Concord 4 Touch Screen Installation Sheet
Description
The Concord 4 Touch Screen, model 60-924-3-C4TS, features
a 3.5-inch color LCD screen with a graphical user interface
designed to control basic functionality of the Concord 4,
version 4.5 or later.
Multiple touch screens can be added to each Concord 4 panel.
An internal speaker provides system status beeps for trouble
and alarm indications.
The touch screen provides a convenient option for the
following system operations:
Easily obtain home/building status using At-A-Glance
(AAG) sensor status.
Arm the system (doors, windows, motion sensors, and
property).
Disarm the system.
Activate a panic alarm to call the central monitoring station
in a non-medical emergency.
Equipment
Alphanumeric keypad (for panel and end user
programming)
4-conductor, 22-gauge wire
#6 screws and anchors (included)
Super bus power supply (optional), PN 600-1019
Tools
2.5mm flat-blade screwdriver
#2 Phillips screwdriver
Drill and drill bits for opening wallboard (1/8- and 1/2-inch
bits)

Safety information

IMPORTANT SAFETY INFORMATION. READ ENCLOSED
WARNINGS AND SAFETY INFORMATION.
WARNING: CHOKING HAZARD.
bag contains items that could be choking hazards. Please keep
away from small children.
P/N 466-5224 • REV C• 6NOV2015
ATTENTION: Le sachet d'accessoires produit contient des
éléments qui pourraient être les dangers d'étouffement.
Veuillez garder hors de la portée des jeunes enfants.
Débrancher l'alimentation du panneau avant l'entretien.
handling electronic components. Utiliser les précautions de
l'électricite statique lors de la manipulation des composants
électroniques.
Installation
Installation guidelines
The touch screen is an auxiliary interface device and in its
current version cannot be used to program the Concord 4. A
full function alphanumeric keypad (such as Interlogix P/N 600-
1070 or 60-983) is required to be present. Consult the Concord
4 Installation Guide for selection of a full function alphanumeric
keypad.
Table 1: Touch Screen Power Usage
Current (mA)
250
100
40
The product accessory
WARNING:
Disconnect panel power before servicing.
CAUTION:
Use static electricity precautions when
The touch screen is not listed to UL Fire Standards and
may not be programmed for use with a Fire System in
California per CSFM Regulations.
Mount the touch screen in an environmentally-controlled
area (32°F to 120°F/0°C to 49°C).
Do not exceed the maximum available power given in the
panel. Refer to the total system power and guideline
section in Concord 4 installation instructions. See Table 1
for touch screen power usage and Table 2 for maximum
wire length between touch screen and panel.
Conditions
Maximum alarm current with the buzzer sounding
and the touch screen illuminated from a button
press
Typical operation
Power saving mode (no panel AC power)
1
