Quick Setup - Rocktron MIDI Mate User Manual

MIDI Mate™ Manual
4
To start using the MIDI Mate™ right away, use a 5 pin MIDI connec-
tor and plug one end into the MIDI OUT jack of the MIDI Mate™. Plug the
other end into the MIDI IN jack of a MIDI receiving device. Plug the adaptor
supplied with the MIDI Mate™ into the POWER jack of the MIDI Mate™.
Plug the adaptor into a nearby compatible wall socket.
Now assign SET1's MIDI channel to the same MIDI channel of the
device that is receiving MIDI. Press the 2ND button so that the 2ND LED
lights. Now press the EDIT FUNCTION SELECT " " button twice, until
"MIDI Channels" scrolls across the display. Allow the scrolling to finish,
and "S1CH 1" will be displayed. This shows that SET1 is assigned to MIDI
channel 1. To change the MIDI channel to match a receiving device's MIDI
channel, use the BANK (ADJUST) buttons. When finished, press the 2ND
button to turn off the 2ND LED.
Now the MIDI Mate™ will send the program change displayed by
the three character display to any MIDI receiver on the same channel.
