Patio Chef SS48055 LP Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Owner's Manual
Liquid Propane Gas Grill
MODEL SS48055 LP
Natural Gas Grill
MODEL SS48055 NG
Customer Service:
or missing parts when you unpack this unit from the shipping boxes, call us 8:00am - 5:00 pm EST,
Monday through Friday at:
!
WARNING:
Read this Owner's Manual carefully and be sure
your gas grill is properly assembled, installed and
maintained. Follow all leak check procedures
carefully in this manual prior to grill operation. Do
this even if the grill was store assembled.
Failure to follow these instructions could result in
serious bodily injury and/or property damage.
This grill is intended for outdoor use only and is
not intended to be installed in or on recreational
vehicles or boats.
Note to Installer:
Leave this Owner's Manual
with the consumer after delivery and/or installation.
Note to Consumer:
Leave this Owner's Manual
in a convenient place for future reference.
MODEL SS48055 LP SHOWN
If you have questions about assembly or grill operation, or if there are damaged
1- 800-667-7313
Important Note:
This grill is manufactured to
exact specifications. Model SS48055 LP is
certified for use with LP gas and Model SS48055
NG is certified for use with Natural Gas. You
can not convert this grill from one fuel type
to the other. For your safety, conversion kits
are not available. Any attempt to convert your
grill will void your warranty.
Imported by S.R. Potten Ltd/Ltée
1645-50th AVE. LACHINE, QUEBEC, CANADA
H8T 3C8
TEL:514-631-4995
TOLL FREE:1-800-667-7313
FAX:514-636-8185
P80153001F-Date: 01/10/2003
