Page 1: Installation Guide
SY-2A-20W Installation Guide 20W Power Amplifier SY Electronics Ltd, Unit 7, Worrall Street, Salford, Greater Manchester, M5 4TH, United Kingdom Tel: +44 (0) 161 868 3450 – Fax: +44 (0) 161 868 3459 – www.sy.co.uk... -
Page 2: Connectors And Controls
SY-2A-20W The SY-2A-20W is a 20W stereo Power Amplifier that may be used with other SY HD-BaseT products, or with the SY-HD-3.5AD HDMI Audio De-embedder, or even as standalone amplifier. This amplifier also features a voiceover capability that will allow its use in presentation applications. - Page 3 SY-2A-20W Rear Name Description 24V DC 24V DC Power input – only use the power supply provided Line Out Stereo 3.5mm line out signal Speakers Connect the speakers in accordance with the amplifier configuration switch Name Description Input Select Amplifier input 1 or 2 selection...
- Page 4 1 x 40W @ 8R Second, decide on the microphone connector mode. Do not switch to 48V phantom power mode while the SY-2A-20W unit is powered up as this may damage the power amplifier MIC / LINE input, the microphone, or both.
-
Page 5: Rs232 Control Commands
The SY-2A-20W can be cascaded to provide more speaker outputs to cover a larger space by connecting the LINE OUT of the preceding SY-2A-20W to either of the two LINE inputs of the next SY2A-20W amplifier. Using IR Remote Controls Connect the IR sensor to the IR socket and place the detector in sight of the remote control keypad. -
Page 6: Safety Instructions
SY-2A-20W Action Command Response 605% Bass of LINE: 04 Raise BASS level 606% Bass of LINE: 03 Lower BASS level 607% Treble of LINE: 04 Raise TREBLE level 608% Treble of LINE: 03 Lower TREBLE level 609% Init OK Return to default values... - Page 7 SY-2A-20W Figure 1 – SY-2A-20W Connection Diagram www.sy.co.uk...
-
Page 8: Specifications
Damage to the product due to incorrect usage or storage Damage caused by unauthorised repairs Damage caused by mistreatment of the product 5. Please direct any questions or problems you may have to your local dealer before contacting SY Electronics. www.sy.co.uk...
