Clarion NX706 Owner's Manual
  1. Manuals
  2. Brands
  3. Clarion Manuals
  4. Car Navigation system
  5. NX706
  6. Owner's manual

Clarion NX706 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Owner's manual
NX706
DVD MULTIMEDIA STATION WITH BUILT-IN NAVIGATION &
7 '' TOUCH PANEL CONTROL

Advertisement

Table of Contents
loading

Related Manuals for Clarion NX706

Summary of Contents for Clarion NX706

  • Page 1 Owner’s manual NX706 DVD MULTIMEDIA STATION WITH BUILT-IN NAVIGATION & 7 ’’ TOUCH PANEL CONTROL...
  • Page 2 The registration form is short and easy to complete. Once you’re registered, we can keep you informed of important product information. Register at www.clarion.com - it’s easy to keep your Clarion product up to date. INFORMATIONS DE L’ENREGISTREMENT DE PRODUITS CLARION Pour les Étas Unis et le Canada seulement...

  • Page 3: Table Of Contents

    Selecting the Pandora Mode ................31 ® Pandora Bluetooth Mode ..................32 ® 13. Bluetooth AUDIO PLAYER OPERATIONS ..........33 Selecting the Bluetooth Audio Mode ..............33 Bluetooth Audio Player Settings .................33 Registering Your Bluetooth Audio Player (Pairing) ..........33 Selecting the Bluetooth Audio Player ..............34 NX706...
  • Page 4 Others Setup Menu .....................50 Set the Anti-Theft Code ..................50 23. TROUBLESHOOTING ..................51 General ........................51 DVD Player ......................51 USB Device ......................52 Bluetooth ......................52 SiriusXM Advisory Messages................53 TFT Screen ......................54 24. ERROR DISPLAY.....................55 DVD/CD Player ....................55 25. SPECIFICATIONS ....................56 26. WIRE CONNECTION GUIDE ................58 NX706...

  • Page 5: Features

    Connect via CCA-771,CCA-802 Refer to NOTE: • The items listed outside of the frames are the commercial products generally sold. iPod/iPhone • CCA-771,CCA-802:Sold separately. EX MIC Black Yellow Yellow External Black NX706 Video Microphone VISUAL IN Connection White White Audio/L...

  • Page 6: Precautions

    • For the installation of this unit or a change in the installation, ask your authorized dealer or a nearest Clarion service center for safety. Professional skills and experiences are required to do • This navigation system should not be used to replace your own judgment. No itinerary suggested by this navigation system should ever override any highway regulations, your own judgment, or a knowledge of safe driving practices.
  • Page 7 • This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End user must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. NX706...
  • Page 8 ALL IN ONE DVD PLAYER off with a soft cloth. If moisture forms on the V8VNX706 optical parts of the player, do not use the 8614A-NX706 025034 72 B player for about one hour. The condensation will disappear naturally allowing normal operation.

  • Page 9: Cautions On Handling

    When affected by static electricity or When the memorized data is lost or electric noise. Connect/disconnect the USB damaged by any chance, Clarion shall not memory stick when it is not accessed. be liable for any damage. • Connecting with the computer is not When using an USB memory stick, we supported.

  • Page 10: Handling Discs

    • Do not use commercially available disc protection sheets or discs equipped with stabilizers, etc. These may damage the disc or cause breakdown of the internal mechanism. NX706...
  • Page 11 ® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Clarion Co., Ltd. is under license. Other trademarks and trade names are those of their respective owners. • Pandora, the Pandora logo, and the Pandora trade dress are trademarks or registered trademarks of Pandora Media, Inc.

  • Page 12: Operation Panel

    [RESET] Button • Press this button to hardware reset the unit. Note: When the [RESET] button is pressed, frequencies of radio stations, titles, etc. stored in memory are cleared. NX706...

  • Page 13: Remote Control

    • Batteries (battery pack or batteries installed) the same direction that you removed it. must not be exposed to excessive heat such as Please ensure the tray is inserted in the sunshine, fire or the like. correct direction. NX706...

  • Page 14: Remote Control Functions

    • If the battery leaks, wipe the remote control completely clean and install a new battery. Remote Control Functions You can use the remote control to operate the NX706. Note: • The wireless remote control operation may not be optimal in direct sunlight.
  • Page 15 Tuner modes. • Press to perform fast-backward or fast-forward searching. Press again to change the speed to 2x, 4x, 8x or 16x. • Press for control of background source in Navigation mode. • Channel Up/Down in SiriusXM mode. NX706...

  • Page 16: Main Menu

    1. Touch and hold any of the mode buttons on the main menu for more than 2 seconds. 2. When it begins to “float”, drag the floating button to a new location. 3. Lifting up your finger will drop the button in the new location. NX706...

  • Page 17: Dvd Video Player Operations

    Also, it may not be possible to play depending on its recording conditions. • You cannot play SuperAudio CD. The CD player is not supported even if it is a hybrid disc. NX706...

  • Page 18: Change Dvd System Settings

    The disc will not be viewable until the correct password is entered. If you force a disc in before auto reloading, it may damage a disc. Set rating for parental level control 1.Select Others screen while in Setting mode. Touch NX706...

  • Page 19: Showing Dvd Player Mode Screen

    A large segment to divide the data area of the disc. 7 - Seek bar • Chapter 8 - Total time A small segment to divide the data area of the disc. 9 - Menu List button 10 - System time NX706...

  • Page 20: Showing Video Files Player Mode Screen

    2. Touch the screen of the playing video file to display with the directional buttons. Video files player menu , touch the screen again to 4. Touch [ ] button to fix on the selected item. return the playback screen. The display will return to NX706...

  • Page 21: Operate The Video Files Player Menu

    Disc Audio player mode. Please refer to CD Player 1. Touch [ ] button to pause during playback. Operations. 2. Touch [ ] button again to resume playback. Switch to Previous/Next File 1. Touch [ ] or [ ] button during playback to play previous/next file NX706...

  • Page 22: Playable Video Disc Formats

    • format: MPEG4 Visual Simple @L1 • Picture size: 720 x 405 • Audio format: AAC • Audio sampling frequency: 32/44.1/48 KHz *.mpg files • format: MPEG2 • Picture size: 720 x 480 • Audio format: MP3 • Audio sampling frequency: 32/44.1/48 KHz NX706...

  • Page 23: Cd Player Operations

    9 - Shortcut button. 3. Touch the desired track title button. The 10 - Play/Pause button corresponding track is started playback. 11 - Next Track/Fast Forward button 12 - Shuffle button 13 - Direct Searching button 14 - Scan Start/Stop button NX706...

  • Page 24: Listening To Compressed Audio

    1.1 and 1.0. played in the order displayed on the PC). In displaying, this unit gives priority to the Version 2.3 • Some noise may occur depending on the type of and 2.4 TAGs. encoder software used while recording. NX706...

  • Page 25: Playback Mp3/Wma/Aac Menu

    ] button to stop playback. 2. Touch [ ] button again to resume playback. Playback resumes from the start of the folder which the playing track is in. • Other operations about playing MP3/WMA/AAC are almost the same as CD Player mode. NX706...

  • Page 26: Usb Audio Operations

    • The maximum allowable number of folders is 65535 (including root directory and folders with no MP3/ WMA/AAC/FLAC file). • The maximum allowable number of files in a folder is 65535. • You can store the MP3/WMA/AAC/FLAC files together in a folder. NX706...

  • Page 27: Playing Audio Files In Usb Memory

    1. Touch the [ ] button to shuffle the tracks in playing folder during playback. 2. Touch this button again to turn off the feature. Alphabet Search Touch the [ ] button to search with alphabet in current list. NX706...

  • Page 28: Usb Video Operations

    6 - Repeat button * The display will return to the playback screen, if you 7 - System time do not touch the screen for 10 seconds. 8 - Bluetooth status indicator 9 - Playback information 10 - Shortcut button NX706...
  • Page 29 This operation is the same as in the USB Audio mode. 6 - Shuffle button Searching with the Track Number 7 - Video files in list This operation is the same as in the USB Audio mode. 8 - System time NX706...

  • Page 30: Ipod Operations

    • This system will not operate or may operate improperly with unsupported versions. • For detailed information on the playable iPod/iPhone models, see our home page: www.clarion.com The playback starts, from where the iPod/iPhone has been paused. Notes on Using an iPod/iPhone •...

  • Page 31: Ipod Audio Playlist Mode Screen

    Audio mode. The Category List operation is same as the normal iPod Audio mode. Select different song categories to play. The category is same as on the iPod/iPhone. iPod Audio Playlist Mode Screen NX706...

  • Page 32: Operations

    13 - Current album name • Skipping a track (Pandora mode) Touch the [ ] button during playback, tracks are skipped and start playback from the beginning of the next track. Note: • Some track are not able to be skipped. NX706...

  • Page 33: Pandora ® Bluetooth Mode

    Pandora when in the Pandora mode. 5. During Pandora playback in the Pandora mode with the Bluetooth connection, the volume level is controlled also on the mobile phone side. (Both iOS and Android devices) NX706...

  • Page 34: Audio Player Operations

    2. Touch the Device button [ ] to display the Device • For detailed information on the playable Bluetooth Select screen. audio players, see our home page: www.clarion.com Selecting the Bluetooth Audio Mode 1. Touch the [BT Audio] button to select the Bluetooth Audio mode.

  • Page 35: Selecting The Bluetooth Audio Player

    3. Touch the desired device button you wish to use. Touch the [ ] button to select it as your active device. The corresponding phone is set as the current telephone. 4. Touch the [ ] button to return to the previous screen. NX706...

  • Page 36: Bluetooth Telephone Operations

    Note: • The input level of the microphone can be affected by its surroundings. Adjust the level if the person on the other end of the telephone has a reception problem. NX706...

  • Page 37: Registering Your Phone (Pairing)

    5. If entering the Pass Key code is prompted on your phone, enter the Pass Key code set in this unit. • You can change the Pass key setting of this unit from the Bluetooth Info screen under the Telephone Settings screen. NX706...

  • Page 38: Answering An Incoming Call

    2. When the call is finished, touch the [ ] button Note: to hang up. • Depending on some phones, the Telephone Interrupt screen may be closed and the connection with this system may be disconnected when entering the Private mode. NX706...

  • Page 39: Using Siri Eyes Free Function

    3. Talk to Siri the same way as using it on the iPhone. 4. To finish Siri Eyes Free function, touch the [ button. Notes: Siri Eyes Free is available on iOS 6.1 or higher. Please use external mic when you use the Siri Eyes Free function. NX706...

  • Page 40: Tuner Operations

    Recalling a preset station order to separate closely spaced stations. This feature 1. Touch the [FM1/2/3/AM] button to select the desire is useful in areas that have many radio stations in band (FM or AM) on the tuner. close proximity. NX706...

  • Page 41: Siriusxm ® Satellite Radio Operations

    SiriusXM signal to receive the activation message. button to enter the Setting menu. Selecting a Satellite Radio Mode Touch the SiriusXM button on the Main Menu display. The system changes to the SiriusXM Satellite Radio mode. The SiriusXM mode screen is displayed. NX706...

  • Page 42: Channel Selection By Up/Down Button

    If you enter a wrong number, you can cancel it by 3. Touch the desired category item button to enter touching the [Clear] button . channel lists belonging to this category. 4. Select the desired channel by touching it on the list. NX706...

  • Page 43: Replay

    Band of Preset channels. Miss a music, news, talk or sports segment? No Problem, because you can rewind and replay when you tune to one of your Preset channels and hear what you missed. NX706...

  • Page 44: Hdmi Mode

    Note: The following are wiring examples. Depending on the device, it might be able to connect to the Clarion device directly with the CCA-771. Depending on the adapter or device, audio and/or video noise might be experienced. (1) Connection with the iPhone 5, iPhone 5s, iPhone 5c, iPhone 6, iPhone 6 Plus, iPhone 6s and iPhone 6s Plus...

  • Page 45: Select Hdmi Source

    This HDMI mode is only indicative or a mirror image the screen of the iPhone, Android. You cannot operate by the touch screen of NX706. Note: Depending on the application and model of the mobile phone, a black frame may appear around the screen.

  • Page 46: Aux

    If the reverse cable is connected correctly to the car, the unit goes to camera mode automatically when the car is in reverse. As an additional safety feature, the audio from a camera with a built-in microphone can be heard through the NX706. NX706...

  • Page 47: Rear Source Operations

    3. Touch the Front button to access the main menu but DVD Video Rear Source Control Direct not close the Rear Source. Mode. DVD Video in Rear NOTE: More detail please refer to DVD Video Front source. NX706...

  • Page 48: Aux Video In Rear

    More detail please refer to AUX Front source. 21. FULL DIGITAL SOUND SYSTEM The NX706 has a Digital (Optical) output which allows it to connect to Clarion’s high fidelity Full Digital Sound System. Clarion’s Full Digital Sound System is a break through in audio technology.

  • Page 49: Setting Operations

    Camera Audio: There are three options, Off, On and Mute. Version: Display the software version information. Note: • Time and 24-Hour Format can be adjusted when set the system time not to be synchronized with GPS local time. NX706...

  • Page 50: Video Setup Menu

    90Hz and 120Hz. Magna Bass EX: Choose the loudness On or Off. Audio Setup Menu Amp Cancel: Selecting ON turns off the internal amplifier in the NX706. Note: Optional cable (sold separately) is necessary when you use Audio line out.

  • Page 51: Others Setup Menu

    Note: If the anti-theft code is lost or forgotten, a charge will be incurred at the owner’s expense by a Clarion service station to unlock the NX706. Set Password: Set the password for the DVD parental control.

  • Page 52: Troubleshooting

    Check that the parking brake is displayed. engaged. engaged. Disc cannot play with Feature exceeds set parental Release the view limitation or the display “PARENTAL level. change the parental level. VIOLATION” shown. See the subsection “Setting up the parental level” NX706...

  • Page 53: Usb Device

    The audio quality is poor after The Bluetooth reception is Move the device closer to the connection with a Bluetooth poor. car audio system or remove enabled device. any obstacle between the device and the system. NX706...

  • Page 54: Siriusxm Advisory Messages

    In Canada, visit www.siriusxm.ca or call 1-877-438-9677 if you have questions about your subscription or would like to subscribe to this channel or would like to subscribe to this channel. NX706...

  • Page 55: Tft Screen

    (The liquid crystal panel is produced according to technology with very high precision. Note that, though there are effective pixels of 99.99% or more, pixel missing or normally lit pixels account for 0.01%). NX706...

  • Page 56: Error Display

    Eject the disc then reload it inside the DVD deck and does properly. not play. PARENTAL VIOLATION Parental level error. Set the correct Parental level. Region code error Region code error. Eject the disc, and replace correct region code disc. NX706...

  • Page 57: Specifications

    Signal to Noise Ratio: 81 dBA(reference 1 W into 4Ω) Resolution: 800 x 480 x 3 (RGB) Bluetooth Specification: Bluetooth Ver 4.0 Profile: HFP1.5(Hands Free Profile) HSP1.0 (Headset Profile) A2DP (Advanced Audio Distribution Profile) AVRCP1.2,1.3,1.4 (AV Remote Control Profile) NX706...
  • Page 58 NX706 dimensions: NX706 weight: 2.74 kg NX706...

  • Page 59: Wire Connection Guide

    • In the optional devices, the RCA cables and the Connector cables are separately-sold items. • Cable Note: For prevent the disconnection of the Optical cable, please fix the cable to NX706 with vinyl tie. Optical Cable (Sold in the market) Refer to page 59 Z3 Commander...
  • Page 60 R ed +12V accessory P urple/ W hite Reverse gear cord G rass-green Parking brake cord Note: *1: Connecting the PHONE INTERRUPT terminal The phone interrupt will mute the audio if the lead receives a negative or ground signal. NX706...
  • Page 61 Clarion Co., Ltd. 2015/10 All Rights Reserved. Copyright © 2016: Clarion Co., Ltd.
  • Page 62 Owner’s manual NX706 English Clarion NX706 English 1...
  • Page 63 It is easy to keep the navigation system up to date. Simply download new map data from Clarion’s portal site, store them on a microSD card and insert it into the Clarion NX706 via the front card slot. Unpleasant surprises are now avoided as navigation maps will match the real world.
  • Page 64 3.1.2.6 Using the ZIP code to select a destination ......................36 3.1.3 Selecting a Place of Interest ........................37 3.1.3.1 Using Quick search categories ........................... 37 3.1.3.2 Searching by category ............................39 3.1.3.3 Searching by name .............................. 41 3.1.3.4 Finding help nearby ............................43 Clarion NX706 English 3...
  • Page 65 4.1.7 Intelligent navigation ..........................68 4.1.7.1 Congestion detour on highways .......................... 68 4.1.7.2 Real-time alternative routes ..........................69 4.1.7.3 Parking around destination ..........................69 4.1.7.4 Hints upon detour ............................... 70 4.2 Useful Information menu ........................70 4 Clarion NX706 English...
  • Page 66 5.5 Keyboard buttons are grayed out ..................... 85 5.6 The map is hidden behind an image of a junction ................86 6 Index ............................87 7 End-user license agreement ....................89 8 Copyright note ......................... 89 Clarion NX706 English 5...

  • Page 67: Warnings And Safety Information

    1 Warnings and safety information The navigation system helps you find your way to your destination with the built-in GPS receiver. NX706 does not transmit your GPS position; others cannot track you. NX706 collects usage information and GPS logs that may be used for improving the application and the quality of maps if you accept it when first using the application.

  • Page 68: Getting Started

    2 Getting started NX706 is optimized for in-car use. You can use it easily by tapping the screen buttons and the map with your fingertips. 2.1 Initial set-up When using the navigation software for the first time, an initial set-up process starts automatically.
  • Page 69 (page 82). Tap to continue. If needed, modify the default route planning options. Later you can change them in Route Preferences (page 74). Tap to continue. The initial set-up is now complete, tap to enter the Navigation view. 8 Clarion NX706 English...

  • Page 70: Screen Controls

    You need to confirm selections or changes only if the application needs to be restarted, if it needs to perform a major reconfiguration, or if you are about to lose some of your data or settings. Otherwise, NX706 saves your selections and applies the new settings without confirmation as soon as you use the controls.
  • Page 71 Caps Lock. Tap again to use lower case letters. Entering numbers and symbols to switch to a keyboard offering numbers and symbols. Finalizing the keyboard entry Starting a search for a keyboard entry Hiding the keyboard 10 Clarion NX706 English...

  • Page 72: Using Touch Gestures

    To move the map in map browsing mode: grab the map, and move it in the desired direction. Using pinch zoom Use pinch zoom on the Navigation view to zoom in and out by moving two fingers in a pinch gesture. Clarion NX706 English 11...

  • Page 73: Manipulating The Map

    Zooming in and Change how much of the map is displayed on the screen. NX706 uses maps that let you examine the locations at various zoom levels, always with optimized content. It always displays street names and other text with the same font size, never upside-down, and you only see the streets and objects that you need.
  • Page 74 Selecting Open a list of additional features like saving a location, or additional searching for Places around the cursor. options Selecting a Select the cursor location as a new destination. The route is destination automatically calculated. Clarion NX706 English 13...

  • Page 75: Navigation View

    2.3 Navigation view The navigation view is the main screen of NX706 that shows the planned route on a map. NX706 works with digital maps which are not simply the computerized versions of traditional paper maps. Similarly to paper road maps, the 2D mode of digital maps shows you streets and roads. Elevation is also illustrated in color.
  • Page 76 Navigation By tapping it, you can open the Navigation menu, where you can reach menu other parts of NX706. Street name It shows the current street name. By tapping it, you can open the Where Am I screen. See page 71.

  • Page 77: Streets And Roads

    2.3.2 GPS position markers When your GPS position is available, NX706 marks your current position. By default, this marker is a blue arrow. The dot near the arrow shows the GPS position as perceived by the GPS receiver.

  • Page 78: The Planned Route

    2.3.3 The planned route The planned route is the currently navigated route. Whenever the destination is set, the route is active until you delete it, reach your destination or suspend navigation. NX706 displays the route in the following ways: Symbol...

  • Page 79: Maneuver Icons

    Enter the traffic circle and take the first exit (next maneuver). Enter the traffic circle (second next maneuver). Enter the freeway. Exit the freeway. Board the ferry. Leave the ferry. Approaching a waypoint on the right. 18 Clarion NX706 English...

  • Page 80: Lane Information And Signposts

    When navigating on multi-lane roads, it is important to take the appropriate lane in order to follow the planned route. If lane information is available in the map data, NX706 displays the lanes and their directions using small arrows at the bottom of the map. Highlighted arrows represent the lanes and the direction you need to take.

  • Page 81: Tunnel View

    Tap any of them to display the exit area on the map. You can now easily add this service station as a waypoint to your route if necessary. If you want to display other types of Places at the next few service stations, you can change the icons in . See page 79. 20 Clarion NX706 English...

  • Page 82: Object Types

    NX706 supports the following 3D object types: Type Description 3D terrain NX706 displays 3D hills and mountains in the Navigation view, and illustrates them by coloring and shading on the 2D map. Elevated roads Elevated roads are complex intersections and vertically isolated roads (such as overpasses or bridges) displayed in 3D.
  • Page 83 Access the User profiles menu where you can create new profiles or edit the existing ones. If several drivers are using the navigation system, they can create their own profiles with their own settings. The following options are also available on many of the menu screens: Button Function 22 Clarion NX706 English...
  • Page 84 Tap it to return to the map from any menu screen. Tap the Back button to return to the previous screen. You can also press and hold this button to quickly return to the Navigation view from any other screen. Clarion NX706 English 23...

  • Page 85: Using The Navigation

    3 Using the navigation By default, NX706 calculates routes using the road network of the maps provided with the product. You can select the destination and start navigating to it right away (normal navigation) if you need a route for immediate navigation.
  • Page 86 If the new search area is in a different country or state, start entering the country/state and the town. to see the whole list of the matching results. With the proper search area displayed, start entering the name, address, or category of the destination you are looking for. Clarion NX706 English 25...
  • Page 87 Once the destination is selected, a full screen map appears with the selected point in the middle. If necessary, tap the map somewhere else to modify the destination. The cursor ( ) appears in the new location. Check the settings for road types and change them if necessary. 26 Clarion NX706 English...

  • Page 88: Selecting An Address

    The center of a town, see page 33 • The midpoint of a street, see page 34 • An intersection, see page 35 • Any of the above, starting the search with the ZIP code, see page 36. Clarion NX706 English 27...

  • Page 89: Entering An Address With States

    Navigation view to access the Navigation menu. By default, the NX706 proposes the country and state where you are or in case there is no valid GPS position, the country and state of the last known position. If needed, change the country. Tap...
  • Page 90 Select the street from the list. Enter the house number by performing the following steps: Tap the House number or crossing street field. Enter the house number on the keyboard. (To enter letters, tap Clarion NX706 English 29...
  • Page 91 The route is calculated and the map appears showing the entire route, where you can check route information and route alternatives. Tap to modify the route parameters, or tap to start your journey. 30 Clarion NX706 English...

  • Page 92: Entering An Address Starting With The Street Name

    Navigation view to access the Navigation menu. By default, NX706 proposes the country and state where you are. If needed, change the country. In the Select Country screen, you can immediately select a country from the list below the...
  • Page 93 A full screen map appears with the selected point in the middle. If necessary, tap the map somewhere else to modify the destination. The cursor ( ) appears at the new location. Check the settings for road types and change them if necessary. 32 Clarion NX706 English...

  • Page 94: Selecting A Town Center

    Go to , and modify the country and state as described earlier (page 28), if necessary. If necessary, select a new town by performing the following steps: Tap the Town or ZIP code field. Clarion NX706 English 33...

  • Page 95: Selecting The Midpoint Of A Street

    , and select the country and town as described earlier. The Select Street screen appears. Enter the street name by performing the following steps: Tap the Street name field. (optional) On the Select Street screen, you can immediately select a street from the list of suggestions. 34 Clarion NX706 English...

  • Page 96: Selecting An Intersection In A Town

    (optional) On the Select Street screen, you can immediately select a street from the list of suggestions. c. Otherwise, start entering the street name on the keyboard. The names that match the string appear in a list. Clarion NX706 English 35...

  • Page 97: Using The Zip Code To Select A Destination

    , and modify the country and state as described earlier (page 28), if necessary. Tap the Town or ZIP code field. Enter the ZIP code by performing the following steps: to open the numeric keypad. Start entering the ZIP code. c. Tap to open the list of results. 36 Clarion NX706 English...

  • Page 98: Selecting A Place Of Interest

    In case of emergency, you can also find help nearby, see page 43 3.1.3.1 Using Quick search categories The Quick search feature helps you quickly find the most frequently selected types of Places. Perform the following steps: on the Navigation view to access the Navigation menu. Clarion NX706 English 37...
  • Page 99 Place, or to save the location. If necessary, tap the map somewhere else to modify the destination. The cursor ( ) appears at the new location. Check the settings for road types and change them if necessary. 38 Clarion NX706 English...

  • Page 100: Searching By Category

    . By default, the search area is around the current position (or if it is not available, around the last known position). In this case, the following result list is ordered by the distance from this position. Clarion NX706 English 39...
  • Page 101 Select one of the main Place categories (for example, Accommodation), then browse the subcategories (for example, Hotel or Motel) to find your destination. You can turn the Category View off at any level to list all Places around the selected location or along the route. 40 Clarion NX706 English...

  • Page 102: Searching By Name

    (The result list is ordered by the distance from the center of the selected town.) • to search for a place around the destination of the planned route. (The result list is ordered by the distance from the destination.) Clarion NX706 English 41...
  • Page 103 . Using the keyboard, start entering the name of the Place or browse in the categories. After entering a few letters, tap to open the list of Places or Place categories with names containing the entered character sequence. 42 Clarion NX706 English...

  • Page 104: Finding Help Nearby

    Tap any of the quick search buttons to get an instant list of those types of Places. (optional) The Places in the list can be ordered by the following criteria: • By their distance from the current or last known position • By name. to reorder the list. Clarion NX706 English 43...

  • Page 105: Selecting A Saved Location

    After you have selected a saved location as the destination, a full screen map appears with the selected point in the middle. If necessary, tap the map somewhere else to modify the destination. The cursor ( ) appears in the new location. 44 Clarion NX706 English...

  • Page 106: Selecting A History Item

    The more you use the navigation software, the better it can guess your desired destination. To select a History item, perform the following steps: on the Navigation view to access the Navigation menu. Clarion NX706 English 45...
  • Page 107 Period Charge or Per-use Toll, tap for ferries, or tap for carpool lanes. to confirm the destination. You can also select a nearby point on the map or tap to select a different destination. 46 Clarion NX706 English...

  • Page 108: Selecting A Saved Route

    Navigation view to access the Navigation menu. The list of saved routes appears. If necessary, scroll the list to see earlier routes. Select a route and the Multipoint Route screen appears. If necessary, modify the saved route. Otherwise, tap Clarion NX706 English 47...

  • Page 109: Entering Coordinates

    Navigation view to access the Navigation menu. You can enter the latitude and longitude values in any of the following formats: decimal degrees, degrees and decimal minutes, or degrees, minutes and decimal seconds. Tap 48 Clarion NX706 English...
  • Page 110 The route is calculated and the map appears showing the entire route, where you can check route information and route alternatives. Tap to modify the route parameters, or tap to start your journey. Clarion NX706 English 49...

  • Page 111: Selecting A Location On The Map

    The route is calculated and the map appears showing the entire route, where you can check route information and route alternatives. Tap to modify the route parameters, or tap to start your journey. 50 Clarion NX706 English...

  • Page 112: Planning A Multipoint Route

    The New Route to... screen appears, where you can select the destination of the route the same way as described in the previous sections. When the selected location appears on the map, tap and the list returns. If needed, you can add further intermediate destinations. Clarion NX706 English 51...

  • Page 113: Checking Route Information And Alternatives

    The planned route is displayed in its full length on the map with the following additional information: • The total length of route • The total time of route. You have the following options on this screen: • to receive detailed information about the route. 52 Clarion NX706 English...

  • Page 114: Editing The Route

    Deleting the planned route, see page 57 • Selecting a route alternative when planning the route, see page 58 • Selecting a route alternative for an existing route, see page 59 • Pausing guidance, see page 60. Clarion NX706 English 53...

  • Page 115: Setting A New Starting Point

    The Change Start to... screen appears. Select the starting point of the route the same way you select a destination. You can see the new starting point on the map. Tap and the Multipoint Route screen appears where you can continue adding a destination to your route. 54 Clarion NX706 English...

  • Page 116: Adding An Additional Destination

    The other destinations of the route remain intact. • on the Navigation view and tap . Add a destination to your route as described on page 51. Clarion NX706 English 55...

  • Page 117: Modifying The List Of Destinations

    Main menu. Tap , then confirm the deletion. 3.3.4 Saving the planned route To save the planned route, perform the following steps: Select a destination as described earlier and tap 56 Clarion NX706 English...

  • Page 118: Deleting The Planned Route

    Type in a name and tap The route is saved and it is available in By selecting a previously saved route, NX706 recalculates the route using the saved destination and/or the waypoints. 3.3.5 Deleting the planned route You have the following two options to delete the navigated route: •...

  • Page 119: Selecting A Route Alternative When Planning The Route

    Select one of the route alternatives and tap to return to the previous screen. NX706 recalculates the route. Tap to start your journey. The orange line now shows the new planned route. 58 Clarion NX706 English...

  • Page 120: Selecting A Route Alternative For An Existing Route

    Select one of the route alternatives and tap to return to the previous screen. NX706 replaces the original route. Tap to start your journey. The orange line now shows the new planned route. Clarion NX706 English 59...

  • Page 121: Pausing Guidance

    Select a destination as described before. It can be an address, a Place, any location on the map, a previously used destination from History, and so on. When the map appears with the selected location in the middle, tap (optional) Using the keyboard, you can change the name offered for the Saved Location. 60 Clarion NX706 English...

  • Page 122: Editing A Saved Location

    In Saved Locations, Home and Work cannot be renamed. To change your home or work Note! location, tap , and confirm the address change. Adding a location to the list of saved locations is described on page 60. Clarion NX706 English 61...

  • Page 123: Adding An Alert Point

    Scroll down the list and tap Select the type of the Alert Point, the direction from which you expect the alert, and (if applicable) the speed limit for this Alert Point. to save the location as a new Alert Point. 62 Clarion NX706 English...

  • Page 124: Running A Simulation

    • : Jump to the next route event (maneuver). • : Pause the simulation. • : Jump to the previous route event (maneuver). Clarion NX706 English 63...

  • Page 125: Off-Road Navigation

    3.7 Off-road navigation When first started, NX706 calculates routes using the road network of the maps provided with the product. If you want to disregard roads during navigation, you can switch to off-road mode, for example when driving in a desert.

  • Page 126: Navigating In Off-Road Mode

    Turn Preview field in the top left corner shows a compass with your bearing and the distance of the next destination. When you reach the final destination, the navigation ends. If you do not want to use off-road navigation, switch back to on-road navigation by tapping Note! Clarion NX706 English 65...

  • Page 127: Reference Guide

    There is a special proximity warning for road safety cameras (like speed or red light cameras) and other proximity Alert Points (like schools or railroad crossings). These Alert Points are not part of NX706. You can download Alert points from clarion.naviextras.com or you can upload points in a specific text file if needed.

  • Page 128: Route Calculation And Recalculation

    The maximum speed set in the vehicle profile (page 74) is also used for this warning. NX706 alerts you if you exceed the pre-set value even if the legal speed limit is higher.

  • Page 129: Intelligent Navigation

    The following sections describe these features. 4.1.7.1 Congestion detour on highways NX706 may offer a detour when you slow down on a highway due to a traffic jam. The Potential congestion detour window appears and shows the length and duration of the detour.

  • Page 130: Real-Time Alternative Routes

    4.1.7.3 Parking around destination If you leave the planned route by exiting a freeway, NX706 tries to guess the reason for making a detour. By tapping , you can open a top-down map with the recommended parking Places around the destination.

  • Page 131: Hints Upon Detour

    4.1.7.4 Hints upon detour If you leave the planned route by exiting a freeway, NX706 tries to guess the reason for making a detour. The Reason for detour window appears and shows available gas stations, restaurants or other Places around the current position. Also, if there are avoidable parts of the original route ahead (like a tunnel, a toll road or a ferry), you can find them in the list, in case you want to bypass them.

  • Page 132: Where Am I

    • The nearest town • Next crossing road/street • Previous crossing road/street. You can also perform some actions on this screen. to add the current position to the saved locations and to check the country information. Clarion NX706 English 71...

  • Page 133: Trip Monitor

    By tapping your recorded trip on the Trip Monitor screen, you can check information such as time, speed, altitude and distance. By tapping on the Trip Data Details screen, you can view the trip on the map, export track logs, and check the elevation and speed profiles. 72 Clarion NX706 English...

  • Page 134: Settings Menu

    4.3 Settings menu You can configure the navigation settings, and modify the behavior of NX706, by tapping Tap the arrows to view the content of other pages. The Settings menu provides the following options: Button Function Select the road types used in route planning, and the route planning method.

  • Page 135: Route Preferences Settings

    To add a new vehicle profile, perform the following steps: , browse the list of vehicles, and tap Select the vehicle type and set the parameters below. You can set the following parameters: 74 Clarion NX706 English...

  • Page 136: Route Planning Method Types

    Results in a route with fewer turns and no difficult maneuvers. With this option, you can make NX706 take, for example, the freeway instead of a series of smaller roads or streets.

  • Page 137: Road Types

    Per-use toll roads are pay roads where there is a per-use charge in the routes by default. If you disable toll roads, NX706 plans the best toll-free route. NX706 includes ferries in a planned route by default. However, a map does not necessarily contain information about the accessibility of temporary ferries. You might also need to pay a fare on ferries.

  • Page 138: Sound Settings

    Announce the road numbers only. • Announce the maneuver only. Set whether you want an immediate announcement for the next maneuver after each turn, or it is enough to receive the information when the turn is near. Clarion NX706 English 77...

  • Page 139: Warnings Settings

    You can enable and modify the following settings: Button Description NX706 is able to warn you if you exceed the current speed limit. This information may not be available in your region, or may not be fully correct for all roads on the map.

  • Page 140: Navigation View Settings

    3D buildings, landmarks, and manage your Place visibility sets (which Places to show on the map). You can modify the following settings: Clarion NX706 English 79...
  • Page 141 Turn it on to get freeway service information (for example gas stations, restaurants) or turn it off if you do not need it. Select the service types displayed for the freeway exits. Choose from the Places categories. 80 Clarion NX706 English...
  • Page 142 A top-down overview of the tunnel and the remaining distance are also displayed. In certain situations, NX706 offers a detour when there is a traffic jam on a highway. See page 68.

  • Page 143: Regional Settings

    TTS Voice with a microphone icon: Besides the above-mentioned profiles, it can also be used for voice recognition. You can set the measurement units and time/date format to be used. NX706 may not support all the listed units in some voice guidance languages.

  • Page 144: Trip Monitor Settings

    Anonymous track logs are sometimes used for providing real-time information service. Your trips can also help us improve the quality and coverage of maps. Clarion NX706 English 83...

  • Page 145: Troubleshooting

    Cause: The digital map data may not include every single address. Solution 1: If the house number is not known or NX706 cannot find it, select only the street name. This way, NX706 will navigate you to the midpoint of the street, where you can find the exact address more easily.

  • Page 146: Disabling The Speed Limit Warning

    Issue: Some keyboard buttons are grayed out and cannot be used. Cause: NX706 has a smart keyboard for address search, which means that only those buttons are active that can be used to type a name that is available on the map.

  • Page 147: The Map Is Hidden Behind An Image Of A Junction

    Solution: If you want to hide the currently displayed junction and return to the Navigation view, tap the picture. To turn off this feature, perform the following steps: , and . Now the tunnel view will not appear again. 86 Clarion NX706 English...

  • Page 148: Index

    Editing the route, 53 Off-road navigation, 64, 75 Fast route, 75 Favorites (Saved Locations), 44, 60, 61 Parking, 69 Places of Interest, 37 GPS Information, 71 POI (Places), 37 Green route, 75 Possible alternative route, 69 Clarion NX706 English 87...
  • Page 149 Simulation, 63 Work address, 44, 60 Smart zoom, 67 Sound settings, 77 Speed camera, 66, 79, 85 ZIP code, 36 Speed limit, 78, 85 Zooming, 11, 12, 67 Speed limit warning, 67, 85 Starting point, 54 88 Clarion NX706 English...

  • Page 150: End-User License Agreement

    2.4 U.S. Government Users. If you acquire the Navigation Product by or on behalf of the United States Government or any other entity seeking or applying rights similar to those customarily claimed by the United States Government, you are on notice that the Navigation Product is a commercial item as that Clarion NX706 English 89...
  • Page 151 5. Rights under copyright or other intellectual property rights 5.1 All material copyrights and other intellectual property rights vested in the Navigation Product or any parts thereof, that are not explicitly granted in this Agreement or by virtue of law, are reserved. 90 Clarion NX706 English...
  • Page 152 7.2 The User may only use the Databases and information from the Services available through the Navigation Product (including but not limited to the traffic data received from the RDS TMC or on-line TMC traffic information service) for his/her own benefit and at his/her own risk. It is strictly prohibited to Clarion NX706 English 91...
  • Page 153 Navigation Product) is the exclusive responsibility of the User. The Licensor shall not assume any responsibility for any damages occurred in relation to use of the Navigation Product in any vehicle. 92 Clarion NX706 English...
  • Page 154 Device or may be deleted by the User manually. 10.3 Collected data is transmitted, stored and handled anonymously and no connection of the data with the User shall be established by Licensor or any third party. Clarion NX706 English 93...
  • Page 155 Applicable third party terms shall be listed in the “About” section of the Navigation Product, in the Device documentation, at a website address indicated in the “About” section or as part of this Agreement. When first using / enabling Connected Services, User accepts compliance with those third party terms and conditions. 94 Clarion NX706 English...
  • Page 156 Attribution of third parties (e.g. copyright notices) supplying software modules, Databases, Services or other material to the Navigation Product are listed in the “About” section of the Navigation Product or at a website address indicated in the “About” section. Clarion NX706 English 95...
  • Page 157 The product and the information contained herein are subject to change without prior notification. This manual may not, in whole or in part, be reproduced or transmitted in any form either electronically or mechanically, including photocopying and recording, without the express written consent of Clarion. © 2014 - Clarion ©...

Table of Contents
