6. Dirt Container & Filters:
Removal & Replacement
IMPORTANT: Always unplug the vacuum cleaner
from the electrical outlet before removing the dirt
container.
IMPORTANT: Do NOT use the vacuum cleaner
without ALL of the filters in place.
Emptying the Dirt Container
1. Press the button located on the dirt container
handle to pull out the dirt container (Fig.6/1)
2. Lift up the safety latch (Fig.6/2)
3. Press the button located under the safety latch to
empty the dirt into a rubbish bin. When all of the
dirt has fallen, close the dirt container flap, close
the safety latch and replace the dirt container.
Cleaning the Filter
1. Remove the dirt container as directed.
2. Release the filter safety latch located on top of
the dirt container and pull out the central filter
unit.
3. Remove the filter shroud by rotating
anticlockwise and pulling away from the central
filter (Fig.6/4).
6
V-091 performance user guide.ind4 4
4. Gently tap the filter against the side of a rubbish
bin to remove excess dirt.
5. The central filter can be washed in warm water
(max 40 C). Allow to air dry completely before
0
replacing.
NOTE: Do NOT use any detergents or boiling
water to wash the filter. Vax recommends washing
the filter every time you empty the dust container.
6. Return the central filter to the filter shroud and
rotate clockwise to secure.
7. Replace the central filter unit to the dirt container
ensuring the filter safety catch has been reset.
8. Replace the dirt container as directed.
Post-motor Filter
NOTE: This is located behind cover on opposite
side to cord rewind on your vacuum cleaner.
1. Release the post-motor cover and remove the
filter by pressing in the catch on the left hand
side.
2. The post-motor filter can be washed in warm
water (max 40 0 C). Allow to air dry for 24 hours
before replacing.
NOTE: Do NOT use any detergents or boiling
water to wash the filter. Vax recommends washing
the filter every 9-12 months.
3. Replace the post-motor filter and cover before
re-starting the vacuum cleaner.
7. Cleaning Blockages
WARNING: To reduce the risk of personal injury, the
power cord must be disconnected before performing
maintenance/troubleshooting checks.
1. Turn the vacuum cleaner off and unplug from the
electrical outlet.
2. The flexible hose can be disconnected from the
vacuum cleaner by pushing in the button on
the hose and pulling away from the machine.
Remove any blockages found then reconnect the
hose securely.
it
8. Storage
IMPORTANT: Always unplug the vacuum cleaner
from the electrical outlet and rewind the power cord
as directed before storing.
NOTE: Always store the vacuum cleaner base
down.
9. Troubleshooting
To reduce the risk of personal injury, unplug the vacuum cleaner before performing
WARNING:
maintenance/troubleshooting checks.
PROBLEM: Vacuum cleaner won't run
Cause: Not properly plugged into wall outlet.
Solution: Plug in securely.
Cause: On/off switch not turned on.
Solution: Push on/off switch to on.
Cause: Motor thermostat has tripped.
Solution: Switch off and unplug the vacuum cleaner. Leave for one (1) hour before switching the vacuum
cleaner back on.
PROBLEM: Cleaner won't pick up/loss of suction
Cause: Dirt container not installed properly.
Solution: Review dirt container replacement.
Cause: Dirt container full or blocked.
Solution: Empty dirt container.
Cause: Clogged filters.
Solution: Remove, clean and replace filters.
PROBLEM: Accessories won't pick up
Cause: Accessories not attached correctly.
Solution: Refer to section 5.
Cause: Accessories clogged.
Solution: Remove blockage.
PROBLEM: Dust escaping from the vacuum cleaner
Cause: Dirt container full.
Solution: Empty dirt container.
Cause: Dirt container not installed correctly.
Solution: Review dirt container replacement.
Cause: Hose not installed correctly.
Solution: Review installation.
Cause: Filter not installed completely.
Solution: Remove, clean and replace filters.
10. VAXCARE Service & Help
AUSTRALIA 1300 36 4040
NEW ZEALAND 0800 800 900
If you have any queries or concerns about using
your Vax, call VAXCARE. Please make a note of the
serial number and model number of the appliance
before calling.
(Aust only: Mon-Fri. 10.00am to 6.00pm. EST)
Calls are charged at the local rate.
An answerphone is available outside of these hours.
We will return your call the next working day.
There are over 300 approved Vax Service Agents in
Australia and New Zealand. For the nearest Service
Agent, please refer to your Vax warranty or call
VAXCARE or visit www.vax.com.au
11. Technical Specification
Voltage: 220-240V~50Hz
Wattage: 2200W maximum
Capacity: 3 litres approx
Filters: Washable central HEPA filter [with
filter shroud]
Post-motor filter
Cord length: 6.0m (approx)
Weight: 6.0 kg (machine weight)
Part No.: 77000
Subject to technical change without notice.
