Roper Whitney 0581 Operation Maintenance Manual & Parts List

Crimping and beading machine

MODEL NO. 0581 CRIMPING AND BEADING MACHINE

OPERATION, PARTS & MAINTENANCE MANUAL

Model:

Serial #:

Purchased From:

Date Received:

Table of Contents

Need help?

Do you have a question about the 0581 and is the answer not in the manual?

Page 1 MODEL NO. 0581 CRIMPING AND BEADING MACHINE OPERATION, PARTS & MAINTENANCE MANUAL Model: Purchased From: Serial #: Date Received:...
Page 2 FOREWORD This manual has been prepared for the owner and operators of Roper Whitney No. 0581 crimping and beading machine. Its purpose, aside from operations instructions, is to promote safety through the use of accepted operating procedures. Read all instructions thoroughly before operating the machine.
Page 3: Specifications
SAFETY Do not operate the No. 0581 machine without the proper safety label in place. If your machine is missing the following label please contact Roper Whitney Co. or your authorized Roper Whitney distributor to order. CAUTION: Be certain that the machine is securely bolted into the bench standard (1) and that the bench standard is securely clamped to the work bench.
Page 4 Lock securely with Roll Nuts (19). 6. Keep machine Arbors, Screws, Rocking Box, Journal Bearings and Gears lubricated with a medium (SAE 30) motor oil. “X” points should be lubricated daily with a good grade machine oil. MODEL 0581 ROLL CHART NAME CATALOG NO.
Page 5 MODEL 0581 PARTS IDENTIFICATION CHART...
Page 6 MODEL 0581 PARTS LIST ITEM PART NO. PART NAME REQ’D 239009750 #975 Bench Standard, Complete *BS1 746060001 Standard *BS2 746010002 Swivel Cap *BS3 746030003 Lever for Clamping Screw *BS4 746650004 Clamping Screw *BS5 633012227 SHSCP Screw 7/16-14 X 1 1/2...
