intellijel designs The Metropolis Manual page 6

MENU FUNCTIONS
(continued...)
INT/EXT
The INT/EXT button allows you to select between three clock modes:
C_INT mode uses the Metropolis' internal clock.
C_EXT mode advances the sequencer each time it receives a trigger on the CLK input.
C_d24 is for syncing with dinsync compatible devices. In this mode Metropolis expects a 24 PPQ
clock on the clock input, and only runs when the RESET input is high. The sequence is reset each
time RESET goes low. (New in 1.10)
The display flashes to indicate that you choice is not active until you click the encoder.
DIV
The DIV button access a menu comrpises of two flashing submenu choices. The select a submenu
item, select it with the encoder and click the encoder to enter that submenu and set the values.
(Changed in 1.10)
1. INCOMING CLOCK DIVISION e.g. dI_01
Here you can set the divion of the clock input.
2. OUTGOING CLOCK DIVISION e.g. do_01
Here you can set the divide clock output. The range of allowable values is determined by what divider
mode you are in (as set in the CONFIG menu)
IF CLK DIV mode = ALL: divider range 1 to 32 (where 1 represents no division)
IF CLK DIV mode = EVE: divider range [1,2,4,6,....32] (even numbers only)
IF CLK DIV mode = ODD: divider range [1,3,5,...31] (odd numbers only)
IF CLK DIV mode = STA: no divider value can be set. Instead a clock pulse is generated at beginning
of each new sequencer stage.
SYSTEM CONFIGURATION FUNCTIONS
AUX A
Use the encoder to select one of six possible destinations for the AUX A input. Note that the selection
is mutually exclusive to AUX B so whatever AUX B is assigned to will not be an available choice.
P.PRE - shift the sequence +/-12 semitones before it is quantized. i.e. TRANSPOSE
P.OCT - shift the sequence +/-4 octaves. i.e. TRANSPOSE
P.POST - shift the sequence +/-12 semitones after it is quantized. i.e. KEY SHIFT
ROOT - shift the root note of the current scale +/-12 semitones i.e. ROOT SHIFT
G. LEN - change the gate length. This value is summed with the dedicated knob value
STAGE - change the number of sequence stages or pulses (if in a fixed mode) by +/-16
STEPD - change the STEP/DIV value by +/-4
d. In - change the clock division of the incoming clock by +/- 32 (New in 1.10)
AUX B
See AUX A.
SAVE
Allows you to save the current state of all the menu and submenu settings to a single location.
6
