SERVICE MANUAL
STEREO RADIO
CASSETTE PLAYER
HS-TX516
HS-TX519
BASIC TAPE MECHANISM : 8ZM-3 P9NF,
S/M Code No. 09-00C-438-8N1
YU,YL,YZ
YZ
8ZM-3 P11NF

Advertisement

   Related Manuals for Aiwa HS-TX516

   Summary of Contents for Aiwa HS-TX516

  • Page 1 HS-TX516 YU,YL,YZ HS-TX519 SERVICE MANUAL STEREO RADIO BASIC TAPE MECHANISM : 8ZM-3 P9NF, CASSETTE PLAYER 8ZM-3 P11NF S/M Code No. 09-00C-438-8N1...
  • Page 2: Specifications

    SPECIFICATIONS Frequency range: For using in Europe and other countries For using in North and South America For using in Japan<YU,YL> Maximum output: Load impedance: Power source: Battery life (EIAJ, 1 mW output Playback): Maximum dimensions: Weight ACCESSORIES / PACKAGE LIST 8B-HRE-904-010 IB,YL(3L)S<[S]516YL>...
  • Page 3: Electrical Main Parts List

    ELECTRICAL MAIN PARTS LIST 1 / 1 C216 87-012-178-080 C-CAP,U 18P-50 CH C217 87-012-162-080 C-CAP,U 1P-50 CK 87-A21-684-040 C-IC,TA2145AF C218 87-012-162-080 C-CAP,U 1P-50 CK 87-A20-851-040 C-IC,TA2111F C219 87-010-831-080 C-CAP,U,0.1-16F 87-A21-846-030 C-IC,LC72348G-9A01 C220 87-012-199-080 CAP 220P C221 87-012-286-080 CAP, U 0.01-25 TRANSISTOR C222 87-A11-056-080...
  • Page 4: Transistor Illustration

    CHIP RESISTOR PART CODE Chip Resistor Part Coding Figure Resistor Code Value of resistor Chip resistor Dimensions (mm) Wattage Type Tolerance Symbol Resistor Code Form 1/16W 1005 0.35 1/16W 1608 0.45 1/10W 2125 1.25 0.45 1/8W 3216 0.55 TRANSISTOR ILLUSTRATION 2SC4215 CSA1362 RN1304...
  • Page 5 WIRING – 5 –...
  • Page 6 SCHEMATIC DIAGRAM – 6 –...
  • Page 7: Lcd Display

    LCD DISPLAY LCD, ASSY (BHR-C) 17P – 7 –...
  • Page 8 IC DESCRIPTION IC, LC72348G-9A01 Pin No. Pin Name Description XOUT Crystal oscillator (75kHz) pin. TEST2 Connected to ground. PA3~PA0 Key input. H:Key exist, L:No Key. (Not Used) PB3~PB2 Not used. 9~10 PB1~PB0 Key output. H:Scan, L:Standby. (Not used) PC3(FM/AM) Output band. H:FM band, L:AM band. PC2(TV OUT) Output band.
  • Page 9 Pin No. Pin Name Description Output error. Output low pass filter. VT input. AGND Connected to ground. TEST1 Connected to ground. Crystal oscillator (75kHz) pin. – 9 –...
  • Page 10 ADJUSTMENT <TAPE PLAYER SECTION> <RADIO SECTION> 1. AM IF Adjustment 5. Tape Speed Adjustment IFT200 ................450kHz Settings: • Test tape : TTA–100 • Test point : PHONES (J100) 2. AM Tracking Adjustment • Adjustment location : SFR100 L203 ................. 630kHz •...
  • Page 11: Mechanical Exploded View

    MECHANICAL EXPLODED VIEW 1 / 1 8ZM-3 BAR ANT,MW HS-TX516 YUBSF,YL1BSF,YL1SF,YZ1BLF,YZ1SF – 11 –...
  • Page 12: Mechanical Parts List

    MECHANICAL PARTS LIST 1 / 1 1 8B-HRE-001-010 LID,CASS<[S]516YU,[S]516YL> 1 8B-HRE-018-010 LID,CASS BLU EG<[L]516YZ> 1 8B-HRE-012-010 LID,CASS EG<[S]519YZ,[S]516YZ> 2 8A-HRH-209-010 SPR-T,CASS 3 8Z-HRB-201-110 HLDR,BAR-ANT 4 8Z-HRB-208-010 BAT-CONTACT,P 5 8Z-HRB-209-010 BAT-CONTACT,M 6 8B-HRC-015-010 LID,BAT BLU<[L]516YZ> 6 8Z-HRB-005-110 LID,BAT SIL<EXCEPT [L]516YZ> 7 8B-HRE-013-010 CABI,REAR 516 EG<[S]516YZ>...
  • Page 13 TAPE MECHANISM EXPLODED VIEW 1 / 1 8ZM-3 P9NF : EXCEPT HS-TX516<YZ1BLF> W-P,1.16-2.8-0.4 27 30 HEAD ASSY, PH 8ZM-3 8ZM-3 P9NF,P11NF (FileName:MECH.EPS) – 13 –...
  • Page 14 TAPE MECHANISM PARTS LIST 1 / 1 8ZM-3 P9NF : EXCEPT HS-TX516<YZ1BLF> 1 8A-HRE-010-110 FRAME,CENTER GRY 2 8Z-HRB-207-110 SPR-P,CASS 3 88-ZM3-253-110 SPR-C,BT L 4 88-ZM3-274-010 GEAR,REEL A 5 87-A91-379-010 MOT,BCY3B-13 6 88-ZM3-236-010 PULLEY,MOT S 7 88-ZM3-263-210 BELT,S 8 88-ZM3-243-010 SPR-T,PLAY BACK...
  • Page 15 TAPE MECHANISM EXPLODED VIEW 1 / 1 8ZM-3 P11NF : HS-TX516<YZ1BLF> W-P,1.16-2.8-0.4 27 30 HEAD ASSY, PH 8ZM-3 8ZM-3 P9NF,P11NF (FileName:MECH.EPS) – 15 –...
  • Page 16 TAPE MECHANISM PARTS LIST 1 / 1 8ZM-3 P11NF : HS-TX516<YZ1BLF> 1 8B-HRE-019-110 FRAME,CENTER BLU 2 8Z-HRB-207-110 SPR-P,CASS 3 88-ZM3-253-110 SPR-C,BT L 4 88-ZM3-274-010 GEAR,REEL A 5 87-A91-379-010 MOT,BCY3B-13 6 88-ZM3-236-010 PULLEY,MOT S 7 88-ZM3-263-210 BELT,S 8 88-ZM3-243-010 SPR-T,PLAY BACK...
  • Page 17 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 9630472 0251431 Printed in Singapore...
