Summary of Contents for Makita DA3000R
- Page 1 Angle Drill MODEL DA3000R MODEL DA3000V 003004 DOUBLE INSULATION I N S T R U C T I O N M A N U A L WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
-
Page 2: Specifications
8JD, ENGLAND tic. Responsible manufacturer: Power supply Makita Corporation Anjo Aichi Japan The tool should be connected only to a power supply of the same voltage as indicated on the nameplate, and can only be operated on single-phase AC supply. They... -
Page 3: General Safety Rules
GENERAL SAFETY RULES GEA001-3 WARNING: Read all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. The term “power tool” in all of the warnings listed below refers to your mains-operated (corded) power tool or battery- operated (cordless) power tool. -
Page 4: Specific Safety Rules
19. Store idle power tools out of the reach of chil- the manner intended for the particular type of dren and do not allow persons unfamiliar with power tool, taking into account the working con- the power tool or these instructions to operate ditions and the work to be performed. -
Page 5: Functional Description
1. Speed control screw 2. Switch lever (paddle switch) Reversing switch action For Model DA3000R only 003026 This tool has a reversing switch to change the rotational direction. Turn the reversing switch knob so that its protrusion will point to... - Page 6 A stuck bit can be removed simply by setting the reversing switch to reverse rotation in order to back out. However, the tool may back out abruptly if you do not hold it firmly. (For Model DA3000R) • Always secure small workpieces in a vise or similar hold-down device.
-
Page 7: Maintenance
CAUTION: • These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose. - Page 8 Makita Corporation Anjo, Aichi, Japan 883327C227...
