Sharp Plasmacluster IG-GC2A Operation Manual

Ion generator.
Hide thumbs

Advertisement

"Plasmacluster" and "Device of a cluster of
grapes" are trademarks of Sharp Corporation.
IG-GC2A
Read and store this manual carefully.
IG-GC2_EN.indd 1
IG-GC2_EN.indd 1
*1
*1 The number on this technical mark indicates the
number of ion per 1cm
measured near the center of space (0.5m height from
fl oor) when the air volume is "MED" by placing the unit
in an appropriate place such as a cup holder beside
the driver's seat.
Plasmacluster Ion Generator
OPERATION MANUAL
HD PCI
3
blown out to the air, which is
6/30/2559 BE 10:42 AM
6/30/2559 BE 10:42 AM

Advertisement

   Related Manuals for Sharp Plasmacluster IG-GC2A

No related manuals

   Summary of Contents for Sharp Plasmacluster IG-GC2A

  • Page 1 Plasmacluster Ion Generator "Plasmacluster" and "Device of a cluster of OPERATION MANUAL grapes" are trademarks of Sharp Corporation. HD PCI IG-GC2A *1 The number on this technical mark indicates the number of ion per 1cm blown out to the air, which is measured near the center of space (0.5m height from...
  • Page 2: Table Of Contents

    IG-GC2A will stop operating after about 6 years and 6 months (19,000 hours) if the Plasmacluster Ion Generating Unit is not replaced. Thank you for purchasing this SHARP Plasmacluster Ion Generator. Please read this manual carefully before using Plasmacluster Ion Generator. After reading, keep the manual in a convenient location for future reference.
  • Page 3: Important Safety Instructions

    • When transporting, be careful not to drop the unit or subject it to shocks. (Doing so could cause injury or damage.) If the unit should drop or be damaged, contact your store of purchase or SHARP authorized service center.
  • Page 4 • Do not place the unit in a place where it is exposed to oil smoke or moisture such as kitchen counter or humidifying device. (Doing so could lead to electric shock.) • Do not place the unit near heating equipment such as the outlet of hot-air type heater.
  • Page 5: Parts Name

    PARTS NAME MAIN UNIT • CONTROL PANEL/DISPLAY CONTROL PANEL/DISPLAY Louver Turbo Light See E-5 Operation (Purple) Air Outlet Button See E-7 Operation Light (Blue) Unit Replacing Light (Red) See E-10 If the Plasmacluster Ion Generating Unit replacement time comes, Main Unit Unit Replacing Light fl...
  • Page 6: Installation Guidance

    INSTALLATION GUIDANCE Connecting the car adapter and installing the unit Insert the car adapter into the accessory socket and connect the USB plug to the car adapter. Note • Be sure to remove any dirt from the Car Adapter accessory socket. Failure to do so could cause faulty contact or fi...
  • Page 7 Cautions on wiring the car adapter • Do not let the cord touch or get caught in the seat rails, shift lever or other moving parts. • Wire in such a way that the cord does not get in the way of the driver. •...
  • Page 8: Operation

    OPERATION To select the preferred mode If you want to operate the product in silence Press Release high-density Plasmacluster ions quietly. MODE If you want to operate the product at a strong fl ow rate Press to change Release high-density Plasmacluster the air volume.
  • Page 9: Cleaning And Maintenance

    CLEANING AND MAINTENANCE FILTER Frequently as necessary The fi lter must be cleaned regularly in order to maintain the ion density. Filter soiling depends on the usage environment, so clean the fi lter frequently as necessary. With frequent cleaning, Plasmacluster ions can be released effi ciently. Main Unit Cover Open Close...
  • Page 10 Plasmacluster Ion Generating Unit (Electrode section) Every 6 months or more often if necessary How to remove the unit holder 1 Remove the fi lter cover. (see E-8) Main Unit 2 Pull up the main unit cover. Cover 3 Pull out the unit holder. Unit Holder Remove dusts from the electrodes by the unit cleaning brush (see E-4).
  • Page 11: Plasmacluster Ion Generating Unit Replacement

    PLASMACLUSTER ION GENERATING UNIT REPLACEMENT If the total operating time passes approximately 17,500 hours (approx. 6 years if the product is operated 8 hours a day), the Unit Replacing Light fl ashes to notify you of the replacement time of the unit. * The unit replacement period is the same regardless of the operation mode.
  • Page 12: Specifications

    How to replace the Plasmacluster Ion Generating Unit Take out the unit holder. (see E-9) Remove the claw Remove the claw of unit holder and remove the Plasmacluster Ion Generating Unit. Please do not dispose of the unit holder. Insert to the claw. 1 Attach a new Plasmacluster Ion Generating Unit to the unit holder.
  • Page 13: Troubleshooting

    (See E-9) • If the lights fl ash repeatedly, contact the store of purchase or SHARP authorized service center. • Is the Plasmacluster Ion Generating Unit installed correctly? Pull out the unit and insert it again and then press the operation button.
