Solus HEMI 36 Installation And Operation Manual

W/ ethanol burner
Hide thumbs Also See for HEMI 36:
Table of Contents

Advertisement

Quick Links

Download this manual
Fire Features
HEMI 36 w/ ETHANOL BURNER
Table of Contents:
1.
Title page.
2.
General Safety Warnings.
3.
Diagram (exploded).
4.
Important Safety Information,
5.
Location and Clearance Requirements.
6.
Location and Clearance Requirements.
7.
Safety Markings.
8.
Clearance to Combustible Surfaces.
9.
Equipment & Accessories Provided.
10.
Equipment & Accessories Provided.
11.
Installation & Assembly.
12.
Filling, Lighting & Extinguishing.
13.
Extinguishing & Refueling.
14.
Maintenance & Care.
15.
Maintenance & Care.
16.
Limited Warranty.
17.
Limited Warranty.
INSTALLATION & OPERATION MANUAL.
WARNING!
Failure to follow instructions may result in serious injury, destruction of property or loss of life
Do NOT re-fill while
Do NOT re-fill while
1
burner unit is still hot!
burner unit is burning!
Fuel may ignite!
Explosion may result!
Keep children away
DANGER FLAMABLE!
from burner! Even
when no flame present,
FOR OUTDOOR USE ONLY.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HEMI 36 and is the answer not in the manual?

Questions and answers

Related Manuals for Solus HEMI 36

Summary of Contents for Solus HEMI 36

  • Page 1 Fire Features INSTALLATION & OPERATION MANUAL. HEMI 36 w/ ETHANOL BURNER Table of Contents: Title page. General Safety Warnings. Diagram (exploded). Important Safety Information, Location and Clearance Requirements. Location and Clearance Requirements. Safety Markings. Clearance to Combustible Surfaces. Equipment & Accessories Provided.
  • Page 2 Fire Features INSTALLER: Leave this manual with the appliance. HEMI 36 w/ ETHANOL BURNER CONSUMER: Retain this manual for future reference. Table of Contents: WARNING: Title page. General Safety Warnings. Read and understand Installation & User Manual and all safety instructions before use.
  • Page 3 Fire Features HEMI 36 w/ ETHANOL BURNER EXPLODED DIAGRAM Table of Contents: Title page. General Safety Warnings. Diagram (exploded). Important Safety Information, Location and Clearance Requirements. Location and Clearance Requirements. Safety Markings. Clearance to Combustible Surfaces. Equipment & Accessories Provided.
  • Page 4 Fire Features HEMI 36 w/ ETHANOL BURNER IMPORTANT SAFETY INFORMATION, LOCATION & CLEARANCE REQUIREMENTS. Please carefully follow the instructions in this manual to prevent personal injury or property loss. Instructions are updated periodi- cally. It is the installers and users responsibility to periodically re-review these instruction and check online for applicable updates  at www.solusdecor.com Table of Contents: WARNING: Explosion and Fire Hazard! Title page.
  • Page 5 Limited Warranty. 30 minutes before refueling. Failure to do so may result in the outcomes listed above. + Solus Decor is not liable for any damage to person or property due to incorrect or inappropriate fuel usage, fuel storage or re-fuelling.

  • Page 6: Table Of Contents

    Fire Features HEMI 36 w/ ETHANOL BURNER WARNING: Ignition and Operation of the Appliance. ***FLAME WILL "WHOOSH" UP EVERY TIME THE FIRE FEATURE IS LIGHT ! KEEP FACE AWAY *** + ALWAYS USE THE LIGHTING WAND TO IGNITE THE APPLIANCE. Fumes start to accumulate as soon as the...

  • Page 7: Title Page

    Fire Features HEMI 36 w/ ETHANOL BURNER SAFETY MARKINGS You will find these safety markings on the top plate of your burner unit and Damper. Please heed them carefully and do not obstruct them. If someone unfamiliar with these safety basic instruction tries to operate the unit and does not see them, they may cause harm to themselves, property or others.

  • Page 8: General Safety Warnings

    Fire Features HEMI 36 w/ ETHANOL BURNER CLEARANCE TO COMBUSTIBLE SURFACES The burner in this fire feature is very powerful and designed to burn at 60,000 BTU (17.5 KWh). Please ensure that you locate and position your fire pit following these guidelines.

  • Page 9: Diagram (Exploded

    Fire Features HEMI 36 w/ ETHANOL BURNER EQUIPMENT AND ACCESSORIES PROVIDED The fire feature includes the following equipment . Use all the pieces provided for safe operation of this appliance. Substituting or altering any of the parts may void warranty.

  • Page 10: Important Safety Information

    Fire Features HEMI 36 w/ ETHANOL BURNER (continued) 11 Damper. Always keep the Damper close by so that you can extinguish the flame quickly if needed. Leave the Damper in place when the fire is not in use to prevent premature evaporation of fuel.

  • Page 11: Location And Clearance Requirements

    Fire Features HEMI 36 w/ ETHANOL BURNER ASSEMBLY 1. Place metal Support Box in center of vessel. Open end up with scalloped end down. 2. Place Safety Drip Bowl on top and in center of Support Box. Table of Contents: 3.

  • Page 12: Location And Clearance Requirements

    Fire Features HEMI 36 w/ ETHANOL BURNER FILLING, LIGHTING & EXTINGUISHING Generally, we have found that 3 litres (3/4 gallon) of fuel will burn for about 1-1/2 hours in a draft free area. The last 10-15 minutes of this time will exhibit weaker flames. If you have installed your fire feature in a breezy or windy area expect to have a shorter burn time.

  • Page 13: Safety Markings

    Fire Features HEMI 36 w/ ETHANOL BURNER EXTINGUISHING 1. Make sure there is a tight fit of the Damper to the Burner Unit. Any impediments will allow air flow into the chamber rendering the Damper useless. Table of Contents: 2. To snuff out the flame, just place the Damper over the burn chamber and leave for 5 minutes. This will ensure that any flame is extinguished.

  • Page 14: Clearance To Combustible Surfaces

    Location and Clearance Requirements. Safety Markings. All Solus products are of the highest quality and designed to last a very long time. With a little extra care and maintenance you Clearance to Combustible Surfaces. can ensure your fire feature will look great and work well far into the future. Please follow these basic guidelines in caring for you Equipment &...

  • Page 15: Equipment & Accessories Provided

    Fire Features HEMI 36 w/ ETHANOL BURNER MAINTENANCE AND CARE (continued) + The Burner unit is made of high quality 304 Stainless Steel so very little maintenance is required. Try to keep sharp objects or harsh abrasives away from the steel surface as they can scratch and mar. It is normal for the stainless steel Table of Contents: to darken to a bronze/black with repeated burning.

  • Page 16: Equipment & Accessories Provided

    Maintenance & Care. Maintenance & Care. + Solus Decor's products are composed of both hand crafted and machine manufactured parts. As such, these parts Limited Warranty. will change, due to heat expansion/contraction and exposure to the elements at different rates. These changes will Limited Warranty.

  • Page 17: Installation & Assembly

    Clearance to Combustible Surfaces. Equipment & Accessories Provided. Ideally there will be no issues with any Solus product that you purchase, but in case there is, we will need to gather some infor- Equipment & Accessories Provided. mation before we can process your claim. Please go to our website and look for the WARRANTY CLAIMS form, fill it out and Installation &...
