HISTORY INFORMATION FOR THE FOLLOWING MANUAL:
SERVICE MANUAL
MODEL NAME
KDF-55WF655
KDF-60WF655
ORIGINAL MANUAL ISSUE DATE: 9/2004
:UPDATED ITEM
REVISION DATE
9/2004
10/2004
1/2005
1/2005
8/2005
9-965-972-05
REMOTE COMMANDER
RM-Y915
RM-Y915
SUBJECT
No revisions or updates are applicable at this time.
Updated Block Diagram (Replaced Page 35 with Page 35)
Corrected PN for Cabinet Assembly Bottom, Added missing parts to Exploded View section
(Replaced Page 73 with Page 73, Replaced Page 74 with Page 74)
Added PN for Lamp and Washer (Replaced Page 122 with Page 122)
Corrected Section 2-1. Setting the Service Adjustment Mode and
2-2. Service Adjustment Mode Memory (Replaced Page 27 with Page 27)
Corrected Section 2-4. Remote Adjustment Buttons and Indicators (Replaced Page 28 with Page 28)
Updated contact information for Service Data requests (Replaced Page 30 with Page 30)
Updated contact information for Tiled Schematic requests (Replaced Last Page with Last Page)
Added Caution statement (Replaced Page 6 with Page 6)
Corrected location of LVDS Cables (Replaced Page 75 with Page 75)
LA-3
DESTINATION
US/CND
US/CND
LCD PROJECTION TELEVISION
CHASSIS
