10、B0M List
MATERIAL CONCENTRATIVE BOM PRINT
MATERIAL NO.:
MATERIAL NAME:
Parent
03-DM62SAB-SC60S T6-016W31-A009XZ
T6-016W31-A009XZ 06-016W31-A009X
03-DM62SAB-SC60S T8-21RFLN-HF4AB ASS'Y - MATCH TUBE
T8-21RFLN-HF4AB T8-21RFLN-FHF4AB ASS'Y - MATCH TUBE(F.CAB)
T8-21RFLN-FHF4AB 44-21RFLN-HF4A
T8-21RFLN-FHF4AB 46-27688H-04XG
T8-21RFLN-HF4AB T8-21RFLN-MHF4AB
T8-21RFLN-MHF4AB 10-0BY228-F0X
T8-21RFLN-MHF4AB 10-0FR104-FBX
T8-21RFLN-MHF4AB 18-FG0151-JHX
T8-21RFLN-MHF4AB 18-FG0439-JHX
T8-21RFLN-MHF4AB 25-BCB101-M1X
T8-21RFLN-MHF4AB 27-AHQ393-JSX
T8-21RFLN-MHF4AB 27-AHR394-JSX
T8-21RFLN-MHF4AB 27-ALQ102-J0X
T8-21RFLN-MHF4AB 27-ALQ272-J0X
T8-21RFLN-MHF4AB 27-ALR133-J0X
T8-21RFLN-MHF4AB 36-LIN180-XX1
T8-21RFLN-MHF4AB 36-WID601-XX1
T8-21RFLN-MHF4AB 37-FCA001-EAA0A FLYBACK BSC27-0101Q
T8-21RFLN-MHF4AB 66-343730-0B0
T8-21RFLN-HF4AB T8-DM62SAB-CRY
T8-DM62SAB-CRY
T8-DM62SAB-CRY
03-DM62SAB-SC60S
S21M62Q/CS-SY33-LA
Child
10-1N4148-ABX
11-SA1015-YBX
Description
ASS'Y-REMOTE CONTROL BD
OF ARTEQU
REMOTE CONTROLLER
RC1663108
CRT A51ERS357X440
HS 4P A/B 400/13 RBGW
TJC1/4Y
ASS'Y - MATCH TUBE(MAIN
BD)
DIODE BY228
DIODE FR104 (FAST
RECTIFIER)
RES. M.O. 150 OHM 2W +/-
5%
RES. M.O. 4.3 OHM 2W +/-
5%
CAP. ELEC 100 UF 16V +/-
20%
CAP. M.PP 0.039 UF 400V
+/-5%
CAP. M.PP 0.39 UF 400V
+/-5%
CAP. M.PP 0.001UF 1.6KV
+/-5%
CAP. M.PP 0.0027UF 1.6KV
+/-5%
CAP. M.PP 0.013 UF 1.6KV
+/-5%
TCL36-LIN180-XX1= COIL
LINEARITY 18 UH R
COIL CHOKE 600 UH
HOLLOW RIVET
1.6MMX3.0MMX3.2MM
ASS'Y - CRT BD
DIODE 1N4148 (SWITCHING)
TRANSISTOR ST2SA1015Y
(PNP)
Qty BOM text
Unit
1 PC
1 PC
1 PC
1 PC
1 PC
1 PC FOR DY COIL
1 PC
1 PC D405
1 PC D407
1 PC R318
1 PC R412
1 PC C275
1 PC C403
1 PC C421
1 PC C421A
1 PC C402
1 PC C406
1 PC L412
1 PC L411A
1 PC T402
2 PC FOR L411A
1 PC
D207;D501;D
3 PC
502
1 PC Q507
