S/M No: FRSU20IA01
Refrigerator
✔ Caution
: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Center
July . 2005
Advertisement
Related Manuals for Daewoo FRS-U20IA Series
Summary of Contents for Daewoo FRS-U20IA Series
- Page 1 S/M No: FRSU20IA01 Refrigerator ✔ Caution : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information,please refer to PPL(Parts Price List) in Service Information Center July .
-
Page 2: Exploded View And Parts List
12. EXPLODED VIEW & PARTS LIST 12-1. FRS(N)-U20IA CABINET... - Page 3 MECH ROOM...
- Page 4 R ROOM...
- Page 5 F ROOM...
- Page 6 F DOOR...
- Page 7 R DOOR...
- Page 8 PART CODE PART NAME Q'ty SPECIFICATION REMARK 3000057700 ASSY CAB URT FRU-571I 3012924400 HINGE *T *R AS PO T3.0+PAINT 3012924300 HINGE *T *L AS PO T3.0+PAINT 3016042300 SPECIAL *T HI BOLT 6X13 SWCH18A 3011446200 COVER *T HI *R 3011446100 COVER *T HI *L 7112401211 SCREW TAPPING T1 TRS 4X12 MFZN...
- Page 9 PART CODE PART NAME Q'ty SPECIFICATION REMARK 3011200500 CLAMP FAN SUS 304 3016808100 DRYER AS C1220T-M OD19.05XL135 3011497000 COVER MACH ROOM AS SBHG T0.35 7112401211 SCREW TAPPING T1 TRS 4X12 MFZN 3012214100 FRAME CHECK VALVE AS FRU-571I 3012023700 FIXTURE MOTOR S3 PP(NATURAL) 3010107100 ABSORBER MOTOR...
- Page 10 PART CODE PART NAME Q'ty SPECIFICATION REMARK 3017053500 EVA AS FRU-571I 79-1 3012818300 HEATER SHEATH AS AC220V/ 192W 79-2 3014806900 SENSOR D AS PBN-43 79-3 3012023600 FIXTURE D SENS 79-4 3017202000 FUSE TEMP AS AC250V 10A 77C 79-5 4017Z90590 FIXTURE FUSE TEMP 3012529000 GUIDE DRN 7122401211...
- Page 11 PART CODE PART NAME Q'ty SPECIFICATION REMARK 3012641500 HANDLE AS FRU-571I 3016002700 SPECIAL SCREW WASR+TRS5X16 MFZN 3010339500 BASE HANDLE *T HIPS 3010339600 BASE HANDLE *U HIPS 7112401211 SCREW TAPPING T1 TRS 4*12 MFZN 3011446400 COVER HNDL DECO *T ABS+SPRAY 3011446500 COVER HNDL DECO *U ABS+SPRAY 3019027500...
- Page 12 12-2. FRS(N)-U20DA CABINET...
- Page 13 MECH ROOM...
- Page 14 R ROOM...
- Page 15 F ROOM...
- Page 16 F DOOR...
- Page 17 R DOOR...
- Page 18 PART CODE PART NAME Q'ty SPECIFICATION REMARK 3000057710 ASSY CAB URT FRU-541D 3012924400 HINGE *T *R AS PO T3.0+PAINT 3012924300 HINGE *T *L AS PO T3.0+PAINT 3016042300 SPECIAL *T HI BOLT 6X13 SWCH18A 7051401065 SCREW MACHINE PAN 4X10 SW BSNI 3011446200 COVER *T HI *R 3011446100...
- Page 19 PART CODE PART NAME Q'ty SPECIFICATION REMARK 3811402200 COVER RELAY MK4A5Q-R1U S/S (R600A) 3011181300 CASE VAPORI AS 3013201710 HOSE DRN B PE FRB-5970NB 3015402300 VALVE WATER AS FR-S660CW 3014461510 PIPE WICON AS TSW OD4.76XT0.7 3012021700 FIXTURE MOTR 3015916100 MOTOR C FAN AS DC-2213DWCA-3 3018500300 M/BELL B...
- Page 20 PART CODE PART NAME Q'ty SPECIFICATION REMARK 3011446700 COVER VEGETB CASE B GPPS 3012529700 GUIDE CASE C *L AS 3012529800 GUIDE CASE C *R AS 3011114700 CASE VEGETB C AS CASE+SILK+FRAME+KNOB 3018701800 DEO ANTI AS W40XT5XL40 3011445900 COVER RETURN DUCT 3011171310 CASE EGG AS CASE+VINYL...
- Page 21 PART CODE PART NAME Q'ty SPECIFICATION REMARK 3017906600 SOCKET F LAMP AS 250V 1A 3013602500 LAMP 240V 25W 7112401211 SCREW TAPPING T1 TRS 4X12 MFZN 3015510700 WINDOW F LAMP MIPS 3016002720 SPECIAL CAP SCREW SM18C 3014807000 SENSOR F AS PT-38 3011442600 COVER F SENS 3018128500...
- Page 22 PART CODE PART NAME Q'ty SPECIFICATION REMARK 3015402000 VALVE SOL DISP CUBE SN8 3018125800 SWITCH MICRO VP333A-2D 3012213200 FRAME DISPNS BUTTON 3016304600 BUTTON DISPNS SILICON 3012406900 GRILL DISPENSER 3019027500 POCKET DAIRY AS POCKET+COVER 3019027200 POCKET R *M AS BASE+DECO+SILK 3019027300 POCKET R *S AS BASE+DECO+SILK 3000060500...
- Page 23 12-3. FRS(N)-U20EA CABINET...
- Page 24 MECH ROOM...
- Page 25 R ROOM...
- Page 26 F ROOM...
- Page 27 F DOOR...
- Page 28 R DOOR...
- Page 29 PART CODE PART NAME Q'ty SPECIFICATION REMARK 3000057710 ASSY CAB URT FRU-541D 3012924400 HINGE *T *R AS PO T3.0+PAINT 3012924300 HINGE *T *L AS PO T3.0+PAINT 3016042300 SPECIAL *T HI BOLT 6X13 SWCH18A 7051401065 SCREW MACHINE PAN 4X10 SW BSNI 3011446200 COVER *T HI *R 3011446100...
- Page 30 PART CODE PART NAME Q'ty SPECIFICATION REMARK 3811402200 COVER RELAY MK4A5Q-R1U S/S (R600A) 3011181300 CASE VAPORI AS 3013201710 HOSE DRN B PE FRB-5970NB 3015402300 VALVE WATER AS FR-S660CW 3014461510 PIPE WICON AS TSW OD4.76XT0.7 3012021700 FIXTURE MOTR 3015916100 MOTOR C FAN AS DC-2213DWCA-3 3018500300 M/BELL B...
- Page 31 PART CODE PART NAME Q'ty SPECIFICATION REMARK 3011114600 CASE VEGETB B AS CASE+SILK+FRAME+KNOB 3018701800 DEO ANTI AS W40XT5XL40 3011445900 COVER RETURN DUCT 3016767100 DAMPER AS DU24-012 3011450900 COVER DUCT CH RM AS PP+SEAL 3012529500 GUDIE CHANGE RM *L 3012529600 GUDIE CHANGE RM *R 3011446800 COVER CHANGE RM GPPS...
- Page 32 PART CODE PART NAME Q'ty SPECIFICATION REMARK 3010968600 CAP F LOUVER B HIPS 3018921500 LOUVER F B AS HIPS 3011443200 COVER F RETURN HIPS 7122401611 SCREW TAPPING T2S TRS 4X16 MFZN 3010924600 CAP F LOUVER HIPS 3012013200 FIXTURE C 3012205600 FRAME ICE MAKER HIPS 3000025920...
- Page 33 PART CODE PART NAME Q'ty SPECIFICATION REMARK 7112401211 SCREW TAPPING T1 TRS 4*12 MFZN 3011446400 COVER HNDL DECO *T ABS+SPRAY 3011446500 COVER HNDL DECO *U ABS+SPRAY 3017903702 SOCKET DISP LAMP AS 250V 1A 14BASE 3013600020 LAMP 240V/15W(E14,CC5A) 3010544000 BOX DISPNS ICE SHUT AS FRU-541D 3011494700 COVER DISPNS BOX AS...
- Page 34 12-4. FRS(N)-U20FA CABINET...
- Page 35 MECH ROOM...
- Page 36 R ROOM...
- Page 37 F ROOM...
- Page 38 F DOOR...
- Page 39 R DOOR...
- Page 40 PART CODE PART NAME Q'ty SPECIFICATION REMARK 3000057710 ASSY CAB URT FRU-541D 3012924400 HINGE *T *R AS PO T3.0+PAINT 3012924300 HINGE *T *L AS PO T3.0+PAINT 3016042300 SPECIAL *T HI BOLT 6X13 SWCH18A 7051401065 SCREW MACHINE PAN 4X10 SW BSNI 3011446200 COVER *T HI *R 3011446100...
- Page 41 PART CODE PART NAME Q'ty SPECIFICATION REMARK 3811402200 COVER RELAY MK4A5Q-R1U S/S (R600A) 3011181300 CASE VAPORI AS 3013201710 HOSE DRN B PE FRB-5970NB 3015402300 VALVE WATER AS FR-S660CW 3014461510 PIPE WICON AS TSW OD4.76XT0.7 3012021700 FIXTURE MOTR 3015916100 MOTOR C FAN AS DC-2213DWCA-3 3018500300 M/BELL B...
- Page 42 PART CODE PART NAME Q'ty SPECIFICATION REMARK 3011446700 COVER VEGETB CASE B GPPS 3012529700 GUIDE CASE C *L AS 3012529800 GUIDE CASE C *R AS 3011114700 CASE VEGETB C AS CASE+SILK+FRAME+KNOB 3018701800 DEO ANTI AS W40XT5XL40 3011445900 COVER RETURN DUCT 3011171310 CASE EGG AS CASE+VINYL...
- Page 43 PART CODE PART NAME Q'ty SPECIFICATION REMARK 3017906600 SOCKET F LAMP AS 250V 1A 3013602500 LAMP 240V 25W 7112401211 SCREW TAPPING T1 TRS 4X12 MFZN 3015510700 WINDOW F LAMP MIPS 3016002720 SPECIAL CAP SCREW SM18C 3014807000 SENSOR F AS PT-38 3011442600 COVER F SENS 3018128500...
- Page 44 PART CODE PART NAME Q'ty SPECIFICATION REMARK 3015402000 VALVE SOL DISP CUBE SN8 3018125800 SWITCH MICRO VP333A-2D 3012213200 FRAME DISPNS BUTTON 3016304600 BUTTON DISPNS SILICON 3012406900 GRILL DISPENSER 3019027500 POCKET DAIRY AS POCKET+COVER 3019027200 POCKET R *M AS BASE+DECO+SILK 3011187000 CASE H/BAR AS CASE+DOOR 3019027700...
- Page 45 12-5. FRS(N)-U20GA CABINET...
- Page 46 MECH ROOM...
- Page 47 R ROOM...
- Page 48 F ROOM...
- Page 49 F DOOR...
- Page 50 R DOOR...
- Page 51 PART CODE PART NAME Q'ty SPECIFICATION REMARK 3000057710 ASSY CAB URT FRU-541D 3012924400 HINGE *T *R AS PO T3.0+PAINT 3012924300 HINGE *T *L AS PO T3.0+PAINT 3016042300 SPECIAL *T HI BOLT 6X13 SWCH18A 7051401065 SCREW MACHINE PAN 4X10 SW BSNI 3011446200 COVER *T HI *R 3011446100...
- Page 52 PART CODE PART NAME Q'ty SPECIFICATION REMARK 3811402200 COVER RELAY MK4A5Q-R1U S/S (R600A) 3011181300 CASE VAPORI AS 3013201710 HOSE DRN B PE FRB-5970NB 3015402300 VALVE WATER AS FR-S660CW 3014461510 PIPE WICON AS TSW OD4.76XT0.7 3012021700 FIXTURE MOTR 3015916100 MOTOR C FAN AS DC-2213DWCA-3 3018500300 M/BELL B...
- Page 53 PART CODE PART NAME Q'ty SPECIFICATION REMARK 3011114600 CASE VEGETB B AS CASE+SILK+FRAME+KNOB 3018701800 DEO ANTI AS W40XT5XL40 3011445900 COVER RETURN DUCT 3016767100 DAMPER AS DU24-012 3011450900 COVER DUCT CH RM AS PP+SEAL 3012529500 GUDIE CHANGE RM *L 3012529600 GUDIE CHANGE RM *R 3011446800 COVER CHANGE RM GPPS...
- Page 54 PART CODE PART NAME Q'ty SPECIFICATION REMARK 3010968600 CAP F LOUVER B HIPS 3018921500 LOUVER F B AS HIPS 3011443200 COVER F RETURN HIPS 7122401611 SCREW TAPPING T2S TRS 4X16 MFZN 3010924600 CAP F LOUVER HIPS 3012013200 FIXTURE C 3012205600 FRAME ICE MAKER HIPS 3000025920...
- Page 55 PART CODE PART NAME Q'ty SPECIFICATION REMARK 7112401211 SCREW TAPPING T1 TRS 4*12 MFZN 3011446400 COVER HNDL DECO *T ABS+SPRAY 3011446500 COVER HNDL DECO *U ABS+SPRAY 3017903702 SOCKET DISP LAMP AS 250V 1A 14BASE 3013600020 LAMP 240V/15W(E14,CC5A) 3010544000 BOX DISPNS ICE SHUT AS FRU-541D 3011494700 COVER DISPNS BOX AS...
- Page 56 DAE WOO E LE CTR ONICS COR P. 686, AHY E ON-DONG , MAP O-G U, S E OUL, K OR E A. C .P .O. B OX 8003 S E OUL K OR E A PR INTE D DATE : JULY 2005...
