Technical Information

Technical Specifications

WEIGHT & DIMENSIONS
Length ......................................................................................................... 9.6 in (245 mm)
Width ........................................................................................................... 9.6 in (245 mm)
Height .......................................................................................................... 7.9 in (200 mm)
Weight .............................................................................................................. 8.8 lbs (4 kg)
POWER
Operating Voltage ............................................................................... 100~240 V, 50/60 Hz
Power Consumption ............................. 43.4 W (0.6 A) @ 120 V, 43.4 W (0.37 A) @ 230 V
Inrush Power ......................................................................... 0.4 A @ 120 V, 0.6 A@ 230 V
Power Factor .......................................................................... 0.52 @ 120 V, 0.61 @ 230 V
Power Output (power linking) ............. 20 units max @ 110 VAC, 40 units max @ 230 VAC
LIGHT SOURCE
LED .......................................................................... 36 x 1 W (12 Red, 12 Green, 12 Blue)
PHOTO OPTIC
Illuminance at 1 m (with included 15 degree lenses) ........................... 1,370 fc (14,741 lux)
Illuminance at 1 m (with optional 30 degree lenses) ................................. 385 fc (3,414 lux)
Beam Angle (with included 15 degree lenses) ............................................................. 11.6°
Field Angle (with included 15 degree lenses) ................................................................. 24°
Beam Angle (with optional 30 degree lenses) ............................................................. 24.8°
Field Angle (with optional 30 degree lenses) ............................................................... 46.5°
THERMAL
Maximum ambient temperature .................................................................... 104° F (40° C)
INGRESS PROTECTION
Rating ............................................................................................................................ IP66
FUSE
Internal PCB ................................................................ 20 mm, glass, 2 A, 250 V, Fast Blow
CONTROL & PROGRAMMING
Data input ............................................................................. locking 3-pin XLR male socket
Data output........................................................................ locking 3-pin XLR female socket
Data pin configuration ........................................................... pin 1 shield, pin 2 (-), pin 3 (+)
Protocols .................................................................................................. USITT DMX512-A
DMX Channels ...................................................................................................... 3, 4 and 9
ORDERING INFORMATION
COLORado 1 Black....................................................................................... COLORado1B
COLORado 1 Silver ...................................................................................... COLORado1S
WARRANTY INFORMATION
Warranty........................................................................................... 2-year limited warranty
14
COLORado 1 Quick Start Guide Rev. 02b
