- Page 1 Theatre spot 100 LP-TS100 CW/WW User Manual Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions 2. Technical Specifications 3. How to Install the Barn Door 4. How to Set the Fixture 5. How to Control the Fixture 6. DMX 512 Configuration 7. DMX 512 Connections 8. Troubleshooting 9. Fixture Cleaning... - Page 3 1. Safety Introductions Please read the instructions carefully which includes important information about the installation, operation and maintenance. WARNING Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. ...
-
Page 4: Technical Specifications
Avoid any inflammable liquids, water or metal objects entering the unit. Once it happened, cut off the mains power immediately. Do not operate in dirty and dusty environment, also cleaning fixtures regularly. Do not allow children to operate the fixture. ... -
Page 5: How To Install The Barn Door
◆Beam angle: 12 ° ~ 40 ° ◆Color Temperature: 5300K-5800K(WW)/3200+200K(VW) ◆Rotating filter and hanger ◆Thermo-optical cooling technology, no noise Power supply: AC90V ~ 250V 50Hz/60 Hz Power consumption: 141W Body temperature: <58 ° C Working life: 50,000 hours CRI: Ra=95 Luminous efficiency: 24.3Lm/W (WW)/34.64Lm/W (CW) Weight: 18.2kgs Dimension：... -
Page 6: How To Set The Fixture
① Open the spring by hands. ② Insert the barn door into the outside slot from top side. ③ Open the barn door, and then fasten the safety cable. ④ Insert the barn door into the inside slot from top side. 4. - Page 7 8. Display: To show the various menus and the selected functions 9. Safety Ring: Keep the installation safe 10. Ethernet: To transfer the unit’s information to the main controller 4.2 Main Function To select any functions, press MENU button until the required one is shown on the display. Select the function by ENTER button and the display will blink.
- Page 8 Slave Mode Select Slave Mode, press the ENTER button to confirm, present mode will blink on the display. Use the DOWN and UP button to select the Master mode or Slave mode. Once the mode has been selected, press the ENTER button to setup, to go back to the functions without any change press the MENU button again.
- Page 9 Fixture Temp. Fixture Temp. Press the MENU button up to when the is blinking on the display. Pressing ENTER button and the display will show the temperature of the unit. To go back to the functions press the MENU button again. Hold and press the MENU button about one second or wait for one minute to exit the menu mode.
-
Page 10: Dmx512 Configuration
the display and move all the motors to their ‘home’ position. After that the unit will be ready to receive DMX signal or run the built in programs. 5.1 Master/Slave Built In Preprogrammed Function By linking the units in master/slave connection, the first unit will control the other units to give an automatic, synchronized light show. -
Page 11: Dmx512 Connections
7. DMX512 Connections The DMX512 is widely used in intelligent lighting control, with a maximum of 512 channels. Connect the fixture together in a “daisy chain” by XLR plug cable from the output of the fixture to the input of the next fixture. The cable cannot be branched or split to a “Y” cable. -
Page 12: Troubleshooting
8. Troubleshooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The fixture does not work, no light 1. Check the connection of power and main fuse. 2. Measure the mains voltage on the main connector. B. - Page 13 Innovation, Quality, Performance...
