- Page 1 Network Surveillance Recorder Release Note Software Version 1.2.0 NSR-S10/S20 Revision 2 (Last Modified: Oct. 5, 2011) © 2011 Sony Corporation...
- Page 2 TORT, CONTRACT, OR OTHERWISE, ARISING OUT OF OR IN CONNECTION WITH THIS DOCUMENT OR INFORMATION CONTAINED HEREIN OR THE USE THEREOF. Sony Corporation reserves the right to make any modification to this document or the information contained herein at any time without notice.
-
Page 3: Table Of Contents
1-1-1 Expansion of frame rate setting for live monitoring ..........1 1-1-2 External e-SATA storage capacity is enhanced to 4 TB ........... 1 1-2 The NSR-S10/S20 WebViewer and the NSR-S Viewer Supported Platforms ....1 1-2-1 Supported operating systems ..................1 1-2-2 System Requirements .................... - Page 4 6-2-1 Expanded camera support ..................18 6-2-2 Remote playback function ..................18 6-2-3 Language support ....................18 6-2-4 Auto add function for external storage ..............18 6-2-5 Unmounting function for external storage via alarm action ......... 19 6-2-6 Snapshot image size ....................19 7 Histories of resolved limitations ...................
-
Page 5: Nsr-S10/S20 Features
JPEG, MPEG-4 and H.264 images from up to four network cameras with the NSR-S10, and up to eight network cameras with the NSR-S20, via the network. The server also allows you to easily search for and play back previously recorded images. -
Page 6: System Requirements
NSR-S10/S20 V1.2.0 Release Note 1-2-2 System Requirements 1-2-2-1 CPU Pentium 4 3.0 GHz or better 1-2-2-2 Video cards 1024 x 768 pixels (32-bit color) or more 128 MB video memory and DirectDraw Capability 1-2-2-3 Network interface 100BASE-TX or better 1-2-2-4 Memory... -
Page 7: Information On Supported Cameras
*3 SNC‐RZ25P *1 The NSR-S10/S20 captures video for recording from these camera models at all times regardless of whether images are recorded or not. Only for monitoring images, the bit rate of recorded video must be considered in calculating network bandwidth. - Page 8 In such cameras, please do not change the aspect ratio to 4:3 (or Maximum image size in some cameras). If it is changed via web browser, the NSR-S10/S20 cannot communicate video settings with cameras correctly. (S10:199) So the maximum video size of the system for Recording is 1920x1080.
-
Page 9: Important Information
(S10:15,130) ・ Alarm recording The NSR-S10/S20 allows you not only to perform motion recording using a single camera but combine it with motion recording, sensor input and other conditions involving other cameras. To do this, select [No Recording] in "Recording Setting" and set alarm recording under [Action] on the "Alarm Setting"... -
Page 10: Main" Screen
NSR-S10/S20 may reduce recording to a maximum of 1 fps (1 frame per second) before recording caused by motion detection or triggered by an alarm. (S10:86) The recording duration prior to motion detection and occurrence of a trigger event can be set to up to 10 seconds in the "Setting Screen,"... -
Page 11: Webviewer
In [Change User Account Control Settings], drag the slider all the way to the bottom Note If Internet Explorer is started up without administrator privileges, Internet Explorer will freeze when NSR-S10/S20 is accessed. Should this occur, force quit Internet Explorer or restart the PC. - 7 -... - Page 12 NSR-S10/S20 V1.2.0 Release Note After making a connection without administrator privileges, delete the files given below from Program Files on the C drive. Then start up Internet Explorer with administrator privileges and connect to the NSR-S10/S20. C:\Program Files\remoteAP - 8 -...
-
Page 13: Precautions
NSR-S10/S20. A USB flash memory device formatted on the NSR-S10/S20 cannot be used for importing in Windows as the file format differs. To enable use with Windows, a memory device formatted on the NSR-S10/S20 will have to be reformatted on the destination device. - Page 14 NSR-S10/S20 V1.2.0 Release Note Starting up the NSR-S10/S20 will automatically log on to the NSR as admin. To log on as user, first log in as admin and edit user in the user settings to change the password. (S10:117) ・ At startup, the NSR-S10/S20 has a function that causes it to automatically register the factory defaults of the camera.
-
Page 15: Main" Screen
NSR-S10/S20 V1.2.0 Release Note 3-2 "Main" screen ・ The NSR-S10/S20 allows you to control the pan, tilt and zoom functions of the SNC-RZ25/RZ50 cameras in the LIVE screen using a mouse or remote control. It also allows you to move these cameras to Preset positions using a mouse or remote commander. -
Page 16: Nsr-S Viewer
3-4 WebViewer ・ A PC running WebViewer allows you to record AVI video files. However, no audio is recorded and you will have to use the NSR-S10/S20 to record audio. (S10:74) 3-5 Other Details ・ When registering a SNC-RZ25 in the factory default condition with auto registration, it might take 1 minute per camera. -
Page 17: Limitations
LIVE screen: Video Size of Display setting PLAYBACK screen: Video Size of Recording setting ・ The issue that the internal clock in the NSR-S10 was inaccurate has been solved. (S10:40) ・ The SNC-RZ25/RZ50 uses a single video stream for recording and display. -
Page 18: Main" Screen
NSR-S10/S20 may erroneously "think" that motion was detected and start recording even when the camera has not captured any video. -
Page 19: Note
NSR-S10/S20 V1.2.0 Release Note Note 5-1 NRS-S Viewer Operating Procedures 5-1-1 Operating Procedures 1. Insert the USB flash memory device containing the video exported from NSR-S10/S20 in the PC. 2. Copy the “Backup” folder on the USB flash memory device to the PC. - Page 20 NSR-S10/S20 V1.2.0 Release Note Note When using the Export (Output Video Clip) function, date including video files is displayed with bold in the calendar area. However, time and camera are not shown in the selection area. Push [Open File] button and select video file directly.
-
Page 21: Starting Up From Webviewer
NSR-S10/S20 V1.2.0 Release Note 5-1-3 Starting up from WebViewer You can play back video recorded on the NSR-S10/S20 unit by downloading NSR-S Viewer from the NSR-S10/S20 unit onto the PC that is running WebViewer. When you click the [PLAYBACK] button in the WebViewer screen, a selection screen with two playback options appears. -
Page 22: Histories Of Additional Features
SNC-CH220, SNC-DH220, SNC-DH220T, SNC-CH260, SNC-DH260 6-2-2 Remote playback function You can now play back video recorded on the NSR-S10 unit from WebViewer. When you click the [PLAYBACK] button on the WebViewer screen, NSR-S Viewer is downloaded onto the PC from the NSR-S10 unit. For details on using NSR-S Viewer, refer to “5-1 NSR-S Viewer Operating Procedures.”... -
Page 23: Unmounting Function For External Storage Via Alarm Action
NSR-S10/S20 V1.2.0 Release Note been added and recording starts, if you are using the unit without a monitor connected, it is recommended that you also confirm whether data is being written to the disk by checking whether the HDD LED on the front of the unit is flashing. -
Page 24: Histories Of Resolved Limitations
You can now turn off the unit without password authentication. (S10:76) ・ Previously, only events for sensor inputs from the NSR-S10 unit were recorded in the “Event Log,” and events for sensor inputs from cameras were not recorded and could not be searched with “Event Search.”...
