TOP CASE & LCD PARTS ASSEMBLY
Ref.No.
Part No. Part Name & DescriptionPcs
1
VYK2E76
LCD U
1-1
VYK2G36
LCD 1U
1-2
VXD0506
HINGE U
1-3
A4LZFE000002 LCD BACK LIGHT
1-4
VMZ3709
LCD BARRIER
1-5
VMZ3708
SHADING PLATE
2
VGQ6901
MONITOR KNOB
3
VGU0B43
RUBBER BUTTON
4
VGU0B44
ORERATION BUTTON
5
VGU9197
MONITOR LOCK KNOB
6
VGU9207
HANDLE S/S BUTTON
7
VHN0382
NYLON NUT
8
VKM7166
TOP CASE
9
VMB3659
MONITOR OPENER SPRING
10
VMB3996
POP UP SPRING
11
VMG1286
CUSHION RUBBER
12
VMG1799
HEADPHONE CAP
13
VMP7331
OPENER HOLDER ANGLE
14
VMS7187
LCD LOCK SHAFT
15
VMX0531
CLATCH SPACER
16
VWJ06H2033L0 FFC
17
VGQ9463
LCD HINGE COVER FRONT
18
VMZ3711
FPC LOCK SHEET
19
VWJ30H2070L0 LCD IF FFC
20
VMZ3756
FFC BARRIER
21
VQL1Q78
LCD CAUTION LABEL
22
VGL1245
LED LENS
23
VMZ3757
FPC PROTECTION SHEET A
24
VMT1896
FPC HOLD CUSHION
101
XYN2+J6FJ
SCREW
102
XQN2+B4FN
SCREW
103
XTB2+6GFJ
SCREW
104
XQN16+B4FJK
SCREW
107
XYN2+J6FJ
SCREW
E7
VEP001S5A
TOP OP C.B.A.
E9
VEP03H21A
LCD C.B.A.
E12
VEP001T1A
LCD SENSOR C.B.A.
E13
VEP04928A
HEADPHONE C.B.A.
Remarks
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1 6PIN 33MM
1
1
1
1
1
1
1
1
8
2
2
4
2
1
1
1
1
MPL-4
Ref.No.
Part No. Part Name & DescriptionPcs
Remarks
