Yamaha YHT-292 Connection Manual

Hide thumbs

Advertisement

Quick Links

YHT-292
Connection Guide
English
The Yamaha YHT-292 Digital Home Theater System includes everything you need to add great
sound to your home theater. By following the steps in this Connection Guide, you'll have your
home theater set up in no time and be enjoying music and movies like never before. Part A
explains how to connect the speakers and antennas. Part B explains how to connect various AV
components. See the relevant owner's manuals for full instructions and precautions.
Caution: Disconnect all components from AC outlets before proceeding.
Part A:
Speakers and Antennas
1
Checking the package contents
1
8
9
2
6
4
>
3
7
5
Unpack and check the package contents. The following items are necessary to complete this
Connection Guide. See the owner's manuals for a complete list of supplied items.
1+2 Front Speakers (NS-B280)
7 AV Receiver (HTR-6230)
3+4 Surround Speakers (NS-B280)
8 Speaker cable
5 Center Speaker (NS-B280)
9 Subwoofer cable
6 Subwoofer (NS-SW280)
0 FM and AM antennas
2
Positioning the speakers
1 Front left speaker
2 Front right speaker
2
3 Surround left speaker
6
4 Surround right speaker
5 Center speaker
1
5
6 Subwoofer
4
Position the speakers as shown. See the
owner's manuals for more information
3
on installing the speakers.
3
Preparing the cables and speakers
Front speakers ( 1 + 2 )
Surround speakers ( 3 + 4 )
Center speaker (5)
• Cut the included speaker cable to suitable lengths for the front, center, and surround
speakers. You need to make five cables altogether. Remove about 10 mm (3/8 in.) of
insulation from the end of each wire, and then twist the bare strands tightly.
• Connect the speaker cables to the front speakers ( 1
+
2 ), surround speakers ( 3
center speaker ( 5 ). Connect the colored wire to the red positive (+) terminal, and
connect the other wire to the black negative (–) terminal. See the owner's manuals for
more information on connecting the speaker cables.
Digital Home Theater System
4
Connecting the front speakers
AV Receiver
Connect the front speaker (1+2) cables to the AV Receiver. Be sure to connect the
colored wire to the red positive (+) terminal, and connect the other wire to the black
negative (–) terminal.
5
Connecting the center and surround speakers
AV Receiver
To surround
right speaker
(4)
Connect the center speaker (5) and surround speaker (3+4) cables to the AV Receiver.
Be sure to connect the colored wire to the red positive (+) terminal, and connect the other
wire to the black negative (–) terminal.
6
Connecting the subwoofer
AV Receiver
Use the included subwoofer cable to connect the Subwoofer's INPUT jack to the AV
Receiver's SUBWOOFER OUTPUT jack.
7
Connecting the antennas
AV Receiver
+
4 ), and
Connect the AM loop antenna and indoor FM antenna to the AV Receiver, as shown. See
the owner's manuals for more information about connecting antennas.
Part B: AV Components
UCRAGLE
Caution: Disconnect all components from AC outlets before proceeding.
© 2009 Yamaha Corporation All rights reserved.
Printed in China
WR88920
1
Connecting your TV
AV Receiver
To front left
Use a video pin cable (not included) to connect the AV Receiver's MONITOR OUT jack to
To front right
speaker (1)
a composite video input on your TV, as shown.
speaker (2)
2
Connecting your DVD player
AV Receiver
ANTENNA
OUT
DVD
DTV/CBL
DOCK
COMPONENT VIDEO
HDMI
DVD
DTV/CBL
DVR
OUT
MONITOR
AM
P
R
GND
DIGITAL INPUT
VIDEO
P
B
DVD
DTV/CBL
IN
DVR
OUT
MONITOR
OUT
FM
OPTICAL
UNBAL.
Y
CD
MULTI CH INPUT
DVD
DTV/CBL
DVR
AUDIO
CD
IN
MD/
DTV/
FRONT
SURROUND
CENTER
IN
OUT
(PLAY)
CD-R
CBL
DVD
COAXIAL
SUBWOOFER
To center
• Use a video pin cable (not included) to connect your DVD player's composite video
speaker (5)
output to the AV Receiver's DVD VIDEO jack, as shown.
• Use a coaxial digital audio cable (not included) to connect your DVD player's coaxial
To surround
digital audio output to the AV Receiver's DVD DIGITAL INPUT jack, as shown.
left speaker (3)
3
Connecting your satellite/cable set-top box
AV Receiver
ANTENNA
OUT
DVD
DTV/CBL
HDMI
DOCK
DVD
COMPONENT VIDEO
DTV/CBL
DVR
MONITOR
OUT
AM
P
R
GND
DIGITAL INPUT
VIDEO
P
B
DVD
DTV/CBL
DVR
MONITOR
FM
IN
OUT
OUT
OPTICAL
UNBAL.
CD
Y
MULTI CH INPUT
AUDIO
DTV/
FRONT
SURROUND
CENTER
DVD
DTV/CBL
IN
DVR
OUT
CD
(PLAY)
IN
CD-R
MD/
CBL
DVD
COAXIAL
SUBWOOFER
Subwoofer (6)
Use an AV pin cable (not included) to connect your satellite/cable set-top box to the AV
Receiver's DTV/CBL jacks, as shown.
4
Connecting HDMI-capable components
AV Receiver
ANTENNA
OUT
DVD
DTV/CBL
DOCK
COMPONENT VIDEO
HDMI
DVD
DTV/CBL
DVR
MONITOR
OUT
AM
P
R
GND
DIGITAL INPUT
P
VIDEO
B
DVD
DTV/CBL
IN
DVR
OUT
MONITOR
OUT
FM
OPTICAL
UNBAL.
Y
CD
MULTI CH INPUT
DVD
DTV/CBL
DVR
AUDIO
CD
IN
CBL
DTV/
FRONT
SURROUND
CENTER
IN
OUT
(PLAY)
CD-R
DVD
COAXIAL
SUBWOOFER
TV
AM antenna
FM antenna
If your TV and DVD player or satellite/cable set-top box have HDMI jacks, you can
connect them via the AV Receiver. Using HDMI cables (not included), connect the AV
Receiver's HDMI OUT jack to an HDMI input on your TV, and connect your DVD player
(FM antenna type depends
on destination country.)
and satellite/cable set-top box to the AV Receiver's DVD and DTV/CBL HDMI jacks,
respectively, as shown.
Note: Audio signals received by the HDMI inputs will be output by the HDMI-capable TV's
speakers, not the speakers connected to the AV Receiver. To listen to an HDMI-capable
component through the AV Receiver's speakers, you must make an analog or digital audio
connection in addition to the HDMI connection, and mute the sound on the TV.
See the owner's manuals for more information about HDMI.
5
TV
VIDEO
6
DVD player
SPEAKERS
SURROUND
SURROUND
CENTER
FRONT B
OUT
OUTPUT
(REC)
SUB
WOOFR
FRONT A
7
Satellite/cable set-top box
SPEAKERS
SURROUND
CENTER
FRONT B
OUTPUT
OUT
(REC)
SUB
WOOFR
FRONT A
8
SPEAKERS
SURROUND
SURROUND
CENTER
FRONT B
MD/
OUT
OUTPUT
(REC)
WOOFR
SUB
FRONT A
DVD player
Satellite/cable set-top box
Almost Finished
• Connect the AV Receiver, Subwoofer, and your other AV components to suitable AC outlets.
• Turn on the AV Receiver first, then the Subwoofer and your other AV components.
• Install the batteries in the AV Receiver's remote control.
• See the relevant owner's manuals for full operating instructions.
Time to enjoy your Yamaha home theater system!
Now, relax and enjoy the great sound of your Yamaha home theater system.
Connecting your DVR/VCR
AV Receiver
DVR/VCR
ANTENNA
SPEAKERS
OUT
DVD
DTV/CBL
SURROUND
CENTER
FRONT B
HDMI
DOCK
DVD
COMPONENT VIDEO
DTV/CBL
DVR
MONITOR
OUT
AM
P
R
GND
DIGITAL INPUT
VIDEO
P
B
DVD
DTV/CBL
DVR
MONITOR
FM
IN
OUT
OUT
OPTICAL
UNBAL.
CD
Y
MULTI CH INPUT
AUDIO
OUTPUT
DTV/
FRONT
SURROUND
CENTER
DVD
DTV/CBL
IN
DVR
OUT
CD
(PLAY)
IN
MD/
CD-R
OUT
(REC)
CBL
SUB
WOOFR
DVD
COAXIAL
SUBWOOFER
FRONT A
Use AV pin cables (not included) to connect your DVR (digital video recorder) or VCR to
the AV Receiver's DVR IN/OUT jacks, as shown.
Connecting your CD player
AV Receiver
CD player
ANTENNA
SPEAKERS
SURROUND
SURROUND
CENTER
FRONT B
OUT
DVD
DTV/CBL
DOCK
COMPONENT VIDEO
HDMI
DVD
DTV/CBL
DVR
MONITOR
OUT
AM
P
R
GND
DIGITAL INPUT
B
P
VIDEO
DVD
DTV/CBL
IN
DVR
OUT
MONITOR
OUT
FM
OPTICAL
UNBAL.
CD
Y
MULTI CH INPUT
DVD
DTV/CBL
DVR
AUDIO
CD
IN
MD/
OUT
OUTPUT
CBL
DTV/
FRONT
SURROUND
CENTER
IN
OUT
(PLAY)
CD-R
(REC)
WOOFR
SUB
DVD
COAXIAL
SUBWOOFER
FRONT A
Use an audio pin cable (not included) to connect your CD player to the AV Receiver's CD
jacks, as shown.
Connecting your MD/CD recorder
AV Receiver
MD/CD recorder
ANTENNA
SPEAKERS
SURROUND
SURROUND
CENTER
FRONT B
OUT
DVD
DTV/CBL
DOCK
COMPONENT VIDEO
HDMI
DVD
DTV/CBL
DVR
MONITOR
OUT
AM
R
P
GND
DIGITAL INPUT
VIDEO
P
B
DVD
DTV/CBL
IN
DVR
OUT
MONITOR
OUT
FM
OPTICAL
UNBAL.
Y
CD
MULTI CH INPUT
DVD
DTV/CBL
DVR
AUDIO
CD
IN
MD/
OUT
OUTPUT
DTV/
CBL
FRONT
SURROUND
CENTER
IN
OUT
(PLAY)
CD-R
(REC)
WOOFR
SUB
DVD
COAXIAL
SUBWOOFER
FRONT A
Use audio pin cables (not included) to connect your MD/CD player to the AV Receiver's
MD/CD-R IN/OUT jacks, as shown.
Connecting your portable music player
AV Receiver
Portable music player
VOLUME
SPEAKERS
PRESET/TUNING
EDIT
A/B/C/D/E
l
PRESET/TUNING
BAND
MEMORY
TUNING AUTO/MAN'L
h
SCENE
1
2
3
4
PHONES
TONE CONTROL
PROGRAM
STRAIGHT
INPUT
NIGHT
VIDEO AUX
STANDBY
/ON
l
h
l
h
SILENT CINEMA
EFFECT
VIDEO
AUDIO
PORTABLE
VIDEO AUX
VIDEO
AUDIO
PORTABLE
Use a 3.5 mm stereo mini plug cable (not included) to connect your portable music player
to the AV Receiver's PORTABLE jack (on the front panel), as shown.
If your AV Receiver has a DOCK jack (U.S.A. and Canada models), you can
connect a Yamaha Universal Dock for iPod, such as the YDS-11, or a Yamaha
Bluetooth Wireless Audio Receiver, such as the YBA-10 (both sold separately). See
the AV Receiver's Owner's Manual for more information.
