GJD OPAL RFX Installation Manual

Wireless 35 metre external pir

Advertisement

Quick Links

T
HE WEATHERPROOF RECEIVER WITH FRONT AND REAR TAMPER OUTPUT CAN BE POSITIONED IN LINE OF
150
SIGHT UP TO
METRES AWAY
. T
MONITORED
HESE SIGNALS ARE DIRECTED TO THEIR RESPECTIVE VOLT FREE OUTPUTS AND IN ADDITION
THERE ARE A FURTHER EIGHT INDIVIDUAL MONITORING AND INFORMATION OUTPUTS
OPAL RFX WIRELESS P.I.R (GJD018)
Supply:
2 x AAA Alkaline 1.5 volt (not supplied)
Low power typical battery life two years.
Transmission - 150 metres line-of-sight:
433.92 MHz frequency - SAW stabalised
Coverage Range 10 to 35 metres:
35 x 30 mtrs max.with 90º multifunction lens
Internal adjustment 180º pan + 90º tilt.
Mounting Heights: (variable)
3 metres high for multi-beam coverage
6 metres high for curtain covage and
1.5 metres for pet immunity (mask supplied)
Processing - Non-volatile memory:
Intelligent signal processing:
Digital & intergral white light filter
16 million possible identification codes
Adjustments:
Detection signal (CCTV) timer 0.4 to 60 secs.
Light level signal 2 lux to daylight
Pulse count 1 (2 & 3
Temperature: -20 C + 55 C
Detector Housing:
ABS high impact IP55 rated
Weight - 152 grams
Dimensions 110high x 100wide x 100 deep
GJD O
T
HE WIRELESS
DETECTOR DESIGNED TO DETECT AND TRANSMIT RELIABLE EVENT
BASED TRIGGERS TO THE WEATHERPROOF
COMBINED UNITS ENABLE THE SIMULTANEOUS OR INDIVIDUAL
CONTROL OF CAMERAS
VOLTAGE SWITCHING REQUIREMENTS
. T
HE ACTIVE STATE OF UPTO
<
6 seconds)
RFX W
PAL
IRELESS
O
RFX
PAL
EXTERNAL PASSIVE INFRARED INTRUDER
, VCR'
S
RFX-3 RECEIVER (GJD017)
Supply: 12VDC @ 35mA nominal
(9 to 20VDC maximum)
Outputs (CCTV):
3 x independent channel outputs (24hr)
Selectable N/O (form A) or N/C (form B)
Individual timers 0.4 to 60 seconds after last
detection. Non volatile memory
Outputs (A):
3 x independent switching -ve outputs (24hr)
rated @ 250mA - 0.4 second on detection.
RF loss of signal outputs:
3 x RF/signal - ve switching rated @ 250mA
Lux Output (S):
1 x photocell controlled -ve switching
Active 60 seconds after last detection
Tamper:
Back & Front tamper volt free output (form B)
Indication with outputs:
Independent channel active & low battery
Temperature: -20 C + 55C
Weatherproof Enclosure:
IP65 high impact ABS
Weight - 340 grams
183 high x 123 wide x 60mm deep
- 1 -
35
E
METRE
I
NSTALLATION
RFX-3 R
, DVR'
S AND VIRTUALLY ALL LOW
.
3 O
RFX PIR'
PAL
PIR
XTERNAL
M
ANUAL
. T
ECEIVER
HESE
-
S IS CONSTANTLY
.

Advertisement

loading
Need help?

Need help?

Do you have a question about the OPAL RFX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for GJD OPAL RFX

  • Page 1 HESE SIGNALS ARE DIRECTED TO THEIR RESPECTIVE VOLT FREE OUTPUTS AND IN ADDITION THERE ARE A FURTHER EIGHT INDIVIDUAL MONITORING AND INFORMATION OUTPUTS RFX-3 RECEIVER (GJD017) OPAL RFX WIRELESS P.I.R (GJD018) Supply: 12VDC @ 35mA nominal Supply: (9 to 20VDC maximum) 2 x AAA Alkaline 1.5 volt (not supplied)
  • Page 2 The RFX-3 Receiver monitors the active been transferred via the secure wire code state of up to three Opal RFX passive infra learning link. This transfer is only required red detectors. on the initial setup, any subsequent changes The RFX-3 Receiver can be mounted to the detector programming will be relayed externally or internally.
  • Page 3 5) The ‘Channel’ indicator blinks twice. BATTERY INSTALLATION The code for that detector is stored 1) Remove the Opal RFX cover and registered to that channel. 2) Remove the module from the bracket 6) Remove the link wire from the...
  • Page 4 = will flashout your selected settings Seven = will reset to GJD factory default settings Eight/hold = will start the RF continuity test (see page 5) Nine/hold = will generate and alternative random code ( see page 5) CUSTOMISING LUX ‘S’...
  • Page 5 The red indicator Press the program button on the Opal RFX will light on the Opal RFX and the respective nine times. On the ninth press 'hold' the Channel indicator will flash every time a button down for 5 seconds until the LED detection takes place.
  • Page 6 ALIGNMENT IMPORTANT: Passive infra red movement sensors detect the Ensure the detector is mounted upright on temperature changes of moving objects. a vertical surface. If mounting the detector Movement across the beams produces the best on a conductive or uneven surface it is response and range whilst movement towards advisable to use the mounting spacer the detector would be less responsive.
  • Page 7 MULTIBEAM LENS DATA The GJD multifunction lens fitted to the OPAL RFX detector produces 9 long range beams and 9 medium to short range curtain beams. Movement across the beams produces the best response and range, whilst movement towards the detector will be less responsive.
  • Page 8 Installation Notes: GJD reserve the right to alter the specification without prior notice Tel: 01204 363998 Fax: 01204 363991 Email: info@gjd.co.uk GJD Limited, Bolton, England © 010704 - 8 -...
