70 190X6&170X6 LCD
Go to cover page
Model:170X6FB/00
Mechanical Parts
0030 313815760401 BEZEL ASSY
0031 313815417001 BEZEL
0033 313815567471 LIGHTFRAME STICKER
0040 313815760411 BACK COVER ASSY
0041 313815417011 BACK COVER
0042 313815135811 HINGE-PLATE
0043 313815413491 OSD BUTTON
0044 313815413511 SKIN COVER
0050 313815757301 FOLDABLE BASE(S)
0097 313815413521 LOGO COVER(B)
0098 313815760421 SHIELDING ASSY
0100 313815137701 AC BRACKET
0101 313810440571 HOUSING COVER
0350 313815137711 SHIELDING
0351 313815321131 INSULATE PLATE
1057 313815864371 FRAME+WIRE ASSY
LCD PANEL
1050 823827718251 LCD LM170E01-TLA8
Packing
0450 313815640901 CARTON
0451 313815638251 CUSHION-R
0452 313815638261 CUSHION-L
0453 313815621491 P.E. BAG
PCB ASSY
1051 313815863031 SCALER PCB ASSY(1SC)
1052 313815859651 AUDIO ASSY
1053 313815862941 USB DOWN ASSY
1054 313815862951 USB UP ASSY
1055 823827717131 LIPS(EADP-43AF A)(POWER)
1056 313815859641 CONTROL ASSY
1065 313815863041 EAR PHONE PCB ASSY
Accessory
0602 313811708651 E-D.F.U.
1058 313815862911 SPEAKER BOX ASSY
1059 313818875051 SPEAKER CABLE(BLACK)
1060 313818877821 CORD SUB-D 15/1M8/SUB-D 15 M/M
1061 313812874931 MAINSCORD
1062 313819871401 CBLE-030 30/135/30-012 AWG28
1063 313819872531 CORD USB A/1M8/USB B BK
1070 313819875361 LSP BOX 16R 2W-L(PS-010017B)
1071 313819875371 LSP BOX 16R 2W-L(PS-010017C)
8061 313819875941 CBLE-023 13/215/12+2 AWG28
Miscellanea
0291 313815567551 LABEL-CPU
0295 313815567561 LABEL-EEPROM(L)
0615 313811708721 HEX CODE OF F/W(NO MATL REQ)
1201 242203300521 SOC DVI H 24P F
1203 242202518065 SOC SUBD H 15P F
1302 243803100435 SOC IC V 8P F 2.54 DIL
1410 243854300086 RES XTL SM 14M318 18P HC49/S R
1502 242202518824 CON V 11P M 2.00
1503 242202518089 CON V 12P M 2.00
1508 242202518814 CON V 2P M 2.00
1603 242202505572 CON H 30P M 1.25 SM
4444 313810610477 CD ROM - SERVICE MANUAL
4444 313810610478 SERVICE MANUAL
8062 313819875961 CBLE-385 5/150/5-385 AWG22
PCB ASSY
1051 313815863031 SCALER PCB ASSY(1SC)
2209 223878615649 CER2 0603 X7R 16V 100N PM10 R
2211 223886715331 CER1 0603 NP0 50V 330P PM5 R
2212 223886715331 CER1 0603 NP0 50V 330P PM5 R
2214 223878615649 CER2 0603 X7R 16V 100N PM10 R
2216 223886715331 CER1 0603 NP0 50V 330P PM5 R
2217 223886715331 CER1 0603 NP0 50V 330P PM5 R
2218 223886715339 CER1 0603 NP0 50V 33P PM5 R
2219 223886715221 CER1 0603 NP0 50V 220P PM5 R
2220 223878615649 CER2 0603 X7R 16V 100N PM10 R
2221 223878615649 CER2 0603 X7R 16V 100N PM10 R
2225 223858615636 CER2 0603 X7R 50V 10N PM10 R
2227 223858615636 CER2 0603 X7R 50V 10N PM10 R
2229 223858615636 CER2 0603 X7R 50V 10N PM10 R
2231 223858615636 CER2 0603 X7R 50V 10N PM10 R
2233 223878615649 CER2 0603 X7R 16V 100N PM10 R
2234 223878615649 CER2 0603 X7R 16V 100N PM10 R
2235 223878615649 CER2 0603 X7R 16V 100N PM10 R
2301 223878615649 CER2 0603 X7R 16V 100N PM10 R
2302 223878615649 CER2 0603 X7R 16V 100N PM10 R
2401 202002191778 ELCAP SM RVJ 16V 100U PM20 R
2402 202203100182 ELCAP SM RVS 25V 10U PM20 R
2403 223878615649 CER2 0603 X7R 16V 100N PM10 R
2404 223878615649 CER2 0603 X7R 16V 100N PM10 R
2405 223878615649 CER2 0603 X7R 16V 100N PM10 R
2406 223878615649 CER2 0603 X7R 16V 100N PM10 R
2407 223878615649 CER2 0603 X7R 16V 100N PM10 R
2408 202203100182 ELCAP SM RVS 25V 10U PM20 R
2409 223878615649 CER2 0603 X7R 16V 100N PM10 R
2410 223878615649 CER2 0603 X7R 16V 100N PM10 R
2411 223878615649 CER2 0603 X7R 16V 100N PM10 R
2412 223878615649 CER2 0603 X7R 16V 100N PM10 R
2413 223878615649 CER2 0603 X7R 16V 100N PM10 R
2414 223878615649 CER2 0603 X7R 16V 100N PM10 R
2415 223878615649 CER2 0603 X7R 16V 100N PM10 R
2416 223878615649 CER2 0603 X7R 16V 100N PM10 R
2417 223878615649 CER2 0603 X7R 16V 100N PM10 R
2418 202202000789 ELCAP SM LV 16V 10U PM20 R
2419 223878615649 CER2 0603 X7R 16V 100N PM10 R
2420 202202000789 ELCAP SM LV 16V 10U PM20 R
2421 223878615649 CER2 0603 X7R 16V 100N PM10 R
2422 202203100182 ELCAP SM RVS 25V 10U PM20 R
2423 223878615649 CER2 0603 X7R 16V 100N PM10 R
2424 223878615649 CER2 0603 X7R 16V 100N PM10 R
2425 223878615649 CER2 0603 X7R 16V 100N PM10 R
2426 223878615649 CER2 0603 X7R 16V 100N PM10 R
2427 223878615649 CER2 0603 X7R 16V 100N PM10 R
2428 202203100182 ELCAP SM RVS 25V 10U PM20 R
2429 202203100182 ELCAP SM RVS 25V 10U PM20 R
2430 202203100182 ELCAP SM RVS 25V 10U PM20 R
2431 223878615649 CER2 0603 X7R 16V 100N PM10 R
2432 223878615649 CER2 0603 X7R 16V 100N PM10 R
2433 223878615649 CER2 0603 X7R 16V 100N PM10 R
2434 223878615649 CER2 0603 X7R 16V 100N PM10 R
2435 202203100182 ELCAP SM RVS 25V 10U PM20 R
2436 223878615649 CER2 0603 X7R 16V 100N PM10 R
2437 202203100182 ELCAP SM RVS 25V 10U PM20 R
2438 223824619863 CER2 0603 Y5V 10V 1U P8020 R
2439 202203100182 ELCAP SM RVS 25V 10U PM20 R
2440 223878615649 CER2 0603 X7R 16V 100N PM10 R
2441 223878615649 CER2 0603 X7R 16V 100N PM10 R
2442 223878615649 CER2 0603 X7R 16V 100N PM10 R
2443 223878615649 CER2 0603 X7R 16V 100N PM10 R
2444 223878615649 CER2 0603 X7R 16V 100N PM10 R
2445 223878615649 CER2 0603 X7R 16V 100N PM10 R
2446 223878615649 CER2 0603 X7R 16V 100N PM10 R
2450 223886715478 CER1 0603 NP0 50V 4P7 PM0P25 R
2451 223886715478 CER1 0603 NP0 50V 4P7 PM0P25 R
2453 223858615632 CER2 0603 X7R 50V 4N7 PM10 R
2454 223858615636 CER2 0603 X7R 50V 10N PM10 R
2455 223858615636 CER2 0603 X7R 50V 10N PM10 R
1.91DVI-D Y
2456 223858615636 CER2 0603 X7R 50V 10N PM10 R
BU 900 Y
2457 223886715109 CER1 0603 NP0 50V 10P PM5 R
L
2460 223878615649 CER2 0603 X7R 16V 100N PM10 R
2461 222224119876 CER2 1206 Y5V 10V 10U P8020 R
63391 B
2462 222224119876 CER2 1206 Y5V 10V 10U P8020 R
63392 B
2501 223878615649 CER2 0603 X7R 16V 100N PM10 R
63382 B
2502 223878615649 CER2 0603 X7R 16V 100N PM10 R
60952 R
2503 202203100206 ELCAP SM HV 25V 47U PM20 R
2507 223878615649 CER2 0603 X7R 16V 100N PM10 R
2508 223878615649 CER2 0603 X7R 16V 100N PM10 R
2509 202203100206 ELCAP SM HV 25V 47U PM20 R
2510 223878615649 CER2 0603 X7R 16V 100N PM10 R
2511 223886715101 CER1 0603 NP0 50V 100P PM5 R
2512 223878615649 CER2 0603 X7R 16V 100N PM10 R
2514 223878615649 CER2 0603 X7R 16V 100N PM10 R
2515 223878615649 CER2 0603 X7R 16V 100N PM10 R
2516 223878615649 CER2 0603 X7R 16V 100N PM10 R
2517 223878615649 CER2 0603 X7R 16V 100N PM10 R
2518 223878615649 CER2 0603 X7R 16V 100N PM10 R
2519 223878615649 CER2 0603 X7R 16V 100N PM10 R
2520 223878615649 CER2 0603 X7R 16V 100N PM10 R
2521 202203100206 ELCAP SM HV 25V 47U PM20 R
2522 223878615649 CER2 0603 X7R 16V 100N PM10 R
2523 223878615649 CER2 0603 X7R 16V 100N PM10 R
2524 223858615636 CER2 0603 X7R 50V 10N PM10 R
2525 223878615649 CER2 0603 X7R 16V 100N PM10 R
2601 223878615649 CER2 0603 X7R 16V 100N PM10 R
2602 223878615649 CER2 0603 X7R 16V 100N PM10 R
2603 223878615649 CER2 0603 X7R 16V 100N PM10 R
2604 223878615649 CER2 0603 X7R 16V 100N PM10 R
2605 223878615649 CER2 0603 X7R 16V 100N PM10 R
2606 223878615649 CER2 0603 X7R 16V 100N PM10 R
2607 223878615649 CER2 0603 X7R 16V 100N PM10 R
2608 223878615649 CER2 0603 X7R 16V 100N PM10 R
2609 202203100182 ELCAP SM RVS 25V 10U PM20 R
2610 223878615649 CER2 0603 X7R 16V 100N PM10 R
2611 223878615649 CER2 0603 X7R 16V 100N PM10 R
2612 223878615649 CER2 0603 X7R 16V 100N PM10 R
2613 223878615649 CER2 0603 X7R 16V 100N PM10 R
2614 202203100182 ELCAP SM RVS 25V 10U PM20 R
2615 202203100182 ELCAP SM RVS 25V 10U PM20 R
2616 202203100182 ELCAP SM RVS 25V 10U PM20 R
2617 223878615649 CER2 0603 X7R 16V 100N PM10 R
2618 202203100182 ELCAP SM RVS 25V 10U PM20 R
2619 223878615649 CER2 0603 X7R 16V 100N PM10 R
2620 223878615649 CER2 0603 X7R 16V 100N PM10 R
2621 223878615649 CER2 0603 X7R 16V 100N PM10 R
2622 223878615649 CER2 0603 X7R 16V 100N PM10 R
2623 223878615649 CER2 0603 X7R 16V 100N PM10 R
2624 223878615649 CER2 0603 X7R 16V 100N PM10 R
2625 202203100182 ELCAP SM RVS 25V 10U PM20 R
2626 223878615649 CER2 0603 X7R 16V 100N PM10 R
2627 223878615649 CER2 0603 X7R 16V 100N PM10 R
2628 223878615649 CER2 0603 X7R 16V 100N PM10 R
2629 223878615649 CER2 0603 X7R 16V 100N PM10 R
2630 202203100182 ELCAP SM RVS 25V 10U PM20 R
2632 223878615649 CER2 0603 X7R 16V 100N PM10 R
2633 202203100182 ELCAP SM RVS 25V 10U PM20 R
2634 223878615649 CER2 0603 X7R 16V 100N PM10 R
2636 223878615649 CER2 0603 X7R 16V 100N PM10 R
2637 222224119876 CER2 1206 Y5V 10V 10U P8020 R
2638 223878615649 CER2 0603 X7R 16V 100N PM10 R
3202 212211805669 RST SM 0603 RC0603 10K PM5 R
3203 212211805669 RST SM 0603 RC0603 10K PM5 R
3204 212211805669 RST SM 0603 RC0603 10K PM5 R
3205 232270260223 RST SM 0603 RC21
3206 232270260101 RST SM 0603 RC21 100R PM5 R
3207 232270260101 RST SM 0603 RC21 100R PM5 R
3208 232270260102 RST SM 0603 RC21
3209 232270260104 RST SM 0603 RC21 100K PM5 R
3210 232270260101 RST SM 0603 RC21 100R PM5 R
3211 232270260101 RST SM 0603 RC21 100R PM5 R
3213 232270260102 RST SM 0603 RC21
3214 232270260472 RST SM 0603 RC21
3215 212211805669 RST SM 0603 RC0603 10K PM5 R
3216 232270260101 RST SM 0603 RC21 100R PM5 R
3217 232270260101 RST SM 0603 RC21 100R PM5 R
3219 212211805669 RST SM 0603 RC0603 10K PM5 R
3220 232270260223 RST SM 0603 RC21
3221 212211805669 RST SM 0603 RC0603 10K PM5 R
3222 212211805669 RST SM 0603 RC0603 10K PM5 R
3223 232270260101 RST SM 0603 RC21 100R PM5 R
3224 232270260101 RST SM 0603 RC21 100R PM5 R
3225 232270260101 RST SM 0603 RC21 100R PM5 R
3226 232270260101 RST SM 0603 RC21 100R PM5 R
3227 232270260222 RST SM 0603 RC21
3228 232270260222 RST SM 0603 RC21
3229 232270260104 RST SM 0603 RC21 100K PM5 R
3230 232270260102 RST SM 0603 RC21
3232 232270260101 RST SM 0603 RC21 100R PM5 R
3233 232270467509 RST SM 0603 RC22H 75R PM1 R
3234 232270260339 RST SM 0603 RC21
3235 232270467509 RST SM 0603 RC22H 75R PM1 R
3236 232270260101 RST SM 0603 RC21 100R PM5 R
3237 232270467509 RST SM 0603 RC22H 75R PM1 R
3238 232270296001 RST SM 0603 JUMP. MAX 0R05 R
3239 232270296001 RST SM 0603 JUMP. MAX 0R05 R
3240 232270296001 RST SM 0603 JUMP. MAX 0R05 R
3241 232270260472 RST SM 0603 RC21
3242 212211805669 RST SM 0603 RC0603 10K PM5 R
3245 232270260101 RST SM 0603 RC21 100R PM5 R
3246 232270260101 RST SM 0603 RC21 100R PM5 R
3301 212211805669 RST SM 0603 RC0603 10K PM5 R
3302 212211805669 RST SM 0603 RC0603 10K PM5 R
3316 212211805669 RST SM 0603 RC0603 10K PM5 R
3321 212211805669 RST SM 0603 RC0603 10K PM5 R
3322 212211805669 RST SM 0603 RC0603 10K PM5 R
3325 212211805669 RST SM 0603 RC0603 10K PM5 R
3326 232270260101 RST SM 0603 RC21 100R PM5 R
3327 232270260101 RST SM 0603 RC21 100R PM5 R
3401 232270260101 RST SM 0603 RC21 100R PM5 R
3402 232270260101 RST SM 0603 RC21 100R PM5 R
3404 232270260121 RST SM 0603 RC21 120R PM5 R
3405 232270260121 RST SM 0603 RC21 120R PM5 R
3406 232270260121 RST SM 0603 RC21 120R PM5 R
3408 232270461002 RST SM 0603 RC22H
3409 212211805639 RST SM 0603 RC0603 47R PM5 R
3410 235003510479 RST NETW SM ARV24 4X 47R PM5 R
22K PM5 R
1K PM5 R
1K PM5 R
4K7 PM5 R
22K PM5 R
2K2 PM5 R
2K2 PM5 R
1K PM5 R
33R PM5 R
4K7 PM5 R
1K PM1 R
