TalkShow
VS 4000
Setup
1
Connect the power cable to the rear panel and
plug into an external power source
2
Connect the keyboard and mouse using USB
ports
3
Connect an external computer monitor
either HDMI port to display the user interface
4
Plug Ethernet cable(s) into the Ethernet port(s)
and connect to a network with Internet access
5
Open the front panel and press the power
button
Registration
1. Accept the End User License Agreement
2. If necessary, enter the Serial Number and Product ID for
your system in the TalkShow registration dialog box
3. Click the Continue button as directed in the TalkShow
registration dialog box to proceed to the NewTek
Registration site
4. Create (or log into) your User Account in the NewTek
Registration System using a valid e-mail address
5. Enter your product information as required, then click the
Register button to obtain your Registration Code via e-mail
6. Enter your Registration Code in the TalkShow registration
dialog box as directed, then click Continue to complete
registration and launch TalkShow
Configure Skype TX controller
1. Accept the Skype TX End User License Agreement
2. Sign in using an existing Skype ID or associated Microsoft account
(or create a new account)
3. In the Skype TX controller user interface, click the menu icon in the
top right corner of the window
4. Navigate to the data entry field under Add a Skype TX Unit to control
5. Enter the device name for your TalkShow system (displayed in the
title bar of the TalkShow user interface) or the system's IP number
into the data entry field
6. Click the (+) button to the right of the data entry field to add the
four call channels of your TalkShow system to Skype TX controller
7. Choose a call channel and click Sign In
8. Configure the settings for the channel using the on-screen controls; repeat steps 7-8 for each call channel
Minimum 1024x768 resolution
1
Minimum 2.5 Mbps (upload and download) recommended per call channel
2
Registration is required to begin using TalkShow. To register your system, connect TalkShow to a network with Internet access as directed and follow the instructions provided, or visit register.newtek.com from any
Web browser (TalkShow Serial Number and Product ID required).
Be sure to record your User Account login and password, Serial Number, Product ID, and Registration Code, and store in a safe place for future reference.
®
