EPS Bio Technology EasyPlus mini 2IN1 Quick Reference Manual

Hide thumbs Also See for EasyPlus mini 2IN1:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
EasyPlus mini 2IN1
Self-Monitoring Blood Glucose System

Quick Reference Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EasyPlus mini 2IN1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EPS Bio Technology EasyPlus mini 2IN1

Summary of Contents for EPS Bio Technology EasyPlus mini 2IN1

  • Page 1: Quick Reference Guide

    EasyPlus mini 2IN1 Self-Monitoring Blood Glucose System Quick Reference Guide...

  • Page 2: Installing Batteries

    Installing Batteries 1. Flip open the battery door by pushing the tab in the direction of the arrow and pulling the door up. 2. Insert a battery. 3. Put the battery door back in place and snap it closed. The meter beeps and turns on automatically.

  • Page 3: Setting The Time And Date-First Time Use

    Setting The Time and Date—First Time Use Setting the current time and date in your meter is important if you intend to use the meter memory or if you want to download your results to a computer. 1. If your meter does not turn on automatically, press for 3 seconds to turn on the meter.

  • Page 4: Running A Control Solution Test

    Running A Control Solution Test You need the meter, a test strip, and control solution. 1. Put a test strip into the meter in the direction of the arrow. 2. The meter beeps and turns on automatically. The icon shows itself. 3.
  • Page 5 6. Squeeze the bottle until a tiny drop forms at the tip of the bottle. 7. Touch the drop to the blood collection area at the tip of the test strip. When you hear beeps, you have enough control solution in the test strip.
  • Page 6 Inserting A Lancet Into The Built-in Lancing Device You must first load the lancet into the lancing device to get it ready for use. 1. Unscrew the Cap. 2. Insert a new disposable lancet firmly into the carrier and then twist off the protective cover.
  • Page 7 3. Recap the front cap. 4. Select the desired penetration depth. Select 1-2 for thick or calloused skin. 3 for average. 4-5 for soft or thin skin.
  • Page 8 5. Pull on the cocking button of the lancing device until it clicks and then release. Now the lancing device is ready. Do not prick your finger until your meter and strip are prepared. 6. Set the lancing device aside until later in the test.

  • Page 9: Running A Blood Glucose Test With Blood From Your Fingertip

    Running A Blood Glucose Test With Blood From Your Fingertip 1. Wash your hands with soap and warm water. Rinse and dry thoroughly. Put a test strip into the meter in the direction of the arrow. The meter beeps and turns on automatically. 3.
  • Page 10 5. Gently squeeze and/or massage your fingertip until a round drop of blood on your fingertip. 6. Touch the blood drop at the tip of the transparent window of the test strip. Do not put blood on top of the strip. When you hear beeps, you have enough blood in the test strip.

  • Page 11: Discarding Used Lancets

    Discarding Used Lancets 1. Unscrew and remove the cap. Without 2. Discard the used disposable lancet touching the used lancet, stick the into an appropriate sharps or lancet tip into its protective cover. Grip biohazard container. the lancet carrier firmly and pull the lancet safely out.

  • Page 12: Viewing & Deleting Test Results

    Viewing & Deleting Test Results 1. Press to turn the meter on. 2. Press to view averages for 7/14/30 days. 3. Continue to press to view the test result from latest to oldest.
  • Page 13 4. To delete a test result, press for 3 seconds. When display shows "dEL", press to confirm the deletion. Or press to cancel the deletion and go back to the total number of the stored results. 5. Press for 1 second to go back to the total number of the stored results.

  • Page 14: Screen Messages And Troubleshooting

    Screen Messages And Troubleshooting Never make treatment decisions based on an error message. If you have any concerns, please contact your healthcare professional. What it means ? What to do ? System err. Please replace the batteries first. If Err appears again, please contact your healthcare professional immediately.
  • Page 15 What it means ? What to do ? Memory err. Please replace the batteries first. If Err appears again, please contact your healthcare professional immediately. Low power. Please replace with a new battery.
  • Page 16 What it means ? What to do ? You may have a very high Please test again and if you blood glucose level(severe get the same result, please hypoglycemia), over 630 contact your healthcare mg/dL. professional immediately. You may have a very low Please test again and if you blood glucose level(severe get the same result, please...
  • Page 17 What it means ? What to do ? Temperature is too high, Relocate the meter to a outside the required range of location with temperature 10°C - 40°C (50°F - 104°F). between 10°C - 40°C This alerts users that an (50°F - 104°F).
  • Page 18 Manufacturer: EPS Bio Technology Corp. No.8, R&D RD III, Hsinchu Science Park, Hsinchu, Taiwan 30077 Tel: +886-3-6686868 Fax: +886-3-6686866 E-mail: info@epsbio.com.tw Website: http://www.epsbio.com.tw Obelis s.a. Boulevard Général Wahis 53, 1030 Brussels, BELGIUM TEL：(32) 2.732.59 54 FAX：(32) 2.732.60 03 E-mail: mail@obelis.net...
