  • Page 1 Models: A5RT 90 BR A5RT 120 BR A5RT 150 BR A5RT 180 BR R410A Rooftop Packaged B Series A5RT - 2010...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. NOMENCLATURE ......................1 - PRODUCT LINE-UP 2. FEATURES ........................3 3. APPLICATION INFORMATION ..................5 - OPERATING RANGE - REFRIGERANT CIRCUIT DIAGRAMS - CONTROLLERS - INSTALLATION 4. SOUND DATA .......................22 5. SELECTION PROCESS....................25 - DRIVE PACKAGE - BLOWER CURVES 6.

  • Page 3: Nomenclature

    1. NOMENCLATURE Product Specification Variation Type Of Connection X : Not Applicable Electrical Characteristic F : 380-415V/3Ph/50Hz Model Type R : Heat pump Series B : B series Capacity 90 : 90,000 Btu/h Model Name RT :Rooftop Refrigerant 5 : R410A Brand A : Acson...

  • Page 4: Product Line-Up

    Product Line-up A5RT-BR Series Heat pump Classification 90BR FXAA 120BR FXAA A5RT 150BR FXAA 180BR FXAA Remarks: Economizers & CO sensor will be ready soon.

  • Page 5: Features

    2. FEATURES • Package Unit: Acson’s new range of rooftop packaged units has been developed specifically to suit commercial applications and are designed to be easy to install, requiring only ducting (and associated fittings), power/ control wiring and drain piping. Along with the light grey colour, the flat top and compact design gives an aesthetic and neat appearance when installed in line of sight. The unit cabinet is made of powder coated sheet metal especially suitable for outdoor use. All parts of the structure are fastened with corrosion resistant screws and bolts. • Base Beam: The base beams are fixed and provide a rigid foundation for the entire unit. The beam has the forklift slots and rigging holes for better handling purpose. It is also designed to allow mounting on a roof curb, the dimension of the roof curb should be followed strictly in accordance with the installation manual. • Flexible Air Supply: Since all the units utilize a belt/ pulley driven supply air fan, the units are able to meet a wide range of supply air volumes and external static pressures. Furthermore, the supply air fan motors, pulleys and belts (field supplied) can be easily changed on site to meet exact air flow and ESP requirement if required. • Convertible Return and Supply Air: Unit can be easily converted from horizontal to vertical (downward) supply and return air duct configuration by relocating the panels and supply air fan mounting. • Scroll Compressor: Units are equipped with high efficiency and reliable scroll compressors. Each compressor is mounted on rubber vibration isolators in order to reduce the noise level and vibration transmissions.
  • Page 6 • Evaporator Evaporator coils are manufactured from seamless inner grooved copper tubes mechanically bonded to aluminium fins to ensure optimum heat transfer. All coils are tested against by Nitrogen holding at 609psig and highly precise Helium leak test at 235psig. ALL standard coils are 3-4 rows / 14-16 FPI, 3/8”...

  • Page 7: Application Information

    3. APPLICATION INFORMATION Operating Range Ensure the operating temperature is in allowable range. Cooling Caution : Indoor WB Temperature (°C) The use of your air conditioner outside the range of working Heating temperature and humidity can result in serious failure. Indoor DB Temperature (°C)

  • Page 8: Refrigerant Circuit Diagrams

    Refrigerant Circuit Diagrams Model: A5RT90/120/150/180BR Item Part’s Model/Part No/Size Compressor Pressure Switch 600PSI N/C Access Valve Filter Drier Strainer Accumulator Pressure Switch 18PSI N/C Solenoid Valve Bypass Capillary Tube ID Coil OD Coil Check Valve Cooling Operation Compensator Heating Operation Note: (a) 120, 150, 180 consists of 2 circuits in the system. (b) Item 15 is applicable for 120 only...

  • Page 9: Controllers

    Controllers A. Operating Guide 1. Upon power up of the unit, the LCD displays the main display screen 2000/01/01 [Sat] 12:00am Status : OFF Mode : Heating Set Temp : 24°C ▼ 2. Press the ON/OFF button for 1 second to switch on the unit if the status shows OFF. The status will change to ON.
  • Page 10 B. Main Menu 1. Changes can be made to the factory setting parameter. This is done in the Main Menu. Press ENTER button to go into the Main Menu. 2. The Main Menu consists of Operation Menu, Settings Menu, Timer Menu, Alarm Menu, Warning Menu and Display Menu.

  • Page 11: Main Menu

    Main Menu Press ENTER to go to this menu. Operation Menu Timer Menu Alarm Menu Settings Menu Warning Menu Timer Menu Display Menu Alarm Menu Warning Menu There are 6 sub menus in [Main Menu]. Press ▲ or ▼ to select sub menus, ENTER to enter into the sub menu or press ESC to exit to main display screen.

  • Page 12: Clock Setting

    Timer Menu Select [Timer Menu] in [Main Menu] and press ENTER to go into this menu. TIMER MENU Clock Setting Date Setting Timer Schedule Timer : Enable All the timer/schedule settings are included in this menu. Press ▲ or ▼ to select the required setting. Then, press ENTER to enter the setting mode.
  • Page 13 Alarm Menu/Warning Menu Select [Alarm Menu]/[Warning Menu] in [Main Menu] and press ENTER to go to this menu. This place keeps records for all previous system faults/alarms/warnings. User can view or clear these records. The panel can keep up to 20 faults/alarm warning records. Press ESC to exit to [Main Menu].

  • Page 14: Installation

    C. Installation When installing the LCD panel to the bracket, Push to fasten the LCD panel to the bracket Hook the LCD panel from the bottom fi rst When removing the LCD panel from the bracket, Remove the LCD panel from the top part first Remove the LCD panel...

  • Page 15: Roof Curb

    Installation (a) Location For Installation Install the unit in a manner that prevents short cycling of condenser air back into the unit. (As in the case of short circuit of discharge air). Allow sufficient space for maintenance around the unit. When two or more units are installed in a location, they must be positioned such that one unit will not be taking the discharge air from another unit. Ensure that there is no obstruction of air flow into or out of the unit. Remove obstacles which block air intake or air discharge. The location must be well ventilated, in a manner that prevents short cycling of condenser air back into the unit. The unit is recommended to install in:- A place capable of bearing the weight of the unit and isolating noise and vibration. A place that has adequate drainage. A place where the unit will not be buried in snow. A place where air outlet port is not exposed to strong wind.
  • Page 16 Section A-A 25.0 Section B-B Section C-C A5RT Dimension A5RT180BR A5RT90BR 120/150BR Label 1821.0 1890.0 2448.0 1505.5 2081.0 2081.0 1881.0 1908.0 2466.0 1468.5 1998.0 1998.0 15.0 25.0 25.0 20.0 43.0 46.0 838.2 698.7 827.0 538.1 676.0 676.0 272.4 538.9 444.6 605.1 599.8 645.8...
  • Page 17 (d) Unit Lifting Lifting beam Holes at 4 corners of the unit base are used for unit lifting purpose. The spreader bar shall be slightly wider than the unit width. Chain The insulation should be added at 4 corners of the chain Spreader to prevent the damage of the panel when lifting.
  • Page 18 (g) Unit Conversion In the case of converting standard unit to downflow unit, follow the steps as stated below: A5RT 90,120, 150 & 180 Step 1 Step 2 Remove screws at both sides Remove the Pulley Belt Remove the side panel Detached blower Detached the blower support...
  • Page 19 Special Precautions When Dealing With Refrigerant R410A Unit (1) What is new refrigerant R410A? R410A is a new HFC refrigerant which does not damage the ozone layer. The working pressure of this new refrigerant is 1.6 times higher than conventional refrigerant (R22), thus proper installation / servicing is essential.
  • Page 20 (d) When charging R410A, ensure that only liquid is being withdrawn from the cylinder or can. This is to ensure that only the original composition of R410A is being delivered into the system. The liquid composi- tion can be different from the vapor composition. Invert cylinder Dip-pipe without dip-pipe...
  • Page 21 Note: While installing the circuit breaker onto the unit, make sure that the screws do not damage the components (e.g. coil) inside the unit. The switch box also can be installed without attaching to the unit. The knockout holes are only in A5RT90BR; A5RT120BR comes with a power cable hole. A5RT90BR A5RT120BR CONTROL...
  • Page 22 Control Module Of Unit A5RT90BR Control Module Of Unit A5RT120BR...
  • Page 23 Control Module Of Unit A5RT150BR Control Module Of Unit A5RT180BR...

  • Page 24: Sound Data

    4. SOUND DATA Outdoor Noise Level Noise 1/1 Octave Sound Pressure Level (dB, ref 20µPa) Overall Model Criteria (dBA) 63Hz 125Hz 250Hz 500Hz 1kHz 2kHz 4kHz 8kHz (NC) A5RT90BR A5RT120BR A5RT150BR A5RT180BR 1/1 Octave Sound Power (dB, ref 20µPa) Overall Model dBA) 63Hz 125Hz 250Hz...
  • Page 25 A5RT90BR NC CURVES NC70 NC65 NC60 NC55 NC50 NC45 NC40 NC35 NC30 NC25 NC20 1000 2000 4000 8000 Octave-band frequency (Hz) A5RT120BR NC CURVES NC70 NC65 NC60 NC55 NC50 NC45 NC40 NC35 NC30 NC25 NC20 1000 2000 4000 8000 Octave-band frequency (Hz)
  • Page 26 A5RT150BR NC CURVES NC70 NC65 NC60 NC55 NC50 NC45 NC40 NC35 NC30 NC25 NC20 1000 2000 4000 8000 Octave-band frequency (Hz) A5RT180BR NC CURVES NC70 NC65 NC60 NC55 NC50 NC45 NC40 NC35 NC30 NC25 NC20 1000 2000 8000 4000 Octave-band frequency (Hz)

  • Page 27: Selection Process

    5. SELECTION PROCESS Drive Package Selection The following are the design requirements for A5RT90BR unit: Model : A5RT90BR Supply air Quantity = 1600 l/s External Static Pressure = 175 Pa Step 1: From the blower curve (at 1600 l/s) Standard operating system; Internal Static Pressure = 90 Pa Step 2: Therefore at 1600 l/s and 175 Pa external static pressure Total Static Pressure = 175 + 90 Pa = 265 Pa Step 3: From the blower curve, the design requirement calls for RPM about 690 RPM. From the table: Motor pulley = 71 mm Blower pulley = 160 mm Motor RPM = 1480 RPM In order to obtain 700 RPM, we calculate the new blower pulley as: (while maintaining the motor pulley) = 71 x (1480/690) = 152.3 mm Let us take close approximation of 150 mm diameter pulley size Recheck, with Db = 142 mm Blower pulley...

  • Page 28: Drive Package

    Drive Package A5RT90B(R) 1.5 kW 1.1 kW Standard Point 0.75 kW Internal Static Pressure 2600 2800 3000 3200 3400 3600 3800 4000 1300 1400 1500 1700 1600 1800 Air Flow Blower Pulley, Db Motor Pulley, Dm Model Type Diameter(mm) Bore(mm) Diameter(mm) Bore(mm) A5RT90BR...

  • Page 29: Blower Curves

    Blower Curves A5RT90B(R) 1.5 kW 1.1 kW Standard Point 0.75 kW Internal Static Pressure 2600 2800 3000 3200 3400 3600 3800 4000 1500 1300 1400 1700 1600 1800 Air Flow...
  • Page 30 A5RT120B(R) 1000 2.2 kW 1.5 kW 1.1 kW Standard Point Internal Static Pressure 3200 3500 3800 4100 4400 4700 5000 5150 1900 2200 1600 1800 2300 1700 2000 2100 2400 Air Flow...
  • Page 31 A5RT150B(R) 3.0 kW 1000 2.2 kW 1.5 kW Standard Point Internal Static Pressure 4200 4700 5200 5700 6200 6700 7200 2000 2200 2400 2600 2800 3000 3200 3400 AIR FLOW...
  • Page 32 A5RT180B(R) 3.7 kW 3.0 kW 1000 2.2 kW Standard Point Internal Static Pressure 5300 5800 6300 6800 7300 7800 8300 2500 2700 2900 3100 3300 3500 3700 3900 AIR FLOW...

  • Page 33: Engineering & Physical Data

    6. ENGINEERING & PHYSICAL DATA General Data - Heat pump (R410a) MODEL A5RT90BR A5RT120BR Btu/h 93300 121400 NOMINAL COOLING CAPACITY (GROSS) 27340 35580 Btu/h 85000 118700 NOMINAL HEATING CAPACITY (NETT) 24910 34790 NOMINAL TOTAL INPUT POWER (COOLING) 8140 10780 NOMINAL TOTAL INPUT POWER (HEATING) 7330 10840 NOMINAL RUNNING CURRENT (COOLING)
  • Page 34 General Data - Heat pump (R410a) MODEL A5RT150BR A5RT180BR Btu/h 152600 190000 NOMINAL COOLING CAPACITY (GROSS) 44720 55690 Btu/h 142600 184000 NOMINAL HEATING CAPACITY (NETT) 41790 53930 NOMINAL TOTAL INPUT POWER (COOLING) 13040 16740 NOMINAL TOTAL INPUT POWER (HEATING) 12860 15540 NOMINAL RUNNING CURRENT (COOLING) 28.3...
  • Page 35 Electrical Data -Heatpump (R410a) MODEL A5RT90BR A5RT120BR INSULATION GRADE POWER SOURCE V/Ph/Hz 380 ~ 415 / 3 / 50 RATED INPUT POWER 1,160 EVAPORATOR MOTOR RATED RUNNING CURRENT 3.10 MOTOR OUTPUT 1100 1,500 POLES INSULATION GRADE POWER SOURCE V/Ph/Hz 220 ~ 240 / 1 / 50 RATED INPUT POWER CONDENSER MOTOR 1...
  • Page 36 Electrical Data - Heatpump (R410a) MODEL A5RT150BR A5RT180BR INSULATION GRADE POWER SOURCE V/Ph/Hz 380 ~ 415 / 3 / 50 RATED INPUT POWER 1910 2,580 EVAPORATOR MOTOR RATED RUNNING CURRENT 4.70 MOTOR OUTPUT 2200 3,000 POLES INSULATION GRADE POWER SOURCE V/Ph/Hz 220 ~ 240 / 1 / 50 RATED INPUT POWER...
  • Page 37 Components Data-Heatpump (R410a) MODEL A5RT90BR A5RT120BR TYPE CENTRIFUGAL FORWARD CURVE QUANTITY MATERIAL GALVANISED STEEL GALVANISED STEEL EVAPORATOR DRIVE BELT DRIVE mm/in DIAMETER 381 / 15 381 / 15 LENGTH mm/in 381 / 15 381 / 15 TYPE INDUCTION MOTOR EVAPORATOR QUANTITY FAN MOTOR INDEX OF PROTECTION (IP)
  • Page 38 Components Data-Heatpump (R410a) MODEL A5RT150BR A5RT180BR TYPE CENTRIFUGAL FORWARD CURVE QUANTITY MATERIAL GALVANISED STEEL GALVANISED STEEL EVAPORATOR DRIVE BELT DRIVE DIAMETER mm/in 381 / 15 400 / 15.7 LENGTH mm/in 381 / 15 400 / 15.7 TYPE INDUCTION MOTOR EVAPORATOR QUANTITY FAN MOTOR INDEX OF PROTECTION (IP)
  • Page 39 Safety Devices- Heatpump (R410a) MODEL A5RT90BR A5RT120BR TYPE NC, Auto Reset HIGH PRESSURE SWITCH OPEN kPa/psi 4137 / 600 CLOSE kPa/psi 3309 / 480 TYPE NC, Auto Reset SAFETY DEVICE LOW PRESSURE SWITCH OPEN kPa/psi 124 / 18 CLOSE kPa/psi 193 / 28 PHASE SEQUENCER DISCHARGE THERMOSTAT SETTING...

  • Page 40: Performance Data

    7. PERFORMANCE DATA Calculation Steps Interpolation method can be used to get the total capacity, TC and sensible capacity, SC and power input, PI at those temperatures which are not stated out in the table. Extrapolation method are not allowed to be used to get the TC, SC and PI.
  • Page 41 Details: Step: To obtain the Total capacity and Sensible capacity and Power input for (a) Indoor Condition: 25˚C DB, 16˚C WB Outdoor Condition: 35°C DB Outdoor DB, ˚C Indoor WB Indoor DB ˚C ˚C TC (kW) SHC (kW) PI (kW) 41.41 35.59 12.81...
  • Page 42 (b) Indoor Condition: 25˚C DB, 16˚C WB Outdoor Condition: 40°C DB Outdoor DB, ˚C Indoor WB Indoor DB ˚C ˚C TC (kW) SHC (kW) PI (kW) 38.59 33.52 13.91 ....... 40.74 39.20 14.06 Total capacity, TC Interpolation Method: 27º C – 24º C 40.74kW –...
  • Page 43 Step: To obtain the Total capacity, Sensible capacity and Power Input for (a) Indoor Condition: 25°C DB, 17°C WB Outdoor Condition: 35°C DB Outdoor DB,˚C Indoor WB Indoor DB ˚C ˚C TC (kW) SHC (kW) PI (kW) 42.10 37.60 12.85 ......
  • Page 44 (b) Indoor Condition: 25°C DB, 17°C WB Outdoor Condition: 40°C DB Outdoor DB,˚C Indoor WB Indoor DB ˚C ˚C TC (kW) SHC (kW) PI (kW) 39.31 35.41 13.96 ......41.46 29.99 14.13 Total capacity, TC Interpolation Method: 19ºC – 16ºC 41.46kW –...
  • Page 45 Step: To obtain the Total capacity and Sensible capacity for (a) Indoor Condition: 25°C DB, 17°C WB Outdoor Condition: 37°C DB Outdoor DB, ˚C Indoor WB Indoor DB ˚C ˚C (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) ..42.92 35.61 12.91...

  • Page 46: Performance Table

    Performance Table R410A Model Cooling Mode Model: A5RT90BR Outdoor temperature AFR (CFM) ° 9 ° 5 ° 0 35°C 40°C 46°C 21°C 26.92 17.79 6.55 25.90 17.33 6.93 25.31 17.19 7.46 24.12 16.64 7.91 22.42 15.75 8.60 20.86 15.04 9.52 24°C 27.02 20.73 6.56 26.00 20.27...
  • Page 47 Model: A5RT150BR Outdoor temperature ° 9 ° 5 ° 0 35°C 40°C 46°C (CFM) 21°C 44.03 29.82 10.49 42.37 29.06 11.10 41.41 28.82 11.95 39.46 27.89 12.68 36.67 26.40 13.77 34.12 25.22 15.25 24°C 44.20 34.76 10.50 42.53 33.98 11.11 41.57 33.82 11.96...
  • Page 48 Heating Mode Model: A5RT90BR Outdoor WB, ° C Indoor DB, °C TC (kW) PI (kW) TC (kW) PI (kW) TC (kW) PI (kW) TC (kW) PI (kW) TC (kW) PI (kW) 17.71 5.41 24.99 6.49 28.96 7.08 30.95 7.38 32.93 7.67 17.23 5.64 24.96...

  • Page 49: Dimensional Data

    8. DIMENSIONAL DATA Model: A5RT90BR 1274.5 116.7 513.0 84.8 544.0 379.1 2063.0 SUPPLY AIR 45.3 RETURN 50.5 2181.0 DRAIN PIPE Ø 1" 872.1 788.1 FOR HORIZONTAL DISCHARGE 171.0 779.0 Back view of the unit: 1638.0 VERTICAL RETURN VERTICAL SUPPLY 171.2 408.0 2131.0 BACK VIEW OF THE UNIT FOR VERTICAL DISCHARGE CENTER OF GRAVITY All dimensions are in mm...
  • Page 50 Model: A5RT120BR 2180.0 1407.0 264.8 544.0 650.5 614.3 2113.0 135.6 SUPPLY AIR 57.5 RETURN ø DRAIN PIPE 1" 2230.0 1161.3 1069.3 FOR HORIZONTAL DISCHARGE 630.0 164.3 Back view of the unit: 2209.0 VERTICAL RETURN CONTROL VERTICAL SUPPLY 164.3 407.0 FOR VERTICAL DISCHARGE All dimensions are in mm CENTER OF GRAVITY...
  • Page 51 Model: A5RT150BR All dimensions are in mm CENTER OF GRAVITY...
  • Page 52 Model: A5RT180BR All dimensions are in mm CENTER OF GRAVITY...

  • Page 53: Wiring Diagrams

    9. WIRING DIAGRAMS Model: A5RT90BR...
  • Page 54 Model: A5RT120BR...
  • Page 55 Model: A5RT150BR...
  • Page 56 Model: A5RT180BR...

  • Page 57: Servicing & Maintenance

    10. SERVICING & MAINTENANCE Service Of The Filter • Remove any dust adhering to the filter by using a vaccum cleaner or wash in lukewarm water (below 40°C) with neutral cleaning detergent. • Rinse the filter well and dry before placing it back onto the unit. •...

  • Page 58: Troubleshooting

    11. TROUBLESHOOTING For any enquiries on spare part please contact your authorized dealer. If any malfunction of the air conditioner unit is noted, check the following fault conditions and causes for some simple troubleshooting tips. Problem Causes Action Unit does not run. Power failure.

  • Page 59: Exploded View & Parts List

    12. EXPLODED VIEW AND PARTS LIST MODEL : A5RT90BR No Description Part Number No Description Part Number Structure, Base Right R01014087427 Ins, Panel, Base ID 7 (T10x1065.4x66) R06014087528 Support, Structure, Base R01014087430 Ins, Panel, Base ID 8 T10x505x155 (87523) R06014087529 Assy, Structure Base Back R50014088634 Insulation, Base/top (T3x20x990) R06014096637 Assy, Structure Base Front...

  • Page 60: Part Number

    No Description Part Number No Description Part Number Ins., Front Panel 4 (T10.0x1000.0x25.0) R06014102236 Motor, 11KTML 1.1kW P714958x01 R03039021694 Ins., Front Panel 5 (T10.0x1000.0x45.0) R06014105557 Pulley, 1 SPZ 71/1108 Reptech R03049030767 Ins., Front Panel 6 (T10.0x510.0x148.0) R06014105558 Pulley, Bush 1108/24 R03044039695 Ins., Front Panel 7 (T10.0x510.0x70.0) R06014105698...
  • Page 61 MODEL : A5RT120BR No Description Part Number No Description Part Number Assy Tubing Assy, Pillar Rear Centre Right R50014102263 Assy, Base Pan Main R50084107170 Ins, Rear Center Right R06014106775 Assy, Separator R50014101962 Assy, Pillar Rear Centre Left R50014102262 Ins, Separator 3 R06014101995 Ins, Pillar Rear Center L R06014105885...
  • Page 62 No Description Part Number No Description Part Number ID Channel, Top Right R01014105812 Assy, Main Isolator R50014105228 Ins, ID Top Channel 1 R06014105880 Plate, Cover Isolator R01014105311 Ins, ID Top Channel 2 R06014105877 Coil Guard, Side R01024105468 Ins, ID Top Channel 3 R06014105875 Coil Guard, Back (Right) R01024105467...
  • Page 63 MODEL : A5RT150BR No Description Part Number No Description Part Number Assy Tubing Assy, Pillar Rear Centre Right R50014101966 Assy, Base Pan Main R50084107170 Ins, Pillar Rear CTR R (T3.0x916.2x168.8) R06014105886 Assy, Separator R50014105793 Assy, Pillar Rear Centre Left R50014101967 Ins, Separator 3 T10.0 X 924.2 X 299.0 R06014105909 Ins., Pillar Rear CTR L T3.0x916.2x118.8...
  • Page 64 No Description Part Number No Description Part Number ID Channel, Top Left R01014105811 Fan Guard Left R01024102016 Fan Guard Right R01024102017 Ins, ID Top Channel 1 R06014105880 Cover, Top Panel R01014106139 Ins, ID Top Channel 2 R06014105877 Ins, Cover Top Panel R06014106852 Ins, ID Top Channel 3 R06014105875...
  • Page 65 MODEL : A5RT180BR No Description Part Number No Description Part Number Assy Tubing Assy, Pillar Rear R R50014103296 Assy Base Pan Main R50084107170 Ins Pillar Rear Right R06014105531 Plate, Support Solenoid Valve R01014105529 Assy, Pillar Center L R50014103293 Panel Return Cover R01014105872 Ins, Pillar Center R06014102117...
  • Page 66 No Description Part Number No Description Part Number Assy., Panel Front R50014102124 Plate, Cover Isolator R01014105311 Ins., Panel Front 1 R06014102125 Switch,Isolator 63a 3ID2504-1TL53 Siemen R04069033879 Ins., Panel Front 2 R06014102126 Base, Motor Lower R01014108550 Ins, Front Panel 3 R06014103000 Base, Motor Upper R01014107747 Ins., Panel Front 4...
  • Page 67 While upmost care is taken in ensuring that all details in the publication are correct at time of going to press, we are constantly striving for improvement and therefore reserve the rights to alter model specifications and equipment without prior notice. Details of specifications and equipment are also subject to change to suit local conditions and requirements and not all models are available in every market.
