W-100Ω-F-E 0094103316 R151 Resistor RS-0402-1/16W-100Ω-F-E 0094103316 Resistor RS-0402-1/16W-100Ω-F-E 0094103316 R168 Resistor RS-0402-1/16W-100Ω-F-E 0094103316 Resistor RS-0402-1/16W-100Ω-F-E 0094103316 R164 Resistor...
  • Page 52 0094500059 Inductor Coil LCA2-0910-22μH-K-F05 0094300212 VGA Terminal 0094300215 Earphone Socket 0094300215 Earphone Socket 0094300218 AV Terminal rca-359h-00a-06 0094300216 AV Terminal rca-359h 0094300216 AV Terminal rca-359h 0094300217 Multiple Terminal rca-238h 0090100968 U34-ON Heatsink 25*25*6.0 0094102937 R958 Resistor ROHS-RS-0603-1/10W-470Ω-F-E 0094600120 Quartz-Crystal Oscillators 4MHz 0090100987 Heatsink...
  • Page 53 0094200123 C914 Ceramic Disc Capacitor CT41-0402-X7R-16V-0.1μF-K-E 0094200123 C948 Ceramic Disc Capacitor CT41-0402-X7R-16V-0.1μF-K-E 0094200123 C973 Ceramic Disc Capacitor CT41-0402-X7R-16V-0.1μF-K-E 0094200123 CB989 Ceramic Disc Capacitor CT41-0402-X7R-16V-0.1μF-K-E 0094200123 C646 Ceramic Disc Capacitor CT41-0402-X7R-16V-0.1μF-K-E 0094200123 C513 Ceramic Disc Capacitor CT41-0402-X7R-16V-0.1μF-K-E 0094200123 CB139 Ceramic Disc Capacitor CT41-0402-X7R-16V-0.1μF-K-E 0094200123 C414...
  • Page 54 0094200137 C1060 Ceramic Disc Capacitor CC41-0402-COG-50V-22pF-J-E 0094200137 C979 Ceramic Disc Capacitor CC41-0402-COG-50V-22pF-J-E 0094200137 C1071 Ceramic Disc Capacitor CC41-0402-COG-50V-22pF-J-E 0094200137 C1052 Ceramic Disc Capacitor CC41-0402-COG-50V-22pF-J-E 0094200137 C1070 Ceramic Disc Capacitor CC41-0402-COG-50V-22pF-J-E 0094200137 Ceramic Disc Capacitor CC41-0402-COG-50V-22pF-J-E 0094200138 Ceramic Disc Capacitor CC41-0402-COG-50V-47pF-J-E 0094200138 Ceramic Disc Capacitor CC41-0402-COG-50V-47pF-J-E...
  • Page 55 0094200161 Ceramic Disc Capacitor CT41-0402-X7R-50V-3300pF-K-E 0094200161 CD15 Ceramic Disc Capacitor CT41-0402-X7R-50V-3300pF-K-E 0094200161 C906 Ceramic Disc Capacitor CT41-0402-X7R-50V-3300pF-K-E 0094200161 CD14 Ceramic Disc Capacitor CT41-0402-X7R-50V-3300pF-K-E 0094200161 CD16 Ceramic Disc Capacitor CT41-0402-X7R-50V-3300pF-K-E 0094100281 R2846 Resistor RS-0402-1/16W-470Ω-J-E 0094100281 R2847 Resistor RS-0402-1/16W-470Ω-J-E 0094200177 CE835 Ceramic Disc Capacitor 10μF CT41-0805-X5R-10V-10uF-K-E 0094200177 CE13...
  • Page 56 0094100339 Resistor RS-0402-1/16W-75Ω-J-E 0094100339 Resistor RS-0402-1/16W-75Ω-J-E 0094100339 Resistor RS-0402-1/16W-75Ω-J-E 0094100339 R2660 Resistor RS-0402-1/16W-75Ω-J-E 0094100339 Resistor RS-0402-1/16W-75Ω-J-E 0094100339 R144 Resistor RS-0402-1/16W-75Ω-J-E 0094100334 R2616 Resistor RS-0402-1/16W-220kΩ-J-E 0094100334 R2672 Resistor RS-0402-1/16W-220kΩ-J-E 0094100341 R2763 Resistor RS-0402-1/16W-1kΩ-J-E 0094100341 R5208 Resistor RS-0402-1/16W-1kΩ-J-E 0094100341 R2756 Resistor RS-0402-1/16W-1kΩ-J-E 0094100341 R3007 Resistor...
  • Page 57 0094100344 R2430 Resistor RS-0402-1/16W-10kΩ-J-E 0094401674 ME9435/SOP8/MOS 0094401674 ME9435/SOP8/MOS 0094200195 C1176 Ceramic Disc Capacitor CT41-0402-X7R-50V-3900pF-K-E 0094500183 Bead Inductor BLM18PG121SN1 0094500183 FB54 Bead Inductor BLM18PG121SN1 0094500183 FB23 Bead Inductor BLM18PG121SN1 0094500183 FB22 Bead Inductor BLM18PG121SN1 0094500183 FB21 Bead Inductor BLM18PG121SN1 0094500183 FB26 Bead Inductor BLM18PG121SN1 0094500183...
  • Page 58 Schottky Barrier Diode MBRX180-SOD123FL(1A/80V) 0094200213 Aluminum Electrolytic Capacitor CD11C-63V-4.7uF-M-2.5-F 0094200213 Aluminum Electrolytic Capacitor CD11C-63V-4.7uF-M-2.5-F 0091802061B FR-4 220*220mm 0094300257 CNE1 Socket TJC2004-5AW 0090802531 Packaging Assembly BZMK-LE22T3-AKAI 0090502847D Plastic Bag 700*670mm 0.7/0.015 Packaging Assembly 0090509543 Styrofoam Pad EPE 250*100*300 LE22T3 0090509727 Cardboard Box...
