Operating Instructions
LCD Television
Contents
Be Sure to Read
Important Notice ·················································2
Safety Precautions ·············································3

Quick Start Guide

Accessories ························································6
Connections························································8
Identifying Controls ···········································14
First time Auto Setup ········································16
Using your VIERA
Operations ························································18
How to Use eHELP ···········································19
Viewing 3D images ···········································20
Others
FAQs·································································20
Maintenance ·····················································21
Specifications ···················································21
Thank you for purchasing this Panasonic product.
Please read these instructions carefully before operating this product and
retain them for future reference.
The images shown in this manual are for illustrative purposes only.
Please refer to Pan European Guarantee Card if you need to contact your
local Panasonic dealer for assistance.
TX-L42DT60Y TX-L55DT60Y
TX-L47DT60Y TX-L60DT60Y
TX-L50DT60Y
For more detailed instructions, refer to [eHELP]
(Built-in Operating Instructions).
●
How to use [eHELP]
(p. 19)
Model No.
TQB0E2338P2

Advertisement

Chapters

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TX-L60DT60Y and is the answer not in the manual?

Questions and answers

Related Manuals for Panasonic TX-L60DT60Y

Summary of Contents for Panasonic TX-L60DT60Y

  • Page 1: Table Of Contents

    Specifications ···················································21 How to use [eHELP] (p. 19) Thank you for purchasing this Panasonic product. Please read these instructions carefully before operating this product and retain them for future reference. The images shown in this manual are for illustrative purposes only.

  • Page 2: Important Notice

    Panasonic has no authority to and does not grant you that permission and explicitly disclaims any right, ability or intention to obtain such permission on your behalf.

  • Page 3: Safety Precautions

    ● Do not use an unapproved pedestal / mounting equipment. Be sure to ask your local Panasonic dealer To help avoid risk of electrical shock, fire, damage or to perform the setup or installation of approved wall- injury, please follow the warnings and cautions below: hanging brackets.
  • Page 4 Do not use the pedestal if it becomes warped or LAN devices, other Bluetooth devices, microwaves, physically damaged. If this occurs, contact your nearest mobile phones and the devices that use 2.4 GHz signal. Panasonic dealer immediately. ● ■ During setup, make sure that all screws are securely Ventilation tightened.
  • Page 5 LCD Television Declaration of Conformity (DoC) “Hereby, Panasonic Corporation declares that this TV is in compliance with the essential requirements and other relevant provisions of the Directive 1999/5/EC.” If you want to get a copy of the original DoC of this TV, please visit the following website: http://www.doc.panasonic.de...

  • Page 6: Accessories

    Accessories Remote Control VIERA Touch Pad Pedestal Controller (see below) (p. 14) (p. 15) ● N2QAYB000842 42-inch model 60-inch model ● N2QBYB000027 47-inch model 50-inch model 55-inch model Mains lead Batteries (4) 3D Eyewear (4) Cable tie (p. 9) ● (p.
  • Page 7 ■ Assembling the pedestal 42-inch model 50-inch model 60-inch model 47-inch model 55-inch model Secure the base as shown below to prevent the TV from falling over. ● The place where the base is secured should be thick enough and made of hard material. Commercially available screw (not supplied) Diameter: 3 mm...

  • Page 8: Connections

    ■ Adjusting the panel to your desired angle 42-inch model 47-inch model 50-inch model 55-inch model ● Do not place any objects within the full rotation range. 15° 15° (View from the top) Removing the pedestal from the TV Be sure to remove the pedestal in the following way when using the wall-hanging bracket or repacking the TV. 1 Remove the assembly screws from the cover.
  • Page 9 Basic connections ● To ensure your satellite dish or aerial is correctly installed, please consult your local dealer. Also please consult the received broadcasting companies for details. Mains lead and aerial ■ DVB-C, DVB-T, Analogue Terrestrial aerial Cable RF cable Mains lead ■...
  • Page 10 AV devices ■ DVD Recorder / VCR Terrestrial aerial SCART cable DVD Recorder / VCR Cable AV1 (SCART) adaptor (supplied) RF cable RF cable ■ DVD Recorder / VCR and Set top box Cable Set top box HDMI cable Terrestrial aerial SCART cable SCART cable AV1 (SCART)
  • Page 11 Other connections ■ DVD player (COMPONENT equipment) (Listening) DVD Player (Viewing) AV2 (COMPONENT / VIDEO) adaptor (supplied) ■ Camcorder / Game equipment (VIDEO equipment) (Listening) Camcorder (Viewing) Game equipment AV2 (COMPONENT / VIDEO) adaptor (supplied) ■ Amplifier (to listen with speakers) HDMI cable Amplifier with External equipment...

  • Page 12: Common Interface

    ■ Headphones ● To adjust volume [Headphone Volume] in the Sound Menu (M3 stereo mini plug) ■ Common Interface ● If a view card and a card reader come as a set, first insert the card reader, then insert the view card into the card reader. ●...
  • Page 13 Using the cable tie and cable clamp (supplied) ● Do not bundle the Satellite cable, RF cable and mains lead together (could cause distorted image). ● Fix cables with the cable tie and cable clamp as necessary. ● When using the optional accessory, follow the option’s assembly manual to fix cables. Attach the cable tie Bundle the cables hole...

  • Page 14: Identifying Controls

    Identifying Controls Remote Control ● Confirms selections and choices. ● Press after selecting channel positions to quickly change channel. ● Displays the Channel List. [Option Menu] ● Easy optional setting for viewing, sound, etc. Coloured buttons (red-green-yellow-blue) ● Used for the selection, navigation and operation of various functions.
  • Page 15 VIERA Touch Pad Controller This touch pad controller is designed for the convenient operations, especially, on Home Screen or internet contents. You can operate the TV intuitively with this controller. ● The touch pad controller can be used by registering to this TV with Bluetooth wireless technology. Setup screen to register will appear in “First time Auto Setup”...

  • Page 16: First Time Auto Setup

    Indicator / Control panel ● When pressing 1, 2, 3 buttons, the control panel guide appears on the right side of the screen for 3 seconds to highlight the pressed button. Channel Up / Down Cursor Up / Down (when in the menu system) Volume Up / Down Cursor Left / Right (when in the menu system) Mains power On / Off switch...
  • Page 17 Plug the TV into mains socket and turn power on ● Takes a few seconds to be displayed. Select the following items Set up each item by following the on-screen instructions. Select the language Select [Home] Select [Home] viewing environment to use in your home environment. ●...

  • Page 18: Operations

    Operations Turn power on ● Mains power On / Off switch should be on. (p. 16) (TV) (Remote Control) The last viewed [Home Screen] is displayed. Example: [TV Home Screen] Example: Selected content screen ● To return to [Home Screen] at any time ●...

  • Page 19: How To Use Ehelp

    How to Use eHELP [eHELP] is the detailed operating instructions built into the TV, and helps you to get more understanding of the operations for each feature. Display [eHELP] [Help] [eHELP] ● [Read first] will be displayed on the top page. Please read these instructions fully to get more understanding of the operation in [eHELP].

  • Page 20: Viewing 3D Images

    3D-supported broadcast ● Please consult the suppliers of contents or programmes for availability of this service. ■ 3D photos and 3D videos taken by 3D-compatible Panasonic products ● Available in Media Player and Network services. ■ 2D images converted to 3D ●...

  • Page 21: Maintenance

    No image can be displayed ● Check the TV is turned on. ● Check the mains lead is plugged into the TV and the socket outlet. ● Check the correct input mode is selected. ● Check the setting of [AV2] ([COMPONENT] / [VIDEO]) in [Input Selection] to match the output of the external equipment.
  • Page 22 55-inch model 60-inch model Model No. TX-L55DT60Y TX-L60DT60Y 1,238 mm × 810 mm × 280 mm 1,368 mm × 892 mm × 309 mm (With Pedestal) (With Pedestal) Dimensions (W × H × D) 1,238 mm × 724 mm × 35 mm 1,368 mm ×...
  • Page 23 This equipment complies with the EMC standards listed below. EN55013, EN61000-3-2, EN61000-3-3, EN55020, EN55022, EN55024 ■ When using the wall-hanging bracket ● Please contact your local Panasonic dealer to purchase the recommended wall-hanging bracket. ● Holes for wall-hanging bracket Depth of screw installation...
  • Page 24 Warranty Service purposes. Model Number Serial Number M0213-0 TQB0E2338U Web Site: http://panasonic.net © Panasonic Corporation 2013 Printed in Czech Republic...
  • Page 25 Specifikationer ··················································21 Sådan bruges [eHJÆLP] (s. 19) Tak, fordi du har valgt at købe dette Panasonic-produkt. Læs denne betjeningsvejledning omhyggeligt, inden du begynder at anvende dit apparat og gem den til fremtidig konsultation. De i denne betjeningsvejledning viste illustrationer er kun til illustrationsformål.

  • Page 26: Vigtig Information

    (Kun på engelsk) http://panasonic.net/viera/support Panasonic giver ingen garanti for driften og ydeevnen af periferiske enheder, der er fremstillet af andre producenter, og vi fraskriver os ethvert ansvar eller en enhver beskadigelse opstået i forbindelse med drift og/eller ydeevne fra brugen af sådanne periferiske...

  • Page 27: Sikkerhedsforanstaltninger

    ● Kom ikke nogen genstande ind i tv’et gennem luftventilerne. ● Brug udelukkende en godkendt sokkel eller monteringsbeslag. Husk at bede din lokale Panasonic- Sikkerhedsforanstaltninger forhandler om at udføre opsætning eller montering af godkendte vægbeslag. ● Du må ikke bruge for megen styrke eller berøre For at undgå...
  • Page 28 Bluetooth-enheder, mikrobølgeovne, mobiltelefoner og eller på anden måde bliver defekt. Hvis dette skulle enheder, der bruger signaler på 2,4 GHz. forekomme, bedes du omgående kontakte den ■ nærmeste Panasonic-forhandler. Ventilation ● Sørg under opsætningen for, at alle skruer er forsvarligt Forsigtig strammede.
  • Page 29 LCD-fjernsyn Overensstemmelseserklæring (DoC) “Herved erklærer Panasonic Corporation, at dette fjernsyn opfylder de væsentlige krav og andre relevante forskrifter i Direktivet 1999/5/EF.” Hvis du ønsker en kopi af det originale DoC-dokument for dette fjernsyn, kan du finde den på følgende hjemmeside: http://www.doc.panasonic.de...

  • Page 30: Tilbehør

    Tilbehør Fjernbetjening VIERA Touch Pad Sokkel controller (se herunder) (s. 14) (s. 15) ● N2QAYB000842 42 tommers model 60 tommers model ● N2QBYB000027 47 tommers model 50 tommers model 55 tommers model Netledning Batterier (4) 3D-briller (4) Kabelbinder (s. 9) ●...
  • Page 31 ■ Samling af soklen 42 tommers model 50 tommers model 60 tommers model 47 tommers model 55 tommers model Fastgør soklen, som vist herunder, for at forhindre at fjernsynet vælter. ● Det sted hvor soklen fastgøres, bør være tykt nok og lavet af et hårdt materiale. Kommercielt tilgængelig skrue (ikke leveret) Diameter: 3 mm...

  • Page 32: Forbindelser

    ■ Indstil panelet til den ønskede vinkel 42 tommers model 47 tommers model 50 tommers model 55 tommers model ● Anbring ikke hænderne eller genstande inden for det fulde rotationsområde. 15° 15° (Vist fra oven) Afmontering af soklen fra tv’et Sørg for at afmontere soklen på...
  • Page 33 Grundlæggende tilslutning ● For at sikre at din parabolantenne eller antenne er korrekt installeret, bedes du kontakte din lokale forhandler. Kontakt også venligst virksomhederne for de modtagne udsendelser for detaljerede oplysninger. Netledning og antenne ■ DVB-C, DVB-T, Analog Jordbaseret antenne Kabel RF-kabel Netledning...
  • Page 34 AV-enheder ■ DVD-optager / videobåndoptager Fjernsyn Jordbaseret antenne DVD-optager / SCART-kabel videobåndoptager Kabel AV1 (SCART) adapter (medfølger) RF-kabel RF-kabel ■ DVD-optager / videobåndoptager og Sæt-topboks Fjernsyn Kabel Sæt-topboks HDMI-kabel Jordbaseret antenne SCART-kabel SCART-kabel AV1 (SCART) adapter (medfølger) RF-kabel DVD-optager / RF-kabel videobåndoptager Netværk...
  • Page 35 Andre forbindelser ■ DVD-afspiller (COMPONENT-udstyr) Fjernsyn (Lytte) DVD-afspiller (Se) AV2 (COMPONENT / VIDEO) adapter (medfølger) ■ Videokamera / spiludstyr (VIDEO-udstyr) Fjernsyn (Lytte) Videokamera (Se) Spiludstyr AV2 (COMPONENT / VIDEO) adapter (medfølger) ■ Forstærker (lytning med højtalere) Fjernsyn HDMI-kabel Forstærker med Eksternt udstyr højttalersystem (DVD-afspiller osv.)
  • Page 36 ■ Hovedtelefoner Fjernsyn ● Regulering af lydstyrken [Hovedtlf. Styrke] i menuen Lyd (M3 stereo-ministik) ■ Almindeligt interface Fjernsyn ● Hvis et visningskort og en kortlæser findes som et sæt, skal man først sætte visningskortet ind i kortlæseren. ● Sæt modulet ind i den rigtige retning. CI-modul Typer af udstyr, der kan sluttes til hver terminal Terminal...
  • Page 37 Ved brug af kabelbinderen og kabelklemmen (medfølger) ● Undlad at binde satellitkablet, RF-kablet og netledningen sammen (det kan forårsage forvrænget billede). ● Fastgør kabler med kabelbinderen og kabelklemme som nødvendigt. ● Følg ekstraudstyrets samlingsvejledning for at fastgøre kabler, når du anvender ekstraudstyr. Påsæt kabelbinderen Bind kablerne sammen Sæt kabelbinderen...

  • Page 38: Kontakternes Betegnelse

    Kontakternes betegnelse Fjernbetjening ● Bekræfter valg og beslutninger. ● Tryk efter valg af kanalpositioner for hurtigt at skifte kanal. ● Viser kanallisten. [Alternativmenu] ● Nem valgfri indstilling til visning, lyd, osv. Farvede knapper (rød-grøn-gul-blå) ● Anvendes til valg, navigation og anvendelse af forskellige funktioner.
  • Page 39 VIERA Touch Pad controller Denne touch pad controller er designet til at give dig nem betjening af især Startskærmen eller internetindhold. Med denne controller kan du betjene fjernsynet intuitivt. ● Denne touch pad controller kan bruges ved at registrere den til dette fjernsyn med trådløs Bluetooth-teknologi. Opsætningsskærmen for registrering vil vises i “Første autoopsætning”, første gang fjernsynet bruges.

  • Page 40: Første Autoopsætning

    Indikator / Kontrolpanel ● Når du trykker på 1, 2, 3-knapperne, fremkommer kontrolpanelguiden på højre side af skærmen i 3 sekunder og viser den knap, der blev trykket på. Lydstyrke op / ned Cursor Venstre/Højre (når du befinder dig i menusystemet) Tænd / sluk-knap (hovedafbryder) ●...
  • Page 41 Slut fjernsynet til stikkontakten i væggen og tænd ● Det varer et par sekunder, inden visningen kommer frem. Vælg følgende punkter Opsæt hvert af følgende punkter ved at følge vejledningen på skærmen. Vælg sproget Vælg [Hjemme] Vælg visningsmiljøet [Hjemme] for at anvende det hjemme hos dig selv. ●...

  • Page 42: Betjeninger

    Betjeninger Tænd ● Tænd / sluk-knap skal være tændt. (s. 16) eller (TV) (Fjernbetjening) Den sidst sete [Startskærm] vises. Eksempel: [TV-startskærm] Eksempel: Valgt indholdsskærm ● For til enhver tid at gå tilbage til [Startskærm] ● Du kan opsætte eller få [Startskærm] til at vise ønskede oplysninger, for nemt at få adgang til bestemte funktioner, for at vælge standarden [Startskærm], etc.

  • Page 43: Betjening Ehjælp

    Betjening eHJÆLP [eHJÆLP], der er indbygget i dit tv, hjælper dig med at få et bedre kendskab til de forskellige funktioner. Vis [eHJÆLP] eller [Hjælp] [eHJÆLP] ● [Læs først] fremkommer øverst på siden. Læs venligst denne vejledning omhyggeligt igennem for at få en bedre forståelse for betjeningen i [eHJÆLP].

  • Page 44: Visning Af 3D-Billeder

    ■ 3D-understøttet udsendelse ● Kontakt venligst udbyderne af programindholdet for information om tilgængeligheden af denne service. ■ 3D-billeder og 3D-videoer, der er optaget vha. 3D-kompatible Panasonic-produkter ● Tilgængeligt i Medieafspiller og netværkstjenester. ■ 2D-billeder, der er konverteret til 3D ●...

  • Page 45: Vedligeholdelse

    Der kan ikke vises noget billede ● Kontroller at fjernsynet er tændt. ● Kontroller at netledningen er sat i fjernsynet og stikkontakten. ● Kontrollér at den korrekte indgangstilstand er valgt. ● Kontrollér indstillingen af [AV2] ([COMPONENT] / [VIDEO]) i [Inputvalg] for at matche udgangssignalet fra det eksterne udstyr.
  • Page 46 55 tommers model 60 tommers model Modelnr. TX-L55DT60Y TX-L60DT60Y 1.238 mm × 810 mm × 280 mm 1.368 mm × 892 mm × 309 mm (Med sokkel) (Med sokkel) Mål (B × H × D) 1.238 mm × 724 mm × 35 mm 1.368 mm ×...
  • Page 47 Dette udstyr er i overensstemmelse med de herunder angivne EMC standarder. EN55013, EN61000-3-2, EN61000-3-3, EN55020, EN55022, EN55024 ■ Når du bruger vægbeslaget ● Kontakt venligst din nærmeste Panasonic-forhandler for at købe det anbefalede vægbeslag. ● Huller til installation af vægbeslag Dybde af skrue minimum: 6 mm...
  • Page 48 Modelnummer Serienummer M0213-0 TQB0E2338K Web Site: http://panasonic.net © Panasonic Corporation 2013 Trykt i Tjekkiet...
