TerraTrike The Rover Assembly Manual
Hide thumbs
Also See for The Rover:
- Quick start manual (8 pages) ,
- Assembly manual (2 pages) ,
- Quick start manual (4 pages)
Subscribe to Our Youtube Channel
Related Manuals for TerraTrike The Rover
Summary of Contents for TerraTrike The Rover
- Page 1 Assembly Guide Pilot’s Handbook Technical Illustration & Parts List www.TerraTrike.com - 800.945.9910 4525 Stauffer Ave SE, Suite A. Kentwood, MI 49508...
-
Page 2: Table Of Contents
-Cautions/Safety - Pg 10 -Riding Tips - Pg 10-11 -Special Tandem Consideration - Pg 11 -Survivals Tips - Pg 11 -Maintenance of your TerraTrike - Pg 11-12 -TerraTrike Lifetime Warranty - Pg 12 -Liability Waiver - Pg 12 Rover Information - Pg 13-14... -
Page 3: Assembly Guide
Assembly Guide Dark Grey = Installation/Adjustment RIGHT HAND SIDE OF TRIKE LEFT HAND SIDE OF TRIKE Hubmount Hubmount “L” Bracket (computer sensor mount) -
Page 4: Alignment
29 13/16” from center 13 15/16” of tires In ate Tires First... -
Page 5: Chain Install
1” - 2”... -
Page 6: Tighten Set-Screw
Pull While tightening Set Screws (Step 6) Tighten to 8-10Nm (70-85 in. lbs.) One located under this tube -IMPORTANT- Rover 3 and Rover 8 also have a chain tube for return (bottom) part of chain. Spacer(s) only used on Rover 3, 8 & Tandem... -
Page 7: Install Seat
Seat frame Base Chain Main (drive train) Tube side of trike Seat stay pins... -
Page 10: Tuck Seat Straps
Handle bar adjustment - SEE PG 13... -
Page 11: Rover Sizing Chart
33” - 43.5” Medium - 14.5” (Boom Sizing sticker) 36.5” - 47” Longest - 18” **Boom positions are from center of bottom brack- et to edge of front frame section** *For X-seam measurement illustration, refer to X-seam measurement chart at: http://www.terratrike.com/sizing.php... -
Page 12: Pilot's Handbook
•Use caution when cornering. Learn to use safe speeds for negotiating corners and going down hills. •Lean into turns when cornering at speed. Your TerraTrike can be “rolled” if turned too sharply for a given speed. Rule of thumb: rubber side down. :) •The disc brakes and rotors will get very hot after braking. -
Page 13: Special Tandem Consideration
•Remember you are riding a tandem. It’s not a sports car, so don’t expect it to handle like one. You are moving twice the weight of a regular TerraTrike, and it will take longer to stop. Give yourself plenty of room to slow down. -
Page 14: Terratrike Lifetime Warranty
TerraTrike. Clean it off immediately! Likewise, salty air will corrode your TerraTrike. It’s a good idea to wax the frame occasionally with a good quality car wax. We do use stainless steel nuts and bolts. -
Page 15: Rover Information
Handlebar Adjustment ***HANDLEBAR ADJUSTMENT VIDEO AVAILABLE ONLINE - http://www.terratrike.com/manuals.php Your Rover’s handlebars are adjustable in two different ways: 1) The stiffness/ease of steering can be adjusted - you can make your Rover harder or easier to steer by adjusting your “Top Cap Bolts”... -
Page 16: Seating Position Adjustment
**TIRE PRESSURE SHOULD BE CHECKED BEFORE EACH RIDE.** The Rover uses “Schrader” valves. These valves are similar to car tires. A standard bicycle tire pump or air compressor will work to inflate these valves. ***BE SURE NOT TO OVER INFLATE.***... -
Page 18: Parts List
ROVER PARTS LIST Item Descriptions Quantity Front Frame Assembly Rear Assembly Boom Assembly Hubmount (Right side) Hubmount (Left side) Handle bar (Right side) Handle bar (Left side) Seat Frame (Steel) Seat bracket w/ quick release Seat Stay - upper Seat Stay - lower Steering washer Tie Rod Tie rod stand-off spacer (13mm) -
Page 19: Notes
NOTES... -
Page 20: Company Contact Information
COMPANY INFORMATION: TerraTrike (WizWheelz Inc.) 4525 Stauffer Ave SE, Suite A. Kentwood, MI 49508 Email: sales@terratrike.com - for Ordering & Customer Service tech@terratrike.com - for Technical Assistance shipping@terratrike.com - for Shipping Inquiries Phone: 1-800-945-9910 or 1-616-455-5988 Fax: 1-616-455-6058 RESOURCES: ∙TerraTrike Forum - http://www.terratrike.com/forum/ ∙TerraTrike Blog - http://terratrike.com/blog/... - Page 21 Michigan. A rider or owner of a TerraTrike and/or the owner of any accessories thereto, agrees that the United Nations Convention on Contracts for the International Sale of Goods does not apply.
