- Page 1 24AER10 USER’S MANUAL 24” LED TELEVISION...
-
Page 2: Important Safety Instructions
Important Safety Instructions 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8. -
Page 3: Safety Instructions
Safety Instructions Important safeguards for you and your new TV Observing the simple precautions discussed in this booklet will provide you with many years of enjoyment and safe operation. This product complies with all applicable US Federal safety requirements, and those of the Canadian Standards Association. - Page 4 Safety Instructions 13. Outdoor Antenna Grounding If an outside antenna or cable system is connected to the TV be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built up static charges. Article 810 of the National Electrical Code (U.S.A.), ANSI / NFPA 70 provides information with regard to proper grounding of the mast and supporting struc- ture, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna- discharge unit, connect on to grounding electrodes, and requirements for the grounding electrode.
- Page 5 Safety Instructions 19. Replacement Parts When replacement parts are required, be sure that only an authorized service technician has used replacement parts specified by Apex Digital or have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, or other hazards and void any warranty.
-
Page 6: Table Of Contents
Table of Contents Important Safety Instructions ............................1 Table of Contents ................................5 Introduction ..................................6 Remote Control Battery Install .................................7 Overview ..................................8 TV Overview Front & Side Panel ..............................10 Rear Panel & Pedestal Removal ..........................11 Installation Connection to Antenna & Cable / Satellite Box ......................12 Connection to HDMI Input ............................13 Connection to Component YPbPr Input ........................14 Connection to Composite Input ...........................15... -
Page 7: Introduction
Introduction What’s In The Box Thank you for purchasing the energy efficient 24AER10 television. It has been designed to enjoy today’s high definition television experience. With a display resolution of 24” 1920X1080 you are assured of one of the finest quality televisions available today. -
Page 8: Remote Control
Remote Control Battery Install Your remote control handset is powered by two (2) AAA type batteries remote control over and remove the battery over. in the battery compartment. Universal Remote Code: To operate this TV using the remote control provided by your Cable / Satel- lite provider, follow the programming instructions included with the provid- ers’... -
Page 9: Overview
Remote Control Overview 24AER10 Notes: 1. If direct sunlight shine directly on the remote sensor, the remote control’s operation may be unstable, and the effective range will be reduced. 2. Do not hit or violently shake the remote control. 3. Never expose the remote control to high temperature or humidity. - Page 10 Remote Control Overview 29. NUMBER KEYS Press number keys to enter channel numbers.
-
Page 11: Tv Overview
TV Overview Front & Side Panel IR Receiver A soft blue light illuminates when the television power is on. 1. Input - After connecting your DVD, cable box, etc., select the appropriate Source Selec t input source to view. Press the INPUT button to display the input options. Press the CH- / CH+ buttons to highlight the input source and press the VOL+ button to select. -
Page 12: Rear Panel & Pedestal Removal
TV Overview Rear Panel & Pedestal Removal LE2424 Wall Mounting It is recommended that you consult a professional before mounting this TV a wall. Use VESA 100 x 100 wall mount hardware. NOTE: You must remove the pedestal before wall mounting. -
Page 13: Installation
Connection to Antenna & Cable / Installation Satellite Box It is strongly recommended that the installation of a high quality roof top antenna, digital cable, or satel- lite set top box be used in conjunction with your television for best broadcast reception. For indoor use, we recommend an Apex Digital amplified HDTV antenna. -
Page 14: Connection To Hdmi Input
Installation Connection to HDMI Input Digital Cable / Satellite Set Top Box Optional HDMI cable ( not included ) Cable / Satellite set top box Coaxial / RF Cable (not included) How to connect with Digital Cable / Satellite Set Top Box Connect the RF coaxial (75 ohm) cable from the video outlet of your cable / Satellite box to the RF input on the TV’s panel. -
Page 15: Connection To Component Ypbpr Input
Connection to Component Installation YPbPr Input Connecting External Equipment to Component Video IN (Y Pb Pr) Optional Component cables (not included) Digital set top box, gaming console or DVD For BETTER video performance Connect to external equipment that features component video output jacks for better performance. -
Page 16: Connection To Composite Input
Installation Connection to Composite Input Connecting External Equipment to AV Composite IN on your television Audio Video Cable (included) Digital set top box, gaming console or DVD For GOOD video performance Connect to external equipment using optional video and audio cables. Composite output jacks are available on most set top cable / satel- lite boxes and DVD players. -
Page 17: Connection To A Personal Computer
Installation Connection to a Personal Computer Connecting a Personal Computer with VGA to your television VGA & Audio Cable (not included) Recommended computer display resolution:1366x768@60 Hz How to Connect a PC Source Selec t Connect using an optional male to male VGA cable (not included) from your PC to the VGA input on the TV’s panel. -
Page 18: Connection To A Home Theater System
Connection to a Home Installation Theater System Connection to a Home Theater Audio System Optional digital cable (not included) For BEST audio performance Connecting to a Home Theater System Digital audio can deliver optimal 2 - channel stereo or 5.1 surround sound with Five discrete full range channels plus a separate channel for a subwoofer. -
Page 19: Tv Setup
TV Setup Initial Setup Wizard Initial Setup Wizard Setup Wizard only appears when first turning the TV on and without channel scanning. After connecting your TV antenna or cable wire, turn the television ON. The quick setup wizard will display on-screen. Select your preferred Picture setting followed by antenna options and performing Auto Scan to receive local broadcast channels that will be stored in the TV tuner memory. -
Page 20: Tv Channel Setup & Channel Auto Scan
TV Channel Setup & TV Setup Channel Auto Scan Select antenna options and perform Channel Auto Scan to receive television channels that will be stored into the TV tuner memory. To enter TV Mode: • Press the MENU button • Channel Using the arrow buttons;... -
Page 21: Picture Setting
Menu Adjustments Picture Setting The Picture menu offers options to enhance and refine the picture displayed on your TV based on ambient room light and personal preferences. Adjustment options include contrast, brightness, color, sharpness and color temperature. How to Navigate: Press the MENU button on the remote control. -
Page 22: Audio Settings
Menu Adjustments Audio Settings The Audio menu offers options to make sound enhancements while listening through the built-in speakers or to select digital audio options when connected to a Dolby Digital receiver though a (SPDIF) coaxial digital output. How to Navigate: Press the MENU button on the remote control. -
Page 23: Date & Time Settings
Menu Adjustments Date & Time Settings The Time menu includes adjustment of settings for your local time zone and daylight savings time. The clock will adjust automatically after the initial Channel Auto Scan of available broadcast channels in your area (see page 19 for TV Setup). -
Page 24: Setup Settings
Menu Adjustments Setup Settings In the Setup menu you may change the initial set up of preferences that include settings for language, menu display, computer monitoring,closed captions, enhancement of black detail in the picture and resetting your TV back to its fac- tory default status. -
Page 25: Closed Captions
Menu Adjustments Closed Captions The Setup menu includes adjustments for activating the Closed Caption text feature for display on-screen and customiz- ing CC display types and font styles. How to Navigate: Press the MENU button on the remote control. Navigate using arrow buttons to select Setup. -
Page 26: Advanced Settings
PC Menu Adjustments Advanced Settings In the Setup menu you may adjust the position of images displayed on screen once you connect an input signal from your PC. The recommended resolution is 19”1366X768 / 24”1920X1080 . For use with a laptop computer, refer to your computer’s user manual on instruction for proper display output. -
Page 27: Parental Control
Menu Adjustments Parental Control In the Lock menu, you may block television and movie programming based on TV ratings and Motion Picture Association guidelines. To gain access and select your preferences within the Parental menu make certain your input is set to TV. How to Navigate: Press the MENU button on the remote control. - Page 28 Menu Adjustments Parental Control In the Lock menu, you may block television and movie programming based on Canadian TV and movie rating guidelines. To gain access and select your preferences within the Parental menu make certain your input is set to TV. How to Navigate: Press the MENU button on the remote control.
-
Page 29: Tv Settings
Menu Adjustments TV Settings The Channel provides the setup / changes of your television to receive broadcast channels, store your favorite chan- nels, add or skip channels in memory and label or name channels.(For antenna and Auto Channel Scan setup, please refer to page 19.) How to Navigate: Press the MENU button on the remote control. -
Page 30: Zoom Modes
ZOOM Modes The ZOOM function offers several viewing display options on the 16:9 screen. Press the ZOOM button to cycle through the following widescreen settings. Press ZOOM to cycle through the following widescreen settings. 1. NORMAL Recommended for viewing native widescreen content and undistorted 4:3 images (with black bars). -
Page 31: Usb Modes
USB Modes 1. Press the INPUT Media. Source Select Source menu, and then press the ENTER button to enter. Component / AV HDMI Media sic, and then press the ENTER button to enter. press ENTER button to enter. then press the ENTER button to enter. then press the ENTER button to enter. - Page 32 MHL Setting Connecting a MHL-enabled device You can connect a compatible MHL-enabled device, such as a cell phone, and view your device’s screen on your TV. To connect a MHL-enabled device: 1. Press INPUT to display the Input Menu. 2. Press to select HDMI, then press ENTER.
-
Page 33: The Mobile Phone Model
MHL Setting The mobile phone match with MHL model list: Mobile Devices Samsung Huawei Asus Fujitsu Sharp Sony Xiaomi Pantech Meizu Panasonic Acer OPPO Kyocera... - Page 34 Specifications Display Size (inch) Aspect Ratio 16:9 Digital Compatibility 480i / 480p / 720p / 1080i / 1080p Resolution 1366x768 Brightness (cd / m2) Dynamic Contrast Ratio 1000:1 Vertical Viewing Angle (degrees) 160° Horizontal Viewing Angle (degrees) 170° Maximum Colors (millions) 16.7M Power Consumption 36Watts...
-
Page 35: Troubleshooting
Troubleshooting Check for a possible solution to a symptom before contacting a customer service representative. Cannot receive certain • Perform Channel Scan to add channels into the TV tuner memory. channels through the See page 19. antenna • Readjust your antenna and retry Auto Channel Scan. •...
