- Page 1 DDC-6, DDC-12 LCD DMX controller user manual...
- Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 16.09.2016, ID: 389945, 389946...
-
Page 3: Table Of Contents
1.1 Further information........................... 5 1.2 Notational conventions........................6 1.3 Symbols and signal words....................... 6 Safety instructions............................. 8 Features............................... 13 Starting up..............................14 Connections and controls........................17 Technical specifications........................25 Plug and connection assignment....................26 Protecting the environment......................27 DDC-6, DDC-12 LCD... -
Page 4: General Information
General information General information This manual contains important instructions for the safe operation of the unit. Read and follow the safety instructions and all other instructions. Keep the manual for future reference. Make sure that it is available to all those using the device. If you sell the unit please make sure that the buyer also receives this manual. -
Page 5: Further Information
Our online guides provide detailed information on technical basics Online guides and terms. Personal consultation For personal consultation please contact our technical hotline. If you have any problems with the device the customer service will Service gladly assist you. DDC-6, DDC-12 LCD... -
Page 6: Notational Conventions
General information 1.2 Notational conventions This manual uses the following notational conventions: Letterings The letterings for connectors and controls are marked by square brackets and italics. Examples: [VOLUME] control, [Mono] button. 1.3 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this manual. - Page 7 NOTICE! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in material and environmental damage if it is not avoided. Warning signs Type of danger Warning – danger zone. DDC-6, DDC-12 LCD...
-
Page 8: Safety Instructions
Safety instructions Safety instructions Intended use This device is used to control spotlights, dimmers, lighting effects equipment or other DMX- controlled devices. Use the device only as described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage. - Page 9 They could swallow the pieces and choke! Never let children unattended use electrical devices. NOTICE! Risk of fire Do not block areas of ventilation. Do not install the device near any direct heat source. Keep the device away from naked flames. DDC-6, DDC-12 LCD...
- Page 10 Safety instructions NOTICE! Operating conditions This device has been designed for indoor use only. To prevent damage, never expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and strong vibrations. NOTICE! External power supply The device is powered by an external power supply. Before connecting the external power supply, ensure that the input voltage (AC outlet) matches the voltage rating of the device and that the AC outlet is protected by a residual cur‐...
- Page 11 Ensure that proper polarity is observed when inserting batteries. NOTICE! Possible damage by leaking batteries Leaking batteries can cause permanent damage to the device. Take batteries out of the device if it is not going to be used for a longer period. DDC-6, DDC-12 LCD...
- Page 12 Safety instructions NOTICE! Possible staining The plasticiser contained in the rubber feet of this product may possibly react with the coating of your parquet, linoleum, laminate or PVC floor and after some time cause permanent dark stains. In case of doubt, do not put the rubber feet directly on the floor, but use felt-pad floor protectors or a carpet.
-
Page 13: Features
Features Features Special features of this monitor speaker: 6 channel faders (DDC-6 item no. 389945) 12 channel faders (DDC-12 item no. 389946) Master fader Display to indicate the settings. Compact design Simple operation Power supply from a 9-V battery (not included in scope of delivery) or from the supplied external 9-V power adapter. -
Page 14: Starting Up
Starting up Starting up Unpack and carefully check that there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the device against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively. - Page 15 Possible data transmission errors For error-free operation make use of dedicated DMX cables and do not use ordi‐ nary microphone cables. Never connect the DMX input or output to audio devices such as mixers or ampli‐ fiers. DDC-6, DDC-12 LCD...
- Page 16 Starting up Connections in DMX mode Connect the DMX input of the device to the DMX output of a DMX controller or another DMX device. Connect the output of the first DMX device to the input of the second one, and so on to form a daisy chain.
-
Page 17: Connections And Controls
Connections and controls Connections and controls Top view DDC-6, DDC-12 LCD... - Page 18 Connections and controls 1 [DISPLAY] DMX channel display and value display of the values set witht he faders. 2 [MASTER] Master fader. The master fader controls all channels simultaneously. 3 [1] … [6] Channel faders 1 through 6. The channel faders allow up to six DMX channels to be controlled individually. In the device software, assign each con‐ nected DMX devices a channel in accordance with its position in the daisy chain: first device = 1 …...
- Page 19 Connections and controls DDC-6, DDC-12 LCD...
- Page 20 Connections and controls 1 [DISPLAY] DMX channel display and value display of the values set with the faders. 2 [MASTER] Master fader. The master fader controls all channels simultaneously. 3 [1] … [6] Channel faders 1 through 12. The channel faders allow up to six DMX channels to be controlled individually. In the device software, assign each con‐ nected DMX devices a channel in accordance with its position in the daisy chain: first device = 1 …...
- Page 21 Connections and controls Rear side DDC-6 DDC-6, DDC-12 LCD...
- Page 22 Connections and controls 5 [ON/OFF] Main switch. Turns the device on and off. 6 [DC INPUT] Connecting socket for power supply unit. 7 [DMX OUT] DMX output. DMX controller...
- Page 23 Connections and controls Rear side DDC-12 DDC-6, DDC-12 LCD...
- Page 24 Connections and controls 4 [POWER] Main switch. Turns the device on and off. 5 [DC INPUT] Connecting socket for power supply unit. 6 [DMX OUT] DMX output. DMX controller...
-
Page 25: Technical Specifications
Technical specifications Technical specifications DDC-6 item no 389945 DDC-12 item no 389946 Output XLR socket, 3-pin Operating supply voltage 9-V power adapter , 100mA 9-V radio battery 6LR61 or 6LF22 Dimensions (W × D × H) 166 mm × 54 mm × 134 mm 275 mm ×... -
Page 26: Plug And Connection Assignment
Plug and connection assignment Plug and connection assignment Introduction This chapter will help you select the right cables and plugs to connect your valuable equip‐ ment so that a perfect light experience is guaranteed. Please take our tips, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into a socket, the result of an incorrect connection may be a destroyed DMX controller, a short circuit or ‘just’... -
Page 27: Protecting The Environment
Batteries must not be disposed of as domestic waste or thrown into fire. Dispose of the bat‐ teries according to national or local regulations regarding hazardous waste. To protect the environment, dispose of empty batteries at your retail store or at appropriate collection sites. DDC-6, DDC-12 LCD... - Page 28 Protecting the environment Disposal of your old device This product is subject to the European Waste Electrical and Electronic Equipment Directive (WEEE). Do not dispose with your normal household waste. Dispose this device through an approved waste disposal firm or through your local waste facility.
- Page 29 Notes DDC-6, DDC-12 LCD...
- Page 30 Notes DMX controller...
- Page 32 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
