- Page 1 Bluetooth Handheld Keyboard (with option of Laser Pointer) User Manual Rev. 1.0 - Multi-language supporting - Multi-touch&Scrolling bar - Google TV Keybaord...
- Page 2 Introduction: this Bluetooth Handheld keyboard consists of keyboard, mouse touchpad, and laser pointer(optional) which is designed small and portable size. It provides people a unique & capable tool to operate their personal computer wirelessly. it is widely used for: ■ the people who need to be apart from their personal computer yet must control it for their presentation, teaching, and lecturing with large screen or projector, up to 33 feet wireless operation distance provides you big free space to communicate with your audience.
- Page 3 7 8 9...
- Page 4 NUMBERED FUNCTION OPERATION FEATURE PRESS LASER BUTTON(SEE ARROW 19) ARROW 1 LASER EMITTER TO ACTIVE IT SLIDE YOUR FINGER TO MOVER MOUSE ARROW 2 TOUCH PAD SLIDE YOUR FINGER ON THIS AREA TO SCROLL BAR ARROW 3 SCROLL PAGE YOU VIEWING PRESS THIS KEY TO RE-BUILD ARRAW 4 BLUETOOTH RESET...
- Page 5 1. Pairing and establishing connection with computor. Windows XP/2000 Let's take Microsoft Bluetooth Software as an example to describe Bluetooth Search,Pairing and Connection, other Bluetooth software please refer to its own user manual. 1.1 Insert Bluetooth adaptor into any vacant USB port on your computor, please be patient to wait system search and install new hard driver.
- Page 6 1.6, When the wizard asks you which passkey you want to use, click “Choose a passkey for me”. Then click “Next”. 1.7 After you are prompted to enter your passkey, please type the passkey on Bluetooth Handheld Keyboard, and then press Enter. You also can choose no passkey to go next step. PLEASE DO REMEMBER TO USE THE KEY OF BLUETOOTH HANDHELD KEYBOARD WHEN INPUT PASSKEY 1.8, In the final page of the wizard, click Finish, it maybe take a few seconds for new hardware driver...
- Page 7 Windows 7 Plug bluetooth receiver into any vacan USB port on your computor, please be patient to wait the system recognize your device, it maybe take several minutes. When new hardware has finished driver installation, an icon will appear in the task bar. Right click icon of bluetooth, select “Add a Device”...
- Page 8 Turn keyboard on by sliding the power switch to ON, LED3 will flash one time, then press key “bluetooth reset” till LED3 flash. And Bluetooth Keyboard will appear in the window. Select it and click “Next” Bluetooth Reset Bluetooth keybaord LED3 Then you will be promoted to input a pass code for your device, please do type the code with bluetooth keyboard, then press Enter...
- Page 9 Star ting Bluetooth Handheld Keyboard 1. The Bluetooth Handheld Keyboard has a battery saving feature. This feature puts the device into sleep mode if you do not use it for a long time. You can wake up the unit by pressing any key for one second. 2 Arrow 14 points to the Fn key.
- Page 10 5. When the backlit light up without any operation , this indicates your battery voltage has a low charge and needs to be recharged. The Bluetooth Handheld Keyboard is equipped with a re-chargeable battery. We have supplied you with a USB cable, which is plugged into a vacant USB slot on your computer and the bottom of the Bluetooth Handheld Keyboard, as indicated by arrow 20 .
- Page 11 Multi-touch application: the touchpad supports various gesture, the related gesture and function is described below: Finger Finger Touchpad Mouse Remark Gesture Action Function Function Move Slide one finger Moving Cursor on the touchpad Scroll upward Tap the touchpad Middle Middle Scroll with two finger botton...
- Page 12 WEEE Directive & Product Disposal At the end of its serviceable life, this product should not be treated as household or general waste. It should be handed over to the applicable collection point for the recycling of electrical and electronic equipment, or returned to the supplier for disposal Not i c e t o c u s t omers : This symbol on the battery indicates that the battery is to be...
- Page 13 And used in accordance with the instructions, may cause harmful interference to radio communications. However,there is no guarantee that interference will not occur in a particular installation.If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna.
- Page 14 该款手持蓝牙键盘是本公司在前面无线键盘触摸板系列上增加的又一款新产品，继承了前 一系列产品结构简单，小巧，携带方便等特点，并在此基础上增加了激光笔，F1，F2，...F10 等功能键，集鼠标,键盘,以及激光笔等功能于一体,是当今世界上体积最小，功能最为齐全的一 款键盘，无论是会议主持演讲，教育培训，还是家庭电脑娱乐，拥有一款蓝牙键盘激光笔，会 让你轻松自如地远距离控制你的电脑。是一款真正的电脑遥控器. 作为一款新型的蓝牙键盘，采用蓝牙无线连接技术,遥控达10米半径范围. 该蓝牙手持键盘采用QW E R T Y式键盘布局, 包含了标准键盘所有常用功能键和字符键, 方便实用 该产品的触摸板采用电容感应式触摸板,为你的提供准确的鼠标指针定位. 与分体式鼠标 一样的方便使用,亦可进行多媒体会议或演讲手写标注. 一, 特点与规格: 1. 蓝牙无线连接：Blu e t o o t h v 2 . 0、B l u e t o o t h H ID v1.0. 2.
- Page 15 三 ，主 要 功能 键布局 以及 说 明 7 8 9...
- Page 16 功 能 描 述 操 作 描 述 发射激光 激光头 用手指触摸以移动鼠标 触摸板 滚动条 用手指在此区上下移动以快速移动页面 蓝牙重启键 单击以重新使键盘处于可连接状态 单击以打开和关闭背光灯 背光灯开关按键 LED1 充电指示灯，充满电时熄灭 LED2 外接电源指示灯 信号传输指示灯，数据传输过程中灯闪 LED3 转换到大写输入时灯亮， LED4 电源开关 打开或关闭电源 开始菜单快捷键 单击以进入到开始菜单 单击打开快捷菜单 快捷菜单按键 组合键 “Ctrl, 同时按住Fn和Enter键等于同时 按住普通键盘上CTRL, ALT,DEL三个键 Alt, Del” 配合其它的键同时操作 Fn 按键...
- Page 17 四.使用 说明 1 连 接建 立：首 先要 确 定你 要连接 的电 脑 是否 具 有蓝 牙功能 ，如 果 没有 的话， 你必 须 要有 一个蓝 牙适 配 器使 之与电 脑相 连 接。 1 .1打 开电 脑中 蓝 牙通 信 软件,使 之处 于 可搜 寻其它 蓝牙 设 备的 状态.具体 操作 请 参 考...
- Page 18 键 的使用 F n是配合以下键使用的：F1,F2...F12, E NTER， Ins, PrtScr, Home, End, Del , 以及触摸板换向键（箭头22），使用时，同时按住 Fn键，以及你想要操作的那个按键，比如： 在标准键盘上，同时按住CTRL+ALT+DE L三个键就可以进行重启，任务管理，等操作，在该无 线键盘上，你只需要同时按住Fn以及Enter就可以。 3 充电: 该无线键盘激光笔配有内置锂电池，如果在开机状态下，没有进行任何的操作，背光灯 自动闪亮,那说明该无线键盘激光笔已处于低电压,需要充电,将 US B 线的一头插入到电脑主机的 上USB接口，另一头插到无线键盘激光笔上的Mini USB 插孔，1号指示灯会亮。充电满时1号指示 灯自动熄灭，LED 2会亮，这时拔掉USB充电线，LED2会熄灭. 4 背光灯:该无线键盘配有背光灯，如果你在黑暗或光线较暗的环境下操作，你可以单击背光灯按 按 钮（箭头5)打开背光灯，同样再按一次该键即可关闭背光灯。 5. 激光笔：该无线键盘配有激光笔以供多媒体教学，培训，演讲，演示。用手指按住激光笔按钮 （如图箭头19所示），激光头就会发射红色激光，释放该按钮即可关闭激光。 6.触摸屏输入: 移 动鼠标: 将手指放在触摸屏上,然后滑动手指,就会快速移动鼠标.移动鼠标到目的位置,然后轻 击...
- Page 19 五，多点触摸应用: 多点触摸应用说明如下图： 等效鼠 图示描述 触摸功能 图示 备注 标功能 移动鼠标 在触摸板上滑动 移动 光标 手指 向 上 同时用两个手指 中键单击 中键单击 向下 在触摸板上单击 在浏览网页时双指 单击会出现滚动条 如上图所示，将光标 移至该图上方则向上快速 移动页面，反之则向下 滚动鼠标 两手指垂直 中键 两手指垂直 方向移动 在 浏 览 图 片 时 ， 两 个 手 指 向 上 、 下 移 方向移动...
